- Page 1 SILENT EC2/TC2 Quick Start Guide Made in Germany...
- Page 3 Die Abluft muss mit dem optionalen Abluftschlauch (A) direkt aus einem Unterschranksystem heraus geführt werden, wenn bestehende Abluftöffnungen nicht den folgenden Abbildungen (B, C) entsprechen. The exhaust air must be allowed to escape directly from the cupboard by means of the optional- ly available exhaust air duct (A) if the existing opening vents do not correspond to the following pictures (B, C).
- Page 5 min. 250 x 120 mm min. 10 x 5 inch...
- Page 7 Selbstdiagnose durchführen Activate self-diagnosis Effectuer un autodiagnostic Eseguire l‘autodiagnosi Ejecutar autodiagnóstico MENU Signalton (Buzzer) EIN Signalton (Buzzer) AUS Signal sound ON Signal sound OFF Signal acoustique ON Signal acoustique OFF Segnalazione acustica ON Segnalazione acustica OFF Señal acústica CONECTADA Señal acústica DESCONECTADA MENU Zeitintervall für Vollanzeige der Staubschublade Time interval for “Full”...
- Page 8 Einschaltschwelle für Automatikbetrieb Switch-on threshold for automatic operation Seuil de démarrage pour le mode automatique Soglia di attivazione per modo operativo Automatico Umbral de conexión para el modo automático Stand-By MENU ~3 sec. MENU 3 - 5 sec. Nachlaufzeit der Saugturbine After-run time of the suction turbine Durée de post-fonctionnement de la turbine d’aspiration Ritardo di spegnimento della turbina di aspirazione...
- Page 9 The manufacturer shall not be liable for damages caused by improper use. Only spare parts and accessories supplied or authorized by Renfert GmbH may be used with this prod- uct. If other spare parts or accessories are used, this could have a detrimental effect on the safety of the device, increase the risk of serious injury and lead to damage to the environment or the device itself.
- Page 10 If the dust extractor is employed to extract hazardous materials, appropriate personal protective See Fig. 1 (on inside cover) SILENT EC2 / TC2 Device socket A Control panel 8B Device socket B...
-
Page 11: Initial Operation
The suction unit is a standing device which must not be operated in a horizontal position. A: External ventilation duct (see accessories at www.renfert.com). C: Remove the back side of the cabinet, the distance from the back side of the cabinet to the wall min. -
Page 12: Operation
Operation Switching On The suction unit is switched on and off via the on / off switch (3). After activation: Stand-by In the stand-by mode the display is dark. Leave stand-by mode: • Press any button. • Switch on any electrical appliance connected to the extractor. Select vacuum channel Start / stop suction turbine and open / close corresponding pinch valve valve: •... - Page 13 Start the self-diagnosis manually. This is performed once. After reaching a set time interval, a request appears to empty the dust drawer. You can select between 5 times. Time interval / hrs Factory setting The switch-on threshold, when a connected electrical device opens the suction channel, can be individu- ally set for each suction channel.
-
Page 14: Cleaning & Maintenance
This is detected by the suction system and indicated by “FILt” in the display. Spare Parts in the internet at www.renfert.com/p918. Enter the following item number: EC2: 29370000, TC2: 29360000. The components excluded from the warranty (such as consumables or parts subject to wear and tear) are marked on the spare part list.
