Description
The EU-C-8r is intended to be used with the EU-L-8e controller.
It should be installed in particular heating zones. It sends current
temperature readings to the EU-L-8e controller which uses the
data to control the thermostatic valves (opening them when the
temperature is too low and closing them when the pre-set room
temperature has been reached).
Colour versions: white and black.
Technical data
Power supply
Room temperature adjustment range
Measurement error
Operation frequency
The pictures and diagrams are for illustration purposes only.
The manufacturer reserves the right to introduce some hanges.
Hereby, we declare under our sole responsibility that EU-C-8r manufactured by TECH, head-quartered in Wieprz Biała Droga 31, 34-122
Wieprz, is compliant with Directive 2014/53/EU of the European parliament and of the Council of 16 April 2014 on the harmonisation of
the laws of the Member States relating to the making available on the market of radio equipment, Directive 2009/125/EC establishing
a framework for the setting of ecodesign requirements for energy-related products as well as the regulation by the MINISTRY OF
ENTREPRENEURSHIP AND TECHNOLOGY of 24 June 2019 amending the regulation concerning the essential requirements as regards the
restriction of the use of certain hazardous substances in electrical and electronic equipment, implementing provisions of Directive (EU)
2017/2102 of the European Parliament and of the Council of 15 November 2017 amending Directive 2011/65/EU on the restriction of the
use of certain hazardous substances in electrical and electronic equipment (OJ L 305, 21.11.2017, p. 8).
For compliance assessment, harmonized standards were used:
PN-EN IEC 60730-2-9 :2019-06 par.3.1a Safety of use
ETSI EN 301 489-1 V2.1.1 (2017-02) par.3.1 b Electromagnetic compatibility
ETSI EN 301 489-3 V2.1.1 (2017-03) par.3.1 b Electromagnetic compatibility
ETSI EN 300 220-2 V3.1.1 (2017-02) par.3.2 Effective and coherent use of radio spectrum
ETSI EN 300 220-1 V3.1.1 (2017-02) par.3.2 Effective and coherent use of radio spectrum
Wieprz, 22.07.2021
Communication
button
batteries 2xAAA 1,5V
50C÷350C
± 0,50C
868MHz
EU Declaration of conformity
How to register a EU-C-8r
sensor in a given zone
Each sensor should be registered in a particular zone. In order
to do it, in the EU-L-8e menu select Zone/Registration/Sensor.
After selecting Registration, press the communication button on
the selected temperature sensor EU-C-8r.
If the registration attempt has been successful, the EU-L-8e
screen will display a message to confirm.
NOTE
Only one room sensor may be assigned to each zone.
Bear in mind the following rules:
-
the
maximum
sensor
may
be
- once registered, the sensor cannot be unregistered, but
only switched off in the submenu of a given zone (OFF);
- if the user attempts to assign a sensor to the zone to which
another sensor has already been assigned, the first sensor
becomes unregistered and it is replaced by the second one;
- if the user attempts to assign a sensor which has already
been assigned to a different zone, the sensor is unregistered
from
the
first
zone
For each temperature sensor assigned to a zone the user
may define the pre-set temperature and a weekly schedule.
It
is
possible
to
edit
controller
menu
(Main
website
emodul.eu.
(using
We are committed to protecting the environment. Manufacturing
electronic devices imposes an obligation of providing for
environmentally safe disposal of used electronic components and
devices. Hence, we have been entered into a register kept by
the Inspection For Environmental Protection. The crossed-out bin
symbol on a product means that the product may not be disposed
of to household waste containers. Recycling of wastes helps to
protect the environment. The user is obliged to transfer their used
equipment to a collection point where all electric and electronic
components will be recycled.
of
one
assigned
to
each
and
registered
in
the
these
settings
both
menu
/
Sensors)
and
EU-505
or
WiFi
RS
temperature
zone;
new
one.
in
the
via
the
module).
