TSI Power Corporation
ATS-500 Series
TSI Power Model Number:
:
DANGER
Make sure unit is de-energized before beginning.
CAUTION:
These instructions must be followed or board failure will result.
Caution: No user serviceable parts.
Caution: Only a trained engineer, electrician or technician should perform this procedure.
Caution: For personnel safety, remove metallic watches and rings.
Always wear protective eye glasses, insulated gloves and insulated shoes.
This is a quick reference start-up guide. Go to TSI Power's website or contact TSI directly to obtain the ATS-500 Series
Product Manual. (TSI Power's contact information is on page 5.)
IMPORTANT SAFETY INSTRUCTIONS: SAVE THESE INSTRUCTIONS - This manual contains important
instructions for the ATS-500 Series that should be followed during installation and maintenance of the ATS.
Please inspect the unit for visible shipping damage (such as damaged case or broken parts)
Table of Contents
Safety Alerts....................................................................................................................................................................... 2
Tools and Test Equipment Required................................................................................................................ 2
Voltage Selection.......................................................................................................................................................... 2
Remote Status / Alarm Monitoring.................................................................................................................. 2
Power-Up Procedure................................................................................................................................................. 4
Contact Information................................................................................................................................................... 5
April, 2021
START-UP GUIDE
ATS-500 Series
Page 1 of 5
SG03501
Rev. 3
Page
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TSi Power ATS-500 Series
Summary of Contents for TSi Power ATS-500 Series
- Page 1 Always wear protective eye glasses, insulated gloves and insulated shoes. This is a quick reference start-up guide. Go to TSI Power's website or contact TSI directly to obtain the ATS-500 Series Product Manual. (TSI Power's contact information is on page 5.) IMPORTANT SAFETY INSTRUCTIONS: SAVE THESE INSTRUCTIONS –...
- Page 2 TSI Power Corporation April, 2021 SG03501 ATS-500 Series Rev. 3 SAFETY ALERTS - SAFETY SIGNAL WORD DEFINITIONS This document contains safety alert pictorial Symbols and Words that point out areas and procedures that require special attention with regards to safety. These Symbols and Words are defined in ANSI Z535.4-1998, Product Safety Signs and Labels.
- Page 3 TSI Power Corporation April, 2021 SG03501 ATS-500 Series Rev. 3 PZ00120-5 Control JP13 (ATS ENABLE) JP1 (HIGH) or JP2 (LOW) PZ00127-5 Control (Figure 1) CAUTION: The unit must be placed in a well – ventilated area to prevent risk of fire due to over- heating.
- Page 4 TSI Power Corporation April, 2021 SG03501 ATS-500 Series Rev. 3 Power-Up Procedure Perform a visual inspection of the ATS-500 unit and verify that it is not physically damaged. Verify that the equipment label states correct voltage, frequency and amperage of the input & output AC power sources.
- Page 5 Factory address: 1103 West Pierce Avenue, Antigo, Wisconsin 54409, USA Internet: www.tsipower.com Hours of operation are from 8AM to 5PM (Central Standard Time), Monday through Friday TSI Power will try to reply to E-mail requests for technical support within 24 hours. REVISIONS Rev.
