3.4

Connection Ports - Input Modules

In addition to the basic connections, the device can be extended with up
to two further input modules.
The figure illustrates the slots for the input modules:
Fig. 6 Connection port, input module
Pos. Designation
1 Input module, SLOT
A
2 Input module, SLOT
B
Further information on the input modules available, the corresponding
connections and PIN assignment is available in Chapter "Input Modules".
1
Description
First slot for an input module
Second slot for an input module
Design and Function
2
