Product Description

About This Manual
This Quick Reference Guide is a component part of The HPM5000 and con-
tains important information on the intended use, safety, operation and mainte-
nance of the device described.
Subject to change without prior notice.
► Before each step, read the corresponding information carefully and adhere
to the sequence of steps described.
► Pay particular attention to Chapter & "Safety Information" and follow the
instructions.
1. Product Description
The HPM5000 is intended for recording the measured values of the sensors
connected. The sensors must be connected at the inputs available.
Sensors with automatic sensor detection parameterize the unit and measuring
range automatically. In addition, sensors can also be connected to AUX inputs.
The HPM5000 is operated basically by using the touch-sensitive touchscreen.
Alternatively, the main functions can be selected via the six hardware keys on
the device.
The USB-C port is used to connect the HPM5000 to a PC and thus enables
measured value evaluation to be completed. In addition, the USB-C port is also
used to charge the device.
