1. Product Description
The HPM7000 is intended for recording the measured values of the
sensors connected. The sensors are connected via two CAN bus
network and analog inputs. In the case of sensors with automatic
sensor detection, the parameterization of units and measuring ranges
is automatic. In addition, sensors without sensor detection can be used
with analog signals as well as a digital input/output and two frequency
channels.
The HPM7000 can be extended by two input modules providing
additional connections and functions.
The HPM7000 is operated basically by using the touch-sensitive
touchscreen. Alternatively, the main functions can be selected via the six
hardware keys. The USB and LAN connections interface can be used
to connect the HPM7000 with a PC or local network to analyze the
measured values.
Fig. 1 The HPM7000
