300 A Current Sensor Kit for D1h/D3h/D5h/D6h Drives
Installation Guide
1 EMC shield
2 M8 flange nut
3 M5x16 countersunk screw
4 Terminal plate
5 R/S/T terminal label
6 M10x30 machine screw
7 M10 hex nut
8 Mains terminal block
9 M5x12 screw
10 M5x16 thread-forming screw
11 U/V/W terminal label
12 Motor terminal block
13 Power terminal mounting plate (IP21/IP54)
14 Mixing fan
15 Mixing fan housing
3.2 Installing the IGBT Output Busbars
To install the new IGBT output busbars, use the following steps.
Procedure
1.
Install the 2 new IGBT output busbars:
- a. Position the 3 new IGBT output busbars in the drive.
The new IGBT output busbars have PEM studs at the bottom rather than holes for fasteners.
- b. Fasten 6 screws (T30), 2 at the top of each IGBT output busbar.
c.
- Fasten 3 thread-forming screws (T25), 1 at the top of each IGBT output busbar.
2. Install the new hex busbar support bracket:
a.
- Position the bracket over the 3 IGBT output busbars.
- b. Fasten 3 M5 nuts (8 mm) to secure the bracket.
3.
Install the gate drive card:
- a. Fasten 6 thread-forming screws (T20) in the edges of the card.
b.
- Reconnect all cables to the gate drive card connectors.
4. Install the DC bus rails:
a.
- Fasten 2 screws (T30) in the top end of the DC bus rails, 1 per bus rail.
- b. Fasten 2 nuts (10 mm) in the lower end of the DC bus rails, 1 per bus rail.
5.
Install the power card mounting plate:
- a. Secure 4 screws (T20) in the corners of the mounting plate.
b.
- Fasten 1 screw (T25) at the top center of the mounting plate.
- c. Reconnect all cables to the power card, and route the cables through the cable clips on the mounting plate.
6.
Install the control card mounting plate.
- a. Reconnect the ribbon cable connecting the control card and power card, and position the control card mounting
plate in the drive.
- b. Secure 4 screws (T20) in the corners of the control card mounting plate.
c.
- Reconnect the customer control wiring.
10 | Danfoss A/S © 2022.11
16 Insulator sleeve (U motor busbar)
17 Motor busbar (U)
18 Motor busbar (V)
19 Motor busbar (W)
20 IGBT output busbars
21 Hex busbar support bracket
22
M6 nut
23 M6x24 screw
24 Hex busbar
25 Nomex® tube
26 Current sensor
27 M4x10 thread-forming screw
28 Wire harness (current sensor cables)
29 M5x11 thread-forming screws (spare fasteners)
Not shown:
Power terminal mounting plate (IP20/Chassis)
AN275538690239en-000101 / 130R0721
Reassembly
