- Page 1 HP10098 BASIC INDEPENDENT AIR SPRING ACTIVATION KIT...
- Page 2 INSTALLATION MANUAL - INSERT TITLE HERE, L1234 Thank you and congratulations on the purchase of a Pacbrake basic independent air spring activation kit. Please read the entire installation manual prior to starting the installation to ensure you can complete the installation once started.
- Page 3 BASIC INDEPENDENT AIR SPRING ACTIVATION KIT - HP10098 L5904 INSTALLATION MANUAL - INSERT TITLE HERE, L1234 COMPRESSOR AIR INTAKE FILTER Locate the air intake filter housing, barbed fitting and 6' length of blue nylon hose provided in kit. Choose a location to mount the filter housing within 6' of the compressor, the housing re- quires a 1/2”...
- Page 4 BASIC INDEPENDENT AIR SPRING ACTIVATION KIT - HP10098 L5904 INSTALLATION MANUAL - INSERT TITLE HERE, L1234 ELECTRICAL CONNECTIONS AT THE REAR OF THE GAUGE The red wire needs to be connected to the dash board illumina- tion circuit using the “T” tap provided.
- Page 5 BASIC INDEPENDENT AIR SPRING ACTIVATION KIT - HP10098 L5904 INSTALLATION MANUAL - INSERT TITLE HERE, L1234 PLUMBING CONNECTIONS Using a sharp razor knife, cut the end of the black nylon tube off squarely, push this end firmly into the push- to-connect fitting on the compressor until it stops.
- Page 6 Try to always jack the vehicle on the axle. Suspending the axle with the air spring limiting the axle travel will damage the air spring and void the air spring warranty. PG 6 PG 6 Printed in Canada L5904_rev4.3.30.11 Patents pending. Pacbrake is a registered trademark of Pacbrake Company. Other trademarks used herein are property of their respective holders.
