Introduction. . . . . . . . . . . . . . . . . . 2
Precautions Microwave Energy. . . . . . . . . .3
Important Safety Instructions . . . . . . . . 4
Operation . . . . . . . . . . . . . . . . . . 9
Maintenance . . . . . . . . . . . . . .
Frigidaire.com USA 1-800-374-4432
Air Fry Oven &
use
Microwave
17
care
&
. . . . . . . . . . . . . . . . 22
8
.
.
.
.
.
.
18 - 20
A06823442 (November 2022)
Advertisement
Related Manuals for Frigidaire PMOS1980AF
Summary of Contents for Frigidaire PMOS1980AF
-
Page 1: Table Of Contents
Operation ....9 Maintenance ....A06823442 (November 2022) Frigidaire.com USA 1-800-374-4432... -
Page 2: Introduction
INTRODUCTION family Welcome to our Thank you for bringing Frigidaire into your home! We see your purchase as the beginning of a long relationship together. This manual is your resource for the use and care of your product. Please read it before using your appliance. -
Page 3: Precautions Microwave Energy
PRECAUTIONS MICROWAVE ENERGY PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY Do not operate the oven if it is damaged. It is Do not attempt to operate this oven particularly important that the oven door close with the door open since open door operation can properly and that there is no damage to the: result in harmful exposure to microwave energy. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this appliance. This manual contains important safety symbols and instructions. Please pay at-tention to these symbols and follow all instructions given. Do not attempt to install or operate your appliance until you have read the safety precautions in this manual. - Page 5 IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances basic safety • To reduce the risk of fire in the oven cavity: precautions should be followed, including the - Do not overcook food. Carefully attend appliance following: when paper, plastic, or other combustible materials are placed inside the oven to facilitate WARNING cooking.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS Materials you can use in microwave oven Follow manufacturer instructions. The bottom of browning dish must be at Browning dish least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Microwave-safe only. Follow manufacturer's instructions. Do not use cracked Dinnerware or chipped dishes.
-
Page 8: Names Of Oven Parts And Accessories
NAMES OF OVEN PARTS AND ACCESSORIES Round Wire Rack Wire Rack Air Fry Tray Air Fry Pan Glass Turntable Turntable Ring Assembly NOTE NOTE CAUTION The Air Fry Pan and Air Fry Tray are designed The Round Wire Rack can be used for Convection for Air Fry cooking only and should not be used cooking and Microwave Cooking functions. -
Page 9: Operation
OPERATION VENT FAN • Before operating your new appliance make sure you read and understand this Use and Care Touch: Display Shows: Guide completely. • The clock can be disabled when the microwave is first plugged in and the CANCEL key is selected. To re-enable the clock follow clock instructions. - Page 10 OPERATION Air Fry The Air Fry feature works best when using the Air NOTE NOTE NOTE NOTE Fry Pan and Air Fry Tray with packaged and convenience foods and can be programmed for Preheat the Air Fry Pan with the legs extended temperatures between 100°F and 425°F using and place on the glass turntable.
- Page 11 OPERATION Convection Cooking Broil-High Suppose you want Broil-High for 10 minutes. • For Best Results... Touch: Display Shows: Always use the round wire rack when convection cooking. Reduce package/recipe temperature 25°F for baked goods. The round wire rack is required CONVECT COOK for good air circulation and even browning.
- Page 12 OPERATION Using the +10 SEC /+ 30 SEC key Touch M ELT/ This feature will let you quickly start or add 10 or Food Amount SOFTEN 30 seconds. 1 or 2 sticks Melt Butter Touch the +10 SEC /+30 SEC pad to:+10 SEC / +30 SEC Melt Chocolate 2/4/8 oz...
- Page 13 OPERATION SENSOR COOK SENSOR REHEAT Suppose you want to cook a frozen dinner. • Suppose you want to reheat Pizza. • Touch: Display Shows: Touch: Display Shows: 1. SENSOR 1. SENSOR COOK REHEAT SENSOR 2. SENSOR REHEAT COOK SENSOR 3. SENSOR REHEAT COOK 4.
- Page 14 OPERATION USING ONE TOUCH START MULTI-STAGE COOKING For best results, some recipes call for different Touch 1 - 9 for 1 - 9 minutes microwave cooking. The power levels during a cook cycle. You can program cooking will start 2 seconds after your selection. your microwave for two power level stages during •...
- Page 15 OPERATION SETTING THE TIMER MICROWAVE AT LOWER POWER LEVEL • Your microwave oven can be used as a kitchen Your Over the Range Microwave Oven can be timer. You can set up to 99:99. The kitchen timer programmed for 99 minutes 99 seconds (99 :99). can be used while the microwave oven is running.
- Page 16 OPERATION USER SETTING SETTING FILTER VOLUME Touch: Display Shows: Suppose you want to set the volume for "off". • Touch: Display Shows: FILTER The display will scroll. When you see the FILTER desired setting touch Start. (after 3 seconds) FILTER The display will scroll.
-
Page 17: Maintenance
MAINTENANCE Troubleshooting Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY • Electrical cord for oven is not plugged in. •... -
Page 18: Cleaning And Care
CLEANING AND CARE Disconnect the power cord or leave the door open to deactivate the oven during cleaning. Disconnect the power cord before replacing filters and lights. EXTERIOR WAVEGUIDE COVER The outside surface is precoated steel and The wave guide cover is located on the right side in plastic. - Page 19 CLEANING AND CARE Disconnect the power cord or leave the door open to deactivate the oven during cleaning. Disconnect the power cord before replacing filters and lights. Charcoal filter replacement ? ? ? ? 5. Slide the top of the new charcoal filter into Charcoal filter part number FRPAMRAF the top area of the filter cavity.
- Page 20 CLEANING AND CARE WARNING Disconnect the power cord before cleaning or leave the door open to deactivate the oven during cleaning. CLEANING THE GREASE FILTER 2. Soak the grease filter in hot water using a mild detergent. Rinse well and shake to dry or wash The oven ventilation grease filters should be grease filter in dishwasher.
- Page 21 SERVICE CALL CHECK Please check the following before calling for service: Place one cup of water in a glass measuring cup in the microwave oven and close the door securely. Operate the microwave oven for one minute at HIGH 100%. A Does the microwave oven light come on? YES ____ NO ____...
-
Page 22: Warranty
Obligations for service and parts under this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described or illustrated are subject to change without notice. Canada 1.800.265.8352 1-800-374-4432 Electrolux Canada Corp. Frigidaire 5855 Terry Fox Way 10200 David Taylor Drive Mississauga, Ontario, Canada Charlotte, NC 28262 L5V 3E4... - Page 23 Our home is your home. Visit us if you need help with any of these things: owner support accessories service registration (See your registration card for more information.) Frigidaire.com 1-800-374-4432 Frigidaire.ca 1-800-265-8352...
