TSi P
OWER
Operating Instructions
UPS-550B
UPS-720B
2 0 0
U P S -7
S
A T O R
IN D IC
OT E
RE M
IN V ON
CH RG
BA T
AC ON
M
A L A R
E R
P O W
O T E
R E M
Uninterruptible Power Supply
TSi P
C
OWER
ORPORATION
1103 West Pierce Avenue
Antigo, WI 30071, USA
Phone: (715) 623-0636
FAX: (715) 623-2426
Internet: www.tsipower.com e-mail: sales@tsipower.com
© Copyright—2000 TSi Power Corporation. All rights reserved.
TSi Power's ongoing product improvement process makes specifications subject to change.
Other company's product names herein are for identification purposes only and may be trademarks of their respective companies.
Advertisement
Table of Contents
Related Manuals for TSi Power UPS-550B
Summary of Contents for TSi Power UPS-550B
-
Page 1: Operating Instructions
Internet: www.tsipower.com e-mail: sales@tsipower.com © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. -
Page 2: Save These Instructions
Mounting Kits for important safety information. © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. -
Page 3: Table Of Contents
Installation Procedure for Mounting Kits ..........13 © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. -
Page 4: Quick Installation
We suggest however that you read the rest of this manual to derive the most benefit from your investment in TSi Power’s UPS’s. If you’ve encountered any problems in this quick installation procedure, please read on. You can also refer to the troubleshooting guide on p. -
Page 5: Front Controls & Indicators
REMOTE switch. © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. -
Page 6: Rear Controls & Functions
Outlets for the equipment to be supported by the UPS. The power accompanying table, “Load Ratings drawn from these receptacles should not exceed 360 watts for UPS-550B for Typical Equipment” and 500 watts for UPS-720B. -
Page 7: About Your Ups
(hence the name) power to protect your valuable equipment and data. Features of your TSi Power UPS • TSi Power’s UPS-550B & UPS-720B series perform the basic function explained above, and much more. Its architecture is that of a standby UPS (or off-line UPS), whose inverter is only activated when the line AC becomes irregular. -
Page 8: Detailed Operating Instructions
The maximum amount of power that each of your equipment will draw should be printed in the rear of each equipment, near the power cord. Their sum should not exceed 360 watts for UPS-550B and 500 watts A typical desktop PC or Mac with for UPS-720B. -
Page 9: Network Installation & Alarm Interface
© Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. - Page 10 Network Installation & Alarm Interface 7 © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies.
-
Page 11: Remote Ups Access
© Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. - Page 12 Normally, you would have to keep your remote PC turned on all the time, thus reducing its life and wasting electricity. With your TSi Power UPS, you can keep the remote PC off, and only turn it on when necessary. You would configure the remote PC to run a communications program—such as...
-
Page 13: Typical Holdup Times
11 min 7 min © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. -
Page 14: Trouble-Shooting And Maintenance
Repairs can be performed only at the factory or at an authorized repair centers by qualified personnel with protective equipment. When you encounter difficulties with your UPS, please consult the relevant sections of this manual and check the trouble-shooting guide below. If you still have problems, please call TSi Power’s Customer Service at (715) 623-0636. Problem... -
Page 15: Ups Technical Specifications
• Extended warranty available. © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. -
Page 16: Installation Procedure For Mounting Kits
Installation Procedures for Mounting Kits 13 © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies. - Page 17 © Copyright—2000 TSi Power Corporation. All rights reserved. TSi Power’s ongoing product improvement process makes specifications subject to change. Other company’s product names herein are for identification purposes only and may be trademarks of their respective companies.
-
Page 18: Limited Warranty
Limited Warranty TSi Power warrants this product to be free from defects in † materials and workmanship for two (2) years from the date of purchase from TSi Power or its authorized representatives. TSi Power will repair (or at its option, replace) any defective component(s) during this warranty period.
