TSi Power UPS-400 Operating Instructions

SPECIFICATIONS
AC Input • 95V to 135V , 47 to 63 Hz, sinusoidal.
AC AC
• 75V to 150V , UPS-400LIC & 600LIC.
AC AC
, 50 or 60 ±3 Hz (user selectable), modified
UPS Output • 108 to 125 V
RMS
sine wave.
• UPS-400: 400 VA/240 W maximum.
• UPS-600: 600 VA/400 W maximum.
Power • Standard models provide 3-way MOV surge suppression
Conditioning and EMI/RFI noise filtering.
Low Impedance • UPS-400LI & 600LI models include low-impedance
Power Condition- isolation transformers for complete input-to-output line
ing (optional) isolation.
• UPS-400LIC & 600LIC models include line isolation and
wide input voltage range power conditioning.
Efficiency • 98% or higher during AC operation.
(Standard Model) • 90% or higher for LI and LIC options.
• 70% or higher during inverter operation.
Transfer Times • 4 ms. typical between AC and inverter.
Battery & Charger • UPS-400 has 84 VAh of battery capacity for about 5
minutes of holdup at full load, 15 minutes at half load.
• UPS-600 has 120 VAh of battery capacity for about 4
minutes of holdup at full load, 13 minutes at half load.
• Optional extended battery models UPS-400X and UPS-
600X have battery capacities of 204 VAh, doubling or
tripling the usual holdup times.
Audible Noise • Less than 40dB at 1.5m, ANSI A scale, during inverter
operation.
Safety and • Designed to meet UL/CSA/IEC standards of safety.
Reliability Features • External fuse protects all AC circuits.
• Internal fuse protects all DC circuits.
Size and Weight • Width: 5" (12.7 cm)
• Depth: 16" (40.6 cm)
• Height: 7" (17.8 cm)
• Weight: UPS-400: 18 lbs (8.2 kg)
UPS-600: 20 lbs (9.1 kg)
Operating • Operating Temperature: 0°C to 40°C (32°F to 100°F).
Environment • Relative Humidity: 90%, non-condensing at 25°C.
• Estimated MTBF: 12 years excluding batteries.
Warranty • Two years limited warranty, parts and labor (excluding
batteries).
• Extended warranty available.
LIMITED WARRANTY
TSi Power warrants this product to be free from defects in materials and
workmanship for two (2) years † from the date of purchase from TSi Power or its
authorized representatives. TSi Power will repair (or at its option, replace) any
defective component(s) during this warranty period.
To make a request or claim for service under this limited warranty, the original
purchaser must return the product, in the original shipping container or equiva-
lent, to TSi Power or its authorized distributor, accompanied by a written receipt
showing the date of purchase, dealer's name, and both the model name and serial
number of the product.
Warranty does not cover transportation costs. Damage by misuse, accident or
unauthorized tampering of the product is not covered by the warranty. NO
OTHER WARRANTIES ARE EXPRESSED OR IMPLIED. TSI POWER IS NOT
LIABLE FOR CONSEQUENTIAL DAMAGES. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE.
† Excluding batteries. Battery manufacturer's warranty applies on batteries.
LIMITATION OF LIABILITY
IN NO EVENT SHALL TSI POWER OR ITS SUPPLIERS BE LIABLE FOR ANY
DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION, DAMAGES
FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF
BUSINESS INFORMATION, OR OTHER PECUNIARY LOSS) ARISING OUT OF
THE USE OR INABILITY TO USE THIS TSI POWER PRODUCT, EVEN IF TSI
POWER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
SOME STATES DO NOT ALLOW THE LIMITATION OR EXCLUSION OF
LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
TSi POWER CORP.
1103 West Pierce Avenue
Antigo, Wisconsin 54409, U.S.A.
Phone: (715) 623-0636 FAX: (715) 623-2426
Internet: www.tsipower.com e-mail: sales@tsipower.com
© Copyright—1999 TSi Power Corporation. All rights reserved.
TSi Power's ongoing product improvement process makes specifications subject to change.
Other company's product names herein are for identification purposes only and may be trademarks of
their respective companies.
TSi P
OWER
Operating Instructions
UPS-400 & UPS-600
Uninterruptible Power Supply
