Configuration
Receiver Unit
Set the channel number (0 to D) being used by the specified controller.
Wireless Smart Combiner Box
A switch is provided on the wireless smart combiner box to select a
range of five channels (0 to 4 or 5 to 9) for the unit to receive.
18
CH. 5-9
CH. 0-4
Second Wireless Smart Combiner Box
In an installation with two wireless smart combiner boxes, the second
box switch is set to the opposite five channels range.
Box 1
CH. 0-4
Box 2
CH. 5-9
