Frigidaire PLMVZ169HC - 1.6 cu. Ft. Microwave Oven Use & Care Manual

Over the range microwave oven
Hide thumbs


Microwave Oven

Visit the Frigidaire Web Site at:
Part Names .................................
Before Operating .......................
Manual Operation ......................
Operating Instructions .............. 9-17
Cleaning and Care ..................... 18-19
Specifi cations ............................ 20
Service Call Check .................... 20
Warranty ..................................... 21



  Related Manuals for Frigidaire PLMVZ169HC - 1.6 cu. Ft. Microwave Oven

  Summary of Contents for Frigidaire PLMVZ169HC - 1.6 cu. Ft. Microwave Oven

  • Page 1: Table Of Contents

    Before Operating ....... Manual Operation ...... Operating Instructions ....9-17 Cleaning and Care ..... 18-19 Specifi cations ......20 Service Call Check ....20 Warranty ........21 Visit the Frigidaire Web Site at: READ AND SAVE THESE INSTRUCTIONS P/N316495001 TINSEB150WRRZ-EL82...
  • Page 2: Welcome & Congratulation

    If you do need service, you can relax knowing help is only a phone call away. A list of toll-free customer service numbers is included in the back of this manual. Or call Frigidaire Customer Services at 1-800-944-9044, 24 hours a day, 7 days a week.
  • Page 3: Save These Instructions

    IMPORTANT SAFETY INSTRUCTIONS This symbol will help alert you to situations that may cause serious bodily harm, death or property damage. This symbol will help alert you to situations that may cause bodily injury or property damage. READ ALL INFORMATION BEFORE USING To reduce the risk of fi...
  • Page 4: Grounding Instructions

    IMPORTANT SAFETY INSTRUCTIONS UNPACKING AND EXAMINING YOUR MICROWAVE OVEN Open the bottom of the carton, bend the carton fl aps back and tilt the microwave oven over to rest on plastic foam pad. Lift carton off microwave oven and remove all packing materials, Installation Instructions, Wall Template, Top Template, Charcoal Filter, Turntable and Turntable Support.
  • Page 5: About Your Microwave Oven

    IMPORTANT SAFETY INSTRUCTIONS ABOUT YOUR MICROWAVE OVEN ABOUT FOODS This Use and Care Manual is valuable: read it carefully and always • Do not pop popcorn in your microwave oven unless in a special save it for reference. microwave popcorn accessory or unless you use popcorn labeled for use in microwave ovens.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS ABOUT UTENSILS AND COVERINGS cooked to safe temperatures. Electrolux is not responsible for any damage to the microwave oven when accessories are used. It is not necessary to buy all new cookware. Many pieces already in your kitchen can be used successfully in your new microwave oven.
  • Page 7: Part Names

    PART NAMES FRONT VIEW The 7-digit Interactive Display spells out operating steps and shows cooking hints. When HELP is lighted in the display, touch the Help pad to read a specifi c hint which may assist you. 9-11 BOTTOM VIEW (Front of microwave oven) 11-14 (Rear of microwave oven)
  • Page 8: Before Operating

    BEFORE OPERATING • Before operating your new microwave oven make sure you read • If the electrical power supply to your microwave oven should and understand this Use and Care manual completely. be interrupted, the display will inter-mittently show WELCOME PRESS CLEAR AND PRESS CLOCK after the power is •...
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS Special Features SENSOR COOKING in the SENSOR COOKING CHART for these foods. 1. Casserole lid. Electrolux’s Sensor is a semi-conductor device that detects the vapor (moisture and humidity) emitted from the food as it heats. The 2. Plastic wrap: Use plastic wrap recommended for microwave sensor adjusts the cooking times and power level for various foods cooking.
  • Page 10: Other Sensor Cooking Settings

    OPERATING INSTRUCTIONS Special Features OTHER SENSOR COOKING SETTINGS • Suppose you want to cook fresh broccoli. 1. Touch Fresh Veggie pad once for soft vegetables. SENSOR COOKING will automatically compute the microwave power and cooking time for foods shown in the chart below. You When sensor detects the vapor emitted from the food, remainder don’t need to enter the weight or quantity of the food.
  • Page 11: Beverage Chart

    OPERATING INSTRUCTIONS Special Features SENSOR COOK CHART (CONT.) FOOD PROCEDURE AMOUNT Poultry Boneless .5 - 2.0 lb Use boneless breast of chicken or turkey. Cover with vented plastic wrap. Touch Poultry pad once. When microwave oven stops, rearrange. Re-cover and touch START pad. After cooking, let stand, covered, 3-5 minutes.
  • Page 12: Special Features

    OPERATING INSTRUCTIONS Special Features BREAKFAST ITEMS CHART It is not necessary to enter AMOUNT. FOOD AMOUNT PROCEDURE 1. Scrambled 1 - 9 eggs For each egg, use 1 teaspoon of butter or margarine and 1 tablespoon of milk. Place butter or margarine in eggs dish, measuring cup or casserole large enough for the egg to expand.
  • Page 13 OPERATING INSTRUCTIONS Special Features Dinner Items 2. Touch Dinner Items pad once more to select ground beef. 3. Touch START pad. Dinner Items will cook any of the dinners listed in the chart by simply following the directions in the lnteractive Display. There are NOTE: 2 recipes in each section.
  • Page 14 OPERATING INSTRUCTIONS Special Features 3. BEEF OR PORK DINNER Sweet and Sour Pork with Rice Beef with Broccoli and Rice Place in a 3 quart casserole: Place in a 3 quart casserole: cup rice cup white rice cups pineapple juice tablespoons Teriyaki sauce cup apricot/peach sauce, sweet and sour sauce or tablespoon Hoisin sauce...
  • Page 15: Speed Defrost

    OPERATING INSTRUCTIONS Special Features food over and separate into pieces. DEFROST 4. Touch START pad. Speed Defrost After defrost cycle ends, let stand for 3-5 minutes. Speed Defrost rapidly defrosts specifi c foods and weights found in NOTE: the SPEED DEFROST CHART below. 1.
  • Page 16: Other Convenient Features

    OPERATING INSTRUCTIONS Other Convenient Features HELP MEMORY COOK Help provides 4 features that make using your microwave oven easy To set Memory Cook because specifi c instructions are provided in the interactive display. Memory Cook allows you to set 1 set of cooking instructions in 1.
  • Page 17: Operating Instructions

    OPERATING INSTRUCTIONS Other Convenient Features DEMONSTRATION MODE TIMER To demonstrate, touch Clock, the number 0 and touch START and • Suppose you want to time a 3 minute long distance phone call. hold for 3 seconds. DEMO ON will appear in the display. Cooking 1.
  • Page 18: Cleaning And Care

    CLEANING AND CARE EXTERIOR ODOR REMOVAL The outside surface is precoated steel and plastic. Clean the Occasionally, a cooking odor may remain in the microwave oven. outside with mild soap and water; rinse and dry with a soft cloth. Do To remove, combine 1 cup water, grated peel and juice of 1 lemon not use any type of household or abrasive cleaner.
  • Page 19: Cleaning And Care

    CLEANING AND CARE CHARCOAL FILTER WORK LIGHT AND NIGHT LIGHT Charcoal Filter, which was enclosed with your microwave oven, is 1. To replace light bulbs, fi rst disconnect power to the microwave used for nonvented, recirculated installation. The fi lter should be oven at the circuit breaker panel or by unplugging.
  • Page 20: Specifi Cations

    SPECIFICATIONS CGLMV169, GLMV169, CPLMZ169, PLMVZ169 AC Line Voltage: UL Rating: Single phase 120V, 60Hz, AC only CUL Rating: Single phase 120V, 60Hz, AC only AC Power Required: UL Rating: 1640W 14.0 amps. CUL Rating: 1500W 13.0 amps. Output Power*: 1000W Frequency: 2450 MHz (Class B/Group2)** Outside Dimensions (including handle):...
  • Page 21: Warranty

    MAJOR APPLIANCE WARRANTY INFORMATION Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
