IDS X-Series X-SMS V2 Quick User Manual

X-SMS V2 Quick User Guide
THANK YOU FOR CHOOSING IDS TO PROTECT YOU
Thank you for purchasing an IDS X-SMS V2 module. IDS X-SMS V2 offers powerful,
versatile and highly configurable reporting and control capabilities, which will keep
you, informed and in control of your X-Series alarm system when away from your
premises.
NOTE: The X-SMS V2 module works only with IDS X-Series panels above a certain
version. Your X-Series alarm panel is a sophisticated professional-grade intrusion
product designed to protect lives and property, and can only be installed and
maintained by a professional IDS-certified installer. The Installer Manual included in
this box does not cover all aspects of installation; these are available only to
installers via our sales offices.
NOTE: Please read the entire Quick User Guide before attempting to use the X-SMS
V2 device!
NOTE: Throughout this manual, the default user code 1234 is used. Commands will
only be accepted by the alarm panel if preceded by a valid user code, programmed
into the alarm panel by your installer.
FEATURES OF THE IDS X-SMS V2 DEVICE

Take full remote control of your X-Series alarm panel
o
Arm / disarm
o
Bypass / un-bypass zones
o Home automation via PGM's

Keep in touch with your premises
o
Receive customised reports on panel status and events
o
Check current panel status
o Check recent activity by retrieving event logs

Enhance the functionality of your X-Series alarm panel:
o
Using names in reporting and commands
o
Update your panel's time and date via the mobile network

Manage your X-SMS V2 device remotely
o Lock X-SMS V2 in event of lost phone
o
Check and top up SIM airtime balance
o
Add, manage and remove X-SMS V2 users
COMMAND FORMAT
Commands are not case sensitive and all follow the same format:
[code] space [command] space [extended command] space [data]
Code – Valid alarm user code stored in the alarm panel
Command – A string that identifies the function that you are wanting to access in
the alarm panel.
Extended Command – Any supplementary information the function requires. (Not
always required will depend on the function being used.)
Data - Any extra information the extended command requires.
NOTE: The cell networks limit the number of characters to 160.
Arm / Disarm
The X-Series panel's 8 partitions may be armed in multiple profiles. Arming requires
a valid user code. These are programmed by your installer.
Valid command examples:
Desired action Code Command
Away arm all partitions 1234 Arm
Away arm P1 & P3 1234 Arm
Stay arm P2 in stay profile 3 1234 Arm
Stay arm P1 & P4 in stay profile 1234 Arm
1
Disarm all partitions 1234 Disarm
Disarm P2 1234 Disarm
Disarm P5 & P6 1234 Arm
NOTE: Stay profiles can be changed by sending a new stay arm command if armed in
stay mode already. Away armed partitions must be disarmed before being stay
armed.
Bypass / un-bypass zones
The "Bypass" command will be sent by you to bypass specific zones, and vice versa
for "unbypass". You must specify which zones to bypass in the data field. Zones may
be referred to by their number or, where applicable, by their name.
Valid command examples:
Desired Action
Bypass zone 1
Bypass zone 3,4,8,10
Bypass named zone "Passage"
Bypass named zone "Lounge" &
"Kitchen"
Unbypass Zone 5
Unbypass "Kitchen"
Home automation via PGM's
Programmable outputs (PGM's) on your X-Series alarm panel may be used to control
electrical devices such as lights, gate and garage door motors, pumps, geysers,
irrigation systems etc. The PGM command controls the programmable outputs
Note: Installations controlling electrical devices often requires a certified electrician.
PGM outputs can only supply 80mA of current.
PGM's can be triggered in several ways as below – consult your installer for further
support.

On – Turns the PGM on by putting 12V DC onto the output

Off – Turns the PGM off by removing the 12V DC

PulseH – Puts 12V DC onto the output for 2 seconds

PulseL – Removes 12V DC from the output for 2 seconds
Desired Action
Turn PGM 1 on
Turn PGM 3, 4 & 5 off
Pulse PGM 2 Low
Pulse PGM 3 High
Receive customised reports on panel status and events
The "report" command is sent to select what reports you want to receive on that
phone number. Each phone number can choose how they want to receive the
messages or turn off messages.
There are four types of SMSes:
Raw – A Contact ID string will be sent to the phone number
Full – All enabled events are reported
Reduced – Only the following will be reported: Arm/Disarm, Zone violations, Panics,
Medical, Fire, AC Fail/Restore, Battery Low/Restore, Zone tamper/restore.
Raw – Contact ID string/ readable format
Minimal – Only the following will be reported: Keypad panic, Medical & Fire, Panic
or Duress, AC Fail/Restorals, zone violations and Low Battery/restorals,
Zone tamper
Valid extended commands: "Type"
Desired Action
Turn on partial reporting
Ext. Cmd Data
Turn on global reporting
All
P1, P3 NOTE: Only a "Master Phone Number" can allocate partitions to a phone number.
S3 P2 Check current panel status
S1 P1, P4
Current arm status, zone status, and PGM status can be checked.
Arm Status
All
Desired Action
P2
Retrieve the status of all
P5, P6
partitions
Retrieve the status of P1
Code Command Ext. Cmd Data
1234 Bypass 1
1234 Bypass 3,4,8,10
1234 Bypass Passage
1234 Bypass Lounge,
Kitchen
1234 Unbypass 5
1234 Unbypass Kitchen
Code Command Ext. Cmd Data
1234 PGM On 1
1234 PGM Off 3,4,5
1234 PGM PulseL 2
1234 PGM PulseH 3
Code Command Ext. Cmd Data
1234 Report Type Reduced Phone number/
Name
1234 Report Type Full Phone number/Name
Code Command Ext. Cmd Data
1234 Arm Status All
1234 Arm Status P1
X-SMS 700-485-01E
Retrieve the status of P3 & P6 1234 Arm
Zone Status
Desired Action Code Command
Retrieve the status of zones in 1234 Zone
partition 1
Retrieve the status of zones in 1234 Zone
partition 1 & 3
PGM Status
Desired Action Code Command
Get PGM 8's status 1234 PGM
Get PGM Gate's status 1234 PGM
Bypass Status
Desired Action Code Command
Retrieve the status of zones in 1234 Zone
partition 1
Retrieve the status of zones in 1234 Zone
partition 1 & 3
Check recent activity by retrieving event logs
The "Event" command is sent by you to retrieve a selectable number of events from
the Alarm event log.
Desired Action Code Command
Retrieving 5 Events 1234 Event
NOTE: SMS text is limited by the networks to 160 characters and retrieving event
logs that exceed 160 characters will amount to a number of SMSes being sent.
SMS Threshold
By default the number of SMSes sent per day per phone number is 20.
The "threshold" extended command is sent by the phone number that is requesting
the change to increase or decrease the number of SMSes.
Desired Action Code Command Ext. Cmd
Increase the reporting 1234 Report Threshold
threshold to 50 SMSes
Decrease the reporting 1234 Report Threshold
threshold to 14
Using names in reporting and commands
The X-SMS V2 device itself, and all partitions, zones, and PGM's can be named.
These names are used by default in all reports, and can be used in commands in
place of the default zone / partition / PGM numbers.
Desired Action Code Command
Name PGM 5 Lights 1234 PGM
Name the X-SMS V2 device 1234 Site
"Home"
Name partition 1 "Main 1234 Partition
House"
Name partition 2 as "Granny 1234 Partition
Flat" & partition 3 as "Garage"
Name zone 1 as "Kitchen" 1234 Zone
Name zone 2 "Lounge" & 1234 Zone
zone 5 "Patio"
NOTES
 The X-Series alarm system does not use site, partition or PGM names, these names
cannot be added via the keypad.
 If a zone is named via SMS it will over write the zone name on the system
 If a space is inserted before or after the name then the space becomes part of the
zone name.
 Names are case sensitive
Status P3, P6
Ext. Comm Data
Status P1
Status P1, P3
Ext. Comm Data
Status 8
Status Gate
Ext. Cmd Data
Status P1
Status P1, P3
Ext. Cmd Data
Panel 5
Data
50 Phone
Number/Name
14 Phone
Number/Name
Ext. Cmd Data
Name 5:Lights
Name Home
Name 1:Main
House
Name 2:Granny
Flat,
3:Garage
Name 1:Kitchen
Name 2:Lounge,
5:Patio
