12' x 20' x 8' Welded Shelter
Peaked Port Style Shelter
Assembly Instructions
DeScrIPtIon
MoDel #
12' x 20' x 8' Welded Shelter
62656
recoMMenDeD toolS
Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored.
THIS IS A TEMPORARY STRUCTURE AND NOT RECOMMENDED AS A PERMANENT STRUCTURE.
Before you start: 2+ individual recommended for assembly, approximate time 2 hr.
1-800-524-9970
150 Callender Road
Canada:
Watertown, CT 06795
1-800-559-6175
www.shelterlogic.com
2/10/10
Page 1
05-62656-0B
