Standalone Operation ......................................... 5 Outputs ............................................5 Inputs ............................................5 Phone Numbers .......................................... 5 Operation ............................................6 Defaulting the SMS Duo module ....................................6 Messages ............................................. 6 Add .............................................. 6 Reporting Options ........................................6 Delete ............................................7 Naming ............................................. 7 Naming the Site ........................................... - Page 4 SMS Duo Manual 700-558-01D...
-
Page 5: Features
Can operate as a standalone unit Function The SMS Duo unit has been designed to work with the IDS805 alarm panel as a virtual keypad or as a standalone system with 2 inputs and 2 outputs. IDS805 Integration The SMS Duo connects to the IDS805 keypad bus as a second keypad and supports the following functionality: ... -
Page 6: Operation
Operation Defaulting the SMS Duo module To default the IDS SMS module: Power the unit down Press and hold the default button down Power up the unit Keep holding down the default button, until the ‘GSM Status LED’ comes on. -
Page 7: Delete
Zone Status Note: Zones on the SMS Duo interface board are reported as zones 9 & 10 and must have 3k3 resistors as end of line supervision. Normally open connections the 3k3 resistor must be in parallel Normally closed connections must have the 3k3 resistor in series Alarm Commands The “Arm”... -
Page 8: Zones Bypassing
Interface Board LED Panel Comms LED (See Fig 1 to 3) Slow flash – IDS805 not detected on power up and SMS Duo in Stand Alone Mode On – IDS805 detected and in IDS805 Mode Off – IDS805 disconnected (Only shows if an IDS805 was connected and then disconnected.) To engage standalone mode power down then up. -
Page 9: Diagrams
Card Connector Holder Pin 1 I/O Module Comms LED Serial Network Comms LED Communication Connector Network Status Heart Beat LED Default Button Figure 2: IDS SMS Duo and IDS805 Connection Xsms Panel Comms LED Interface IDS805 SMS Duo Manual 700-558-01D... - Page 10 Figure 3: IDS SMS Duo Standalone Connection Diagram Xsms Power Supply Interface Technical Data: Input Voltage: 12V DC Current: 5µA (Sleep) 8mA (Transmit) Physical Size (mm): 92 x 37 x 17 Operating Temperature: -10ºC, +50ºC SMS Duo Manual 700-558-01D...
- Page 11 SMS Duo Manual 700-558-01D...
- Page 12 SMS Duo Manual 700-558-01D...
