Model No. NTL89522C.1
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
REGISTER YOUR
PRODUCT
To register your product and
activate your warranty today,
go to iconservice.ca.
MEMBER CARE
Call toll-free 1-888-936-4266
Mon.–Fri. 7:30 a.m.–4:30 p.m. ET
(excluding holidays)
or email us at
service.ca@iFIT.com
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S25i and is the answer not in the manual?

Questions and answers

Related Manuals for NordicTrack S25i

Summary of Contents for NordicTrack S25i

  • Page 1 Model No. NTL89522C.1 Serial No. USER'S MANUAL Write the serial number in the space above for reference. Serial Number Decal REGISTER YOUR PRODUCT To register your product and activate your warranty today, go to iconservice.ca. MEMBER CARE Call toll-free 1-888-936-4266 Mon.–Fri.

  • Page 2: Table Of Contents

    NORDICTRACK and IFIT are registered trademarks of iFIT Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google LLC. The Bluetooth word ®...

  • Page 3: Important Precautions

    6. Use the treadmill only as described in this purchase a surge suppressor, see your local manual. NORDICTRACK dealer, call the telephone number on the front cover of this manual, or 7. The treadmill is intended for home use only.
  • Page 4 19. Read, understand, and test the emergency 26. When folding or moving the treadmill, make stop procedure before using the treadmill (see sure that the storage latch is holding the HOW TO TURN ON THE POWER on page 20). frame securely in the storage position. Do Always wear the clip while using the treadmill.

  • Page 6: Before You Begin

    S25I manual. To help us assist you, note the product model ® treadmill. The S25I treadmill provides an impressive number and serial number before contacting us. The selection of features designed to make your workouts model number and the location of the serial number at home more effective and enjoyable.

  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 8: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 7. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you finish all assembly steps.
  • Page 9 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (94). Next, identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94).
  • Page 10 4. Hold the Right Upright (90) against the Base (94). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) and a Wheel (25) with two 3/8" x 2 3/8" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8"...
  • Page 11 6. Identify the left handrail assembly (E). Attach the left handrail assembly to the Left Upright (89) with two 5/16" x 2 1/2" Screws (28) and two 5/16" Star Washers (11); do not fully tighten the Screws yet. Then, remove and discard the indicated screw (F).
  • Page 12 8. Tighten four #8 x 3/4" Screws (2) into the left and right handrail assemblies (E, G) and into the Left and Right Uprights (89, 90). 9. Set the Console Base (64) facedown on a soft surface to avoid scratching the Console Base. If there are ties (H) securing the Crossbar (93) to the Console Base, remove the ties.
  • Page 13 10. Identify the Right and Left Trays (27, 36). Attach the Trays (27, 36) to the Console Base (64) with eight #8 x 1/2" Screws (10); do not overtighten the Screws. Then, reattach the Console Frame (18) with the six #8 x 3/4" Screws (2) and the two Console Clamps (92) that you removed in step 9;...
  • Page 14 12. With the help of a second person, hold the con- sole assembly (J) near the Handrails (86) (only one side is shown). Connect the ground wire (K) from the console assembly (J) to the Console Ground Wire (58) on the Crossbar (93). Next, insert the Upright Wire (81) through the two indicated looped ties (L) on the console assembly (J).
  • Page 15 15. Orient the Upright Crossbar (98) as shown. Carefully slide the Upright Crossbar (98) between the Left and Right Uprights (89, 90). Attach the Upright Crossbar (98) with the four 5/16" x 3/4" Screws (4) that you removed in step 5; start all four Screws, and then tighten them.
  • Page 16 18. Remove the 5/16" Nut (34) and the 5/16" x 1 3/4" Bolt (6) from the bracket on the Base (94). Next, orient the Storage Latch (53) as shown. Attach the lower end of the Storage Latch (53) to the bracket on the Base (94) with the 5/16"...
  • Page 17 20. Firmly tighten the four 3/8" x 2 3/8" Screws (7) and the two 3/8" x 1 1/4" Screws (63). Next, tighten the two 3/8" x 1 3/4" Screws (62); the Wheels (25) must turn freely. Next, set the Left Inner Base Cover (99) onto the lower end of the Left Upright (89).

  • Page 18: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD capable of carrying 15 or more amps. To avoid overloading the circuit, do not plug other electrical Use a Surge Suppressor devices, except for low-power devices such as cell phone chargers, into the surge suppressor or into Your treadmill, like other electronic equipment, can be an outlet on the same circuit.
  • Page 19 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can also listen to your favorite workout music or audio books with the console’s sound system while you IMPORTANT: To activate your console and begin exercise. using its exclusive features, see assembly step 21 on page 17.
  • Page 20 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 21 4. Follow your progress with the display. To manually advance the scan cycle, press the Multi-Scan button repeatedly. The display can show the following workout To turn off the scan mode, press the Next Display information: button; the scan indicator and the word SCAN will Calories (CALS)—The approximate number of turn off.
  • Page 22 HOW TO USE AN IFIT WORKOUT 4. Select an iFIT workout. The console offers access to a large and varied library In the iFIT app, touch the buttons at the bottom of of iFIT workouts when you download the iFIT app to the screen to select either the main menu (Home your smart device and connect it to the console.
  • Page 23 HOW TO USE A WEARABLE HEART RATE To pause the workout, simply touch the screen or press the Stop button. To continue the workout, MONITOR press the play icon on the screen, or press the Start button. Whether your goal is to To end the workout, touch the screen to pause the burn fat or to workout, and then follow the prompts on the screen...
  • Page 24 THE SETTINGS MODE Total Time—The word TIME will appear in the display. The display will show the total number of 1. Select the settings mode. hours that the treadmill has been used. To select the settings mode, press the Settings button.

  • Page 25: Fcc Information

    HOW TO USE THE SOUND SYSTEM Next, press the play button on your personal audio player. To play music or audio books through the console Adjust the volume level using sound system while you exercise, plug a 3.5 mm male the volume buttons on the to 3.5 mm male audio cable (not included) into the console or the volume control...

  • Page 26: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 27: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal as shown (A), the switch has tripped. To reset the performance and to reduce wear. Inspect and power switch, wait for five minutes and then press properly tighten all parts each time the treadmill is the switch back in (B).
  • Page 28 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is off-center or slips when walked on a. Use only a surge suppressor that meets all of the a. If the walking belt is off-center, first remove the specifications described on page 18.

  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.

  • Page 30: Part List

    PART LIST Model No. NTL89522C.1 R0622A Key No. Qty. Description Key No. Qty. Description #8 x 5/8" Screw 9/32" Plastic Bushing #8 x 3/4" Screw 3/8" Plastic Bushing 5/16" x 2 1/4" Bolt Storage Latch 5/16" x 3/4" Screw Drive Motor #10 Star Washer Motor Belt 5/16"...
  • Page 31 Key No. Qty. Description Key No. Qty. Description 3/8" Washer French Warning Decal 5/16" x 1 3/4" Shoulder Bolt French Caution Decal Ground Screw – User’s Manual Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. NTL89522C.1 R0622A...
  • Page 33 EXPLODED DRAWING B Model No. NTL89522C.1 R0622A...
  • Page 34 EXPLODED DRAWING C Model No. NTL89522C.1 R0622A...
  • Page 35 EXPLODED DRAWING D Model No. NTL89522C.1 R0622A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
