Engineers Quick Start Instructions -
1) Power device on, check the following are displayed in sequence:
(display test), then
and finally a single flashing dot.
2) Press rear red button briefly, the unit should now display:
(software version), then
3) Press the rear red button briefly again and the unit should display
- The unit can now be secured in the housing as all further
Programming can now be carried out from the front panel.
Program a Master Key
Hold the key to be set as a master in front of the reader. The 1
the buzzer will sound a continuous tone. This indicates successful programming
of this key. Remove the key.
A maximum of 3 keys can be programmed as masters. Repeat for the other keys
as necessary
To exit and return to normal operation, hold a master key in front of the unit for
approx 7 seconds, the display will show : -
the unit will return to normal.
1148/45 & 1158/45
(initialisation)
st
bar will rise and
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for urmet domus 1148/45
Summary of Contents for urmet domus 1148/45
- Page 1 Engineers Quick Start Instructions - 1148/45 & 1158/45 1) Power device on, check the following are displayed in sequence: (display test), then (initialisation) and finally a single flashing dot. 2) Press rear red button briefly, the unit should now display:...
- Page 2 Programming Hold a master key to the front panel, the unit will display, in sequence: Current software version (display only) User key storage/checking User key deletion/replacement Door release time Present a master key briefly to the front of the panel to exit programming. To add a user key 1) Hold a master key to the front of the unit until the following is displayed, then remove the...
- Page 3 User Key Deletion/Replacement Important: To delete a user key you must know its allocated key number. 1) Hold a master key to the front of the reader until the following symbol is displayed, then remove the master key. 2) Re-present the master key until the following is displayed; the first number will cycle through 0 to 9 repeating.
- Page 4 Setting of Door Release Open Time 1) Hold a master key to the front of the unit until the following symbol is displayed, then remove the master key. 2) Re-present the master key and hold for at least 2 seconds, the first digit will count up from 0 to 9 repeating.
- Page 5 Complete Reset of Memory The contents of the memory can be cleared completely so allowing the unit to be reused in another installation. To accomplish this proceed as follows: 1) Switch off the device 2) Press the rear red button, and whilst holding it down, switch on the device. 3) Hold the button down until the following is cleared from the display.
