Rowlinson Garden Products Softwood Adirondack Companion Seat Assembly Instructions

Before assembly

• We recommend that time is taken to read
the instructions before starting assembly,
then follow the easy step by step guide.
The instruction sheet is only a guide to the
assembly. Certain items may not be shown
to scale.
• Check all components prior to assembly
• This product should be assembled by no less
than two people
• Drill all components where indicated
x 2
Drill
Recommended tools for assembly
• Power drill/screwdriver
• Crosshead screwdriver drill bit
• 3mm drill bit
• 13mm spanner
Biocidal Products Regulation EU 528/2012
Wolmanit CX treated wood is a treated article
®
that incorporates biocidal products: copper
hydroxide carbonate/II/ and boric acid. They
protect wood against fungal decay /rot/ and
insect attack.
Keep away from food, drink and animal feeding
stuffs. Avoid breathing dust when cutting
treated wood.
No.

Components

1 Seat
2 Inner front leg
3 Outer front leg
4 Back support
5 Rear arm support
6 Rear brace
7 Seat back
8 Lower table
9 Upper table
10 Left outer arm
11 Right outer arm
12 Seat facia
No.

Fixing Kit

13 60mm bolt
14 Washer
15 Nut
16 70mm screw
17 60mm screw
18 50mm screw
19 40mm screw
20 25mm screw
21 L-bracket
Softwood Adirondack
Companion Seat
Assembly Instructions
Qty.
2
2
2
4
2
2
2
10
1
1
1
1
2
Qty.
12
12
12
4
8
16
8
2
8
2
9
8
12
3
English SS392B
4
11
5
6
7
1
