Before assembly
•
We recommend that time is taken to read the
instructions before starting assembly, then
follow the easy step by step guide.
The instruction sheet is only a guide to
the assembly. Certain items may not be
shown to scale.
•
Check all components prior to assembly
•
This product should be assembled by no
less than 2 people.
•
Never attempt to erect the assembly in
high winds.
•
Drill components where indicated.
x 2
Drill
Oriental Pagoda
Assembly Instructions
Base dimensions
2490mm
2187mm
English SS136A
Advertisement
Table of Contents
Related Manuals for Rowlinson Garden Products Oriental Pagoda PERGODA2HD
Summary of Contents for Rowlinson Garden Products Oriental Pagoda PERGODA2HD
- Page 1 English SS136A Oriental Pagoda Assembly Instructions Before assembly Base dimensions • We recommend that time is taken to read the 2490mm instructions before starting assembly, then follow the easy step by step guide. The instruction sheet is only a guide to the assembly.
- Page 2 Components list No. Components Qty. Square centre base Rectangular bases Floor bearers with metal brackets Bearer separators Floor panels Hexagonal centre piece Uprights Floor edge panels Large fences Medium fences Small fences Hand rails Long top frames Short top frames Triangular corner supports Left arch piece Right arch piece...
- Page 3 Rectangular bases Lay out the floor bearers on the bases as shown. Centre of floor bearers resting on squarefloor base. Position floor panels but do not screw down. Add floor bearer separators. Hexagonal floor centre Uprights are located into the metal brackets. Secure uprights in place with 4 x 50mm screws.
- Page 4 Sit the large fence on the floor between the uprights and secure with 6 x 70mm screws. It may help to drill pilot holes in the end frames of all the fence. Shows all large fences in place. Position a handrail on top of each fence. Secure hand rails by screwing through fence into handrail using 3 x 40mm screws.
- Page 5 Using 2 x 40mm screws, secure a corner support in each corner. Drill 2 holes in each of the triangular corner supports. Drill 2 holes in each arch piece. Note that there is a left and right angled arch piece. Attach arches using 2 x 40mm screws per arch.
- Page 6 View from inside building. Secure back of roof with 1 x 40mm screw. Secure in place at each end with 2 x 50mm screws. Attach roof cover strip using 3 x 40mm screws. Underneath view of roof coverstrip attachment. Use wide shank 50mm screws.
- Page 7 Secure small top frames to the top long roof bearers, using 4 x 70mm screws. Shows top frames in position. Short end Long end to to upright. roof bearer. Drill a hole in each end of the 6 roof supports. Note the orientation. Secure each roof support with 2 x 50mm screws.
- Page 8 L-brackets Secure top roof bearers to top frame using 2 L-brackets and 8 x 40mm screws per bearer. Position top fences as shown and secure using 4 x 50mm screws. See Photo 18. Secure roof panels to the top roof rafters using 4 x 50mm screws per panel. Drill 4 holes in the 6 small triangular roof panels.
