SETUP, PARTS & MAINTENANCE
MANUAL JZT1250 PWR UNIT
Power Unit Model:
742105-POWER UNIT-JZT1250
( Operation & Safety Manual: 4124226 )
For Cutterdecks:
754804-CUTTERDECK JZT1250 48 COLLECT
( Parts Manual: 4124227 )
WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
4124225 REV A
