ROSSO
E-QUAD X
ELECTRIC ATV
OWNERS MANUAL -
EN
PRIOR TO FIRST USE, READ THIS MANUAL COMPLETELY AND ATTENTIVELY! IMPERATIVELY FOLLOW THE SAFETY INSTRUCTIONS!
NONOBSERVANCE CAN LEAD TO PERILOUS INJURIES! CAREFULLY KEEP THIS MANUAL!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-Quad X and is the answer not in the manual?

Questions and answers

Related Manuals for ROSSO MOTORS E-Quad X

Summary of Contents for ROSSO MOTORS E-Quad X

  • Page 1 ROSSO E-QUAD X ELECTRIC ATV OWNERS MANUAL - PRIOR TO FIRST USE, READ THIS MANUAL COMPLETELY AND ATTENTIVELY! IMPERATIVELY FOLLOW THE SAFETY INSTRUCTIONS! NONOBSERVANCE CAN LEAD TO PERILOUS INJURIES! CAREFULLY KEEP THIS MANUAL!

  • Page 2: General Information

    Rosso Motors recommends that you periodically review and reinforce the information in this manual with younger riders, and that you inspect and maintain your children’s electric ATV to insure their safety.
  • Page 3 ⚠ DO NOT EXCEED THE WEIGHT LIMIT OF 90 POUNDS. Rider weight does not necessarily mean a person’s size is appropriate to fit or maintain control of the electric ATV. Do not touch the brakes or electric motor on your electric ATV when in use and/or immediately after riding as they can become very hot.
  • Page 4 Do not ride the electric ATV in wet or icy weather and never immerse the electric ATV in water, as the electrical and drive components could be damaged by water or create other possible unsafe conditions. Wet, slick, bumpy, uneven or rough surfaces may increase risks of use. Do not ride the electric ATV in mud, ice, puddles or water.
  • Page 5 Assembly: ● The ROSSO eQuad X requires minimum assembly. ● Please follow instructions below in order to get your eQuad X assembled properly ● An assemble video can also be found at https://youtu.be/391UgZp587k ● The ATV comes protected by a metal frame. Unbolt the frame connections, cut any cable ties and remove the upper portion of frame.

  • Page 6: Handlebar Installation

    2. Handlebar installation: ⚠ Failure to properly adjust and tighten the bolts can cause loss of control and crash. Attach handlebar clamps (a) over top of the handlebars with the included bolts (b), correctly position the handlebars, tightening the bolts into place in the handlebar channel (c) which is now integrated into the steering column.
  • Page 7 4. Front rack and bumper installation: Ensure the plastic bumper piece is attached to the metal bumper with provided bolts. Remove the bolts from the bottom mount on the front of the frame, position the bottom holes of the bumper over the mount holes and hand tighten the bolts back into place. Remove the bolts from the top of the bumper, align the holes on the bumper with the ones on the front of the front rack, then replace the nuts and bolts, hand tightening for now.

  • Page 8: Reflector Installation

    5. Rear rack installation: Remove the bolts from the rear rack mount located on either side of the tail light. Align the holes of the rack with the holes of the mount and replace and tighten the bolts. 6. Reflector installation: Place each of the reflectors, 2 orange for the front, 2 red for the rear, into the reflector brackets on each rack, then secure them with the included nuts.

  • Page 9: Final Adjustments

    8. Final adjustments Adjust the position of the brake levers, secure them in place by tightening the single bolt. Ensure the seat is secure. Position the clip at the front of the seat under the bracket located within the body and then press firmly on the back of the seat to snap it into place. (Please note that the front clip simply slides under the bracket, the holes in the bracket are from a previous difficult to install version of the seat and there was no need to update the frame for the current easy secure seat!) Your eQuad X doesn’t come fully charged and we recommend fully charging...

  • Page 10: Basic Operation

    eQuad X Components: (a) forward/reverse gear switch (f) throttle/battery meter & front brake (b) battery w/ charging port (g) rear brake & headlight/horn buttons (c) controller (h) headlights (d) 800W motor (e) 3 speed switch (left side) & ignition switch (right side) eQuad X Operation: Basic Operation With the ATV powered on, gently twist the throttle until the desired speed is reached.
  • Page 11 To charge the battery separately from the atv, first disconnect the lead from the battery connecting it to the ATV, then remove the bracket holding it in place and pull out the battery box. Connect the charging adapter to the lead from the battery and then connect the charger to the adapter.

  • Page 12: Battery Level Indicator

    Battery Level Indicator The battery level indicator is located on the throttle handle on the right handlebar. The lights indicate the current battery level (Max 100%, Mid 50%, Min 10%-needs charging) and are also an easy way to tell if your ATV is turned on. If you turn your ATV off and the lights do not turn off, it may indicate that it was started with the other method of power up.

  • Page 13: Pre-Ride Checklist

    Pre-Ride Checklist: ⚠ Brakes - Check the brakes for proper function. When you squeeze the lever, the brake should provide positive braking action. Tires – Check tires periodically. Inspect tires for excess wear and replace as needed. (Please note riding on abrasive surfaces such as concrete or asphalt will increase tire wear.) Regularly check the tire pressure and inflate as needed.

  • Page 14: Wheel Alignment

    To adjust cable play on the left (rear) brake lever – tighten/loosen adjuster To adjust cable play on the right (front) brake lever - tighten/loosen adjuster To adjust the calipers, loosen (do not remove completely) anchor nut(a) and pull brake cable(c) until the brake pads are almost touching the rotor(b) (brake disc).

  • Page 15: Troubleshooting

    Chain Your ATV is chain driven and should be periodically lubricated with lithium spray. The chain may make some clicking noises, this is normal. Always inspect, maintain or adjust the chain, if necessary, before each ride. Riding with a chain in poor condition or one improperly adjusted, can lead to serious injury.

  • Page 16: Wiring Diagram

    Problem Possible Cause Solution Power ON but doesn’t move Motor connections loose Check and tighten connections Brake lever not released Release brake lever Gear shifter failure Check connections to gear shifter or replace if necessary Low travel distance Battery low/ not charged Charge battery Low tire pressure Inflate tires...

  • Page 17: Warranty

    Warranty ROSSO MOTORS warranties this product to be free of manufacturing defects for a period of 6 months from date of purchase. This Limited Warranty does not cover normal wear and tear, (tires, tubes or cables) or any damage, failure or loss caused by improper assembly, maintenance, storage or use of your eQuad X Electric ATV.
  • Page 18 11400 Twigg Place Unit 1 Richmond, BC, V6V3C1 CANADA E-Mail: hello@rossomotors.com Website: www.rossomotors.com Tel: 1-888-897-5909 © Rosso Motors, 2022. All Rights Reserved...
