Components and Connections
Wireless Smart Combiner Box - Front View
1
Antenna
2
Channel indicator LEDs
3
Power indicator LED
6
Wireless Smart Combiner Box - Rear View
1
2
3
10
4
AC power in socket
5
Fuse holder
6
Power switch
7
Bandwidth selection switch (currently not in use)
8
Frequency range selection switch
9
Control Net connector
10
Serial connector
4
5
6
7
8
9
