Delta Childrens Products 35301-310 Assembly Instructions Manual

Bassinet
Hide thumbs

Advertisement

Quick Links

Download this manual
Warranty
Your Delta Baby Gear is warranted to be free from defects for a
period of 30 days from the date of purchase under normal use.
This warranty extends only to the original retail purchaser and is
only valid when supplied with proof of purchase, or if received
as a gift, when the registration is on file with Delta.
Delta
Childrens's Products
Delta Children's Products, Inc.
114 West 26th Street
New York, NY 10001 (USA)
Web site:
www.DeltaChildrensProducts.com
E-mail:
customerservice@DeltaChildrensProducts.com
Customer Service Toll-Free:
TM
(212) 645-9033
Delta
TM
Childrens's Products
Bassinet
Assembly Instructions
If you have missing parts or
questions...
If a part is missing or you have questions, call us. DO NOT return
product parts to store from where it was purchased before calling us at:
(212) 645-9033
Our service is fast, free and easier than returning the product.
Important: So we can better assist you, have the model number and
manufacturer's code available. It is located at bottom right-hand corner of this page.
Before assembly, read these instructions. Make sure all pre-assembled parts are tight.
Store this instruction manual for future reference.
Adult assembly required.
©2008 Delta Children's Products, Inc. 35301-XXX_Bassinet_Instruction_V1
35301-310
Model Number
04 / 2011
Manufacturer's Code
Made in China

Advertisement

loading

Related Manuals for Delta Childrens Products 35301-310

Summary of Contents for Delta Childrens Products 35301-310

  • Page 1 New York, NY 10001 (USA) Our service is fast, free and easier than returning the product. Important: So we can better assist you, have the model number and 35301-310 Web site: www.DeltaChildrensProducts.com manufacturer’s code available. It is located at bottom right-hand corner of this page.
  • Page 2 Disassembling Bassinet for Storage BASSINET WARNINGS WARNING - Failure to follow these warnings and assembly instructions To disassemble Bassinet for storage, follow assembly steps in reverse. could result in serious injury or death. Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR Store all parts and hardware together in a safe place.
  • Page 3 CHANGING TABLE WARNINGS Notes WARNING - Failure to follow these warnings and assembly instructions could result in serious injury or death. Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE. WARNING - FALL HAZARD – To prevent death or serious injury, always keep child within arm’s reach.

  • Page 4: Part Numbers

    Parts and Part Numbers Frequently Asked Questions - continued 7) Batteries DO NOT REMOVE FOAM FROM BASSINET PARTS - Bassinets require 3 “C” batteries. 00066 00064 - Locking 00084 - Accessory - Accessory - If your bassinet includes a remote control, the remote control requires 3 “AAA” batteries. Rocker Base Basket Basket Tubes...
  • Page 5 Parts & Hardware/Part & Hardware Numbers Frequently Asked Questions 1) Warranty Information 01629 - Mobile 00142 - Mobile All Delta bassinets include a 30-day limited warranty. Please fill out the product registration card that Propeller with Toys Remote Control (x1) (x1) accompanied your bassinet, and mail it back to us so we can have your information on file.

  • Page 6: Mobile Operation

    Mobile Operation Parts Needed: 00065 - Non-Locking 00066 - Accessory Rocker Base Basket Tubes (x1) (x2) Rotate Mobile Toys Small Lights Music Bassinet Base Assembly Vibration Night Light Vibration Music Volume Adjustment Adjustment Mobile Functions On/Off Night Light - activates the mobile light. Press to turn on mobile light for 5-minutes. To turn off sooner than 5-minutes, press again.

  • Page 7: Caster Assembly

    Parts Needed: Parts Needed: 00077 - Rocker Leg 00068 - Rocker Screw Legs (x2) (x2) Caster Assembly 00084 - Accessory Basket 00078 - Screwdriver (x1) HARDWARE SHOWN AT ACTUAL SIZE To Lower Casters: Bassinet Base Assembly - continued To Raise Casters: Insert two (2) Rocker Legs (D) into Non- Locking Rocker Base.
  • Page 8 Parts Needed: Parts Needed: 00068 00077 - Rocker Leg - Rocker Screw Legs (x2) (x2) Changer Assembly 00064 - Locking Rocker Base 00078 - Screwdriver (x1) HARDWARE SHOWN AT ACTUAL SIZE Bassinet Base Assembly - continued On other side of assembly, attach Rocker Legs (D) into Locking Rocker Base (C).
  • Page 9 Parts Needed: Parts Needed: 01629 - Mobile Assembly (x1) Bassinet Base Assembly - continued Bassinet Basket Assembly - continued Connector Figure 1 Attach Mobile Assembly (T) to the Tie Fabric Accessory Basket (A) to the Mobile Arm (K) by lining up the top of four (4) Rocker Legs (D).
  • Page 10 Parts Needed: Parts Needed: 02503 - Support 00073 - Canopy (x1) Tube (x1) Bassinet Base Assembly - continued Bassinet Basket Assembly - continued Snap Button Figure 1 Insert the two ends of the Canopy (S) through the openings in the Bassinet Fabric and into the connectors on the Figure 2 Insert Support Tube (E) into Rocker Legs...
  • Page 11 Parts Needed: Parts Needed: 00095 00560 - Mattress - Sheet 02503 - Support (x1) Tube (x1) (x1) Bassinet Basket Assembly - continued Bassinet Base Assembly - continued Insert Support Tube (E) into Rocker Legs (D). Push in on the snap button. Then slide the Support Tube down until the snap button locks into place.
  • Page 12 00078 - Screwdriver Parts Needed: Parts Needed: 00077 - Rocker Leg Screw (x4) 00135 - Bassinet Frame Bassinet Basket Assembly - continued (x1) 00079 - Wrench 00130 - Lock Nuts (x4) HARDWARE SHOWN AT ACTUAL SIZE Bassinet Basket Frame Assembly Snap Mattress Support...
  • Page 13 Parts Needed: Parts Needed: 00083 - Bassinet 00131 - Mattress Fabric Skirt Support (x1) (x1) Bassinet Basket Assembly - continued Bassinet Basket Frame Assembly - continued Battery Compartment Snap Figure 1 Note: Unfasten 10 snaps around the Bassinet Fabric Skirt (L) (see Figure 1).
  • Page 14 Parts Needed: Parts Needed: 00131 - Mattress 00078 - Screwdriver 01630 - Mobile 00078 - Screwdriver 00079 Support - Wrench (x1) (x1) *screws included 00080 - Lock Nuts 00139 - Mattress (x2) Support Screw (x2) Bassinet Basket Assembly - continued HARDWARE SHOWN AT ACTUAL SIZE Bassinet Basket Frame Assembly - continued...
