Summary of Contents for TSi Power 10000
- Page 1 TSi P OWER Operating Instructions U P S - 1 0 0 0 0 / 1 0 0 0 B 1 6 0 0 0 / E X T - 8 0 0 0 Uninterruptible Power Supply...
-
Page 3: Save These Instructions
CONSERVER CES INSTRUCTIONS Cette Notice Contient Des Instructions Importantes Concernant La Sécurité. This manual contains important instructions for models UPS-10000, UPS-16000 and EXT-8000 that should be followed during installation and maintenance of the UPS and batteries. Nominal Battery Voltage of the battery supply inside the UPS and Battery Extension Unit is 48 volts. -
Page 4: Table Of Contents
Remote UPS Access ................9 Serial RS-232 Communications ............10 Backup Time Chart ................12 EXT-8000 Battery Extension Units ............13 Troubleshooting and Maintenance ............14 Specifications ..................15 Installation Procedure for Mounting Kits ..........17 UPS-10000, 16000 & EXT-8000 Operating Instructions... -
Page 5: Quick Installation Guide
We suggest however that you read the rest of this manual to derive the most benefit from your investment in TSi Power’s UPS’s. If you’ve encountered any problems in this quick installation procedure, please read on. You can also refer to the troubleshooting guide on p. -
Page 6: Front Controls, Functions & Indicators
Inverter On Light (Yellow) This light blinks when AC power is abnormal and UPS is operating on battery. Remote Mode Light (Orange) This light blinks when UPS is placed in REMOTE mode using the MODE switch. UPS-10000,1000B, 16000 & EXT-8000 Operating Instructions... -
Page 7: Rear Controls & Functions
UPS Output Sockets If you are not sure how much power your Connect equipment to be backed up to these outlets. UPS-10000 has 4 sockets and equipment draws, see maximum output power of 750 watts. UPS-16000 has 6 sockets and maximum insert, “Load Ratings... -
Page 8: Ext-8000 Controls, Functions & Indicators
Connects to another EXT-8000 Battery Extension Unit. Battery Extension Connector To find out how much holdup time you can expect, Connects to a UPS-10000, UPS-16000 or another EXT-8000 Battery consult the chart on p. 12. Extension Unit. Battery Extension Fuses protects against short or overload in the battery extension circuit. -
Page 9: About Your Ups
About Your UPS Normally, your TSi Power UPS-10000 and UPS-16000 Uninterruptible Power Supplies work as constant voltage regulators and line conditioners, filtering out noise and irregularities to provide pure sinewave power to your equipment. However, when incoming AC voltage is too low or too high, or when a power outage occurs, they provide the same pure uninterrupted sinewave power from their internal batteries. -
Page 10: Operating Instructions
UPS. Turn the equipment off for now. CAUTION: Make sure that your equipment does not draw more the maximum power rating of the UPS. For the UPS-10000, the maximum power rating is 750W. For the UPS-16000, the maximum power rating is 1200W. - Page 11 the status of the UPS. They can be read as follows: # OF ON BARGRAPH DISPLAY OUTPUT BATTERY OUTPUT SEGMENTS VOLTAGE VOLTAGE LOAD 112 Vac 40.6 Vdc 114 Vac 42.2 Vdc 116 Vac 44.8 Vdc 118 Vac 46.4 Vdc 120 Vac 48.0 Vdc 122 Vac 49.6 Vdc...
-
Page 12: Network Installation & Alarm Interface
POWER switch must be turned off, then on again, in more than 90% charged. order to re-start the UPS. Network Alarm Interface & Installation Your UPS-10000 and UPS-16000 provide UPS alarm Pin # Name Function reporting for Novell NetWare, UNIX, Windows for SHUTDOWN Input to UPS. -
Page 13: Remote Ups Access
27F2 TO REDUCE THE RISK RS-232 BAUD ® OF ELECTRIC SHOCK, INTERFACE RATE INTERFACE UPS-10000 UNINTERRUPTIBLE INSTALL IN A TEMPERATURE POWER SUPPLY AND HUMIDITY CONTROLLED AC INPUT: 120V, 60HZ, 10A MAX, P.F.=1 INDOOR AREA FREE OF UPS OUTPUT: 120V, 60HZ, 6.2A MAX, P.F.=1 CONDUCTIVE CONTAMINANTS. -
Page 14: Serial Rs-232 Communications
Normally, you would have to keep your remote PC turned on all the time, thus reducing its life and wasting electricity. With your TSi Power UPS, you can keep the remote PC off, and only turn it on when necessary. You would configure the remote PC to run a communications program—such as... - Page 15 The cable connection is made through the female DB-9 connector marked See accompanying list of accessories for information RS-232 INTERFACE, located in the rear of the UPS. Cables that link the about ordering cables. UPS with the computer are available as an option. If you wish to make your own cable, the table below shows the pinouts of the serial ports of the UPS and typical IBM compatible PC’s.
-
Page 16: Backup Time Chart
Additional EXT-8000’s can be daisy-chained for even can also consult the insert, “Load longer backup times. The chart below shows backup times possible with Ratings for Typical Equipment”. various combinations of UPS-10000, UPS-16000 and EXT-8000. 1.5 days 1.5 days 1 day... -
Page 17: Ext-8000 Battery Extension Units 13
EXT-8000 Battery Extension Units Installation To connect one or more EXT-8000’s to an UPS-10000 or UPS-16000, see the figure below and follow these steps. (1) Turn off the UPS and the Battery Extension Units before proceeding! (2) Stack the EXT-8000(’s) under the UPS as shown below. -
Page 18: Troubleshooting And Maintenance
Remove other equipment from the same circuit tripping. served by the circuit breaker. * Please call your dealer or TSi Power for before returning the UPS. † Battery Replacement: Under normal conditions, the battery lifetime is approximately 4 to 5 years. Your authorized dealer or factory can replace batteries for a nominal fee. -
Page 19: Specifications
• Brownout threshold: 95±2V • Overvoltage threshold: 135±2V Battery & Charger • UPS-10000 series: 48Vdc, 7Ah battery, 1.5A half-wave charger. • UPS-16000 series: 48Vdc, 10Ah battery, 2A half-wave charger. • EXT-8000 series: 48Vdc, 17Ah battery, 2A half-wave charger. • Batteries are charged to a float voltage of 56Vdc at an optimum rate to ensure long life and maximum capacity. - Page 20 • Maximum withstanding weight: 400 lbs (180kg). Warranty • 2 years limited warranty, parts & labor (except for batteries). • Battery manufacturer’s warranty on batteries (typically 1 year). • Extended warranty available. 1 6 UPS-10000,1000B, 16000 & EXT-8000 Operating Instructions...
-
Page 21: Installation Procedure For Mounting Kits
• Do not place any equipment heavier than 30 lbs (14 kg) on top of a rack-mounted UPS-10000, UPS-16000 or EXT-8000. • It is strongly recommended that the UPS-10000, UPS-16000 or EXT- 8000 unit is placed on top of a weight-bearing shelf capable of support- ing a minimum of 200 lbs (90 kg). - Page 22 8. When the unit is being held firmly in position by the 4 brackets at all 4 corners by all 16 bolts (4 in front, 8 from bottom, 4 in rear), and all the bolts are tightly fastened, the stretcher may be removed from under the unit. 18 UPS-10000, 16000 & EXT-8000 Operating Instructions...
-
Page 23: Limited Warranty
Limited Warranty TSi Power warrants this product to be free from defects in materials and workmanship for two (2) years † from the date of purchase from TSi Power or its authorized representatives. TSi Power will repair (or at its option, replace) any defective component(s) during this warranty period. - Page 24 Internet: www.tsipower.com e-mail: sales@tsipower.com © Copyright—2002 TSi Power Corp. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies.
