Page 2
- All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 3
We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit.
Installing the Ceiling Bracket You have two options for installation. Pick which one works best for your location. Remove any existing bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. Hunter Pro Tip:...
1886 Installing the Blades: Blade Screw Washers Turn the motor assembly upside down and place it in one of the holes in the packaging. Secure each blade to a blade iron as shown using the blade nuts, found in hardware bag, and the blade assembly screws, found in the IMPORTANT hardware bag.
Page 7
1886 Installing the Cage Hunter Pro Tip: 2 of 8 Alignment and installation of Cage Arm the cage panels is easier with Assembly two people Screw Turn the motor assembly right side up and place it in one of the holes in the Align the screw holes of the packaging.
Page 8
Follow these steps to get your fan wired quickly and safely. Follow the route below that best matches your wall switch setup. If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualifi ed electrician. Hunter Pro Tip: You are going to need these:...
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Note: Fan style may vary. Installing the Bulbs Install a bulb into each of the sockets.
1886 Preparing the Remote The remote control is To close the battery already paired for use. For compartment, secure your convenience, a remote the battery door to the transmitter assembly with function card is packed in the small Phillips head screw. with your remote.
“How do I properly install multiple remote-controlled fans?” for information on how to correct this issue. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching. Cleaning products may damage the finishes.
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,...
