- Page 1 52 cm Undermount Rangehood Model Number HV-C60RU INSTRUCTION MANUAL AFTER SALES SUPPORT (AU) 1300 886 649 (NZ) 0800 836 761...
-
Page 2: Table Of Contents
Contents 03 General Safety Instructions 06 Product Overview 07 Installation 14 Instructions 15 FAQs & Troubleshooting Guide 16 Other Useful Information After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support... -
Page 3: General Safety Instructions
General Safety Instructions (Cont.) IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. - Page 4 General Safety Instructions (Cont.) Electrical safety and usage conditions • Voltage and frequency: Before plugging the unit into an appropriate electrical outlet, make sure your outlet voltage and circuit frequency correspond to the voltage stated on the appliance rating label. •...
- Page 5 General Safety Instructions (Cont.) • CAUTION: No open flame cooking! Do not use an open flame for cooking underneath this rangehood; do not flambé under the rangehood. Open flames can damage the filters and present a fire hazard. • After use: Always switch off the rangehood after use and before cleaning. •...
-
Page 6: Product Overview
Product Overview Scope of delivery Rangehood Rangehood housing Lights Control panel Aluminium mesh filter Lock catch for aluminium filter Installation kit (individual parts are illustrated opposite) Documentation (not shown) Instruction manual Quick start guide Warranty card NOTE: Due to continued product improvement, images and illustrations in this manual may vary slightly from the product purchased. -
Page 7: Installation
Installation Unpacking • This product has been packaged to protect it against transportation damage. Unpack the appliance and remove all packaging materials from around the rangehood. Keep all packaging materials in a safe place. It will help prevent any damage if the product needs to be transported in the future, and you can use it to store the appliance. - Page 8 Installation (Cont.) Important installation advice WARNING! • All electrical work associated with the installation of this rangehood must be carried out by a licensed electrician. Please note the details of your licensed installer on page 19 of this manual. • This rangehood must be correctly installed by a suitably qualified person in strict accordance with all applicable rules and regulations and following the instructions in this manual.
- Page 9 Installation (Cont.) Installation height This rangehood is designed for top-mounted installation in a cabinet above a cooking appliance. Mounting instructions follow on pages 10-11. For optimum performance, the rangehood should be installed at a distance of 650-750 mm from the cooking surface (Fig. 3). (See Fig. 6, page 10, for detailed minimum distance requirements.) Fig.
- Page 10 Installation (Cont.) Mounting in a cabinet • This rangehood is designed for top-mounted installation in a cabinet above a cooking appliance. For optimum performance, the rangehood should be installed at a distance of 650-750 mm from the cooking surface (Fig. 6). The minimum required distance is 500 mm from an electric cooktop and 650 mm from a gas cooktop.
- Page 11 Installation (Cont.) • Unfasten the ST4*10 screw and remove the lid of the terminal box. • Disconnect the wires to the commands at the connectors. Repeat for the lights wires (Fig. 8). Fig. 8 • Fasten the hood to the cabinet (which must have a base with a depth of at least 18 mm) using the 12 (ST4*18) screws provided (Fig.
- Page 12 Installation (Cont.) Outdoor ducting mode This is the recommended extraction mode wherever possible for optimum performance. If you are able to install the exhaust duct to vent the air outside and operate your rangehood in outdoor ducting mode, proceed as follows: •...
- Page 13 Installation (Cont.) Recirculating mode This mode is the default setting. The rangehood must operate with charcoal filters installed, as it will vent the air back into the kitchen. The vent cover should be removed when using this mode. To ensure that the mode is correct, remove the aluminium mesh filters (Fig. 12) and check that the two levers are in the “RECIRCULATING”...
-
Page 14: Instructions
Instructions After the rangehood has been properly installed, insert the power plug into an appropriate electrical outlet and let the unit run for a few minutes prior to using it while cooking. Switching on/off Make sure the rangehood is properly connected to the power supply and the power is switched on at the outlet. -
Page 15: Faqs & Troubleshooting Guide
FAQs & Troubleshooting Guide If you experience problems with your rangehood, or it appears not to be operating correctly, check in the list below for answers to frequently asked questions. If none of the solutions offered help you solve your problem, please contact our after sales support centre for advice using the details at the bottom of the page. -
Page 16: Other Useful Information
Other Useful Information Cleaning and maintenance CAUTION! • Before cleaning the rangehood or carrying out maintenance, make sure the operation and light switches are set to the “ 0 ” position and the rangehood is disconnected from the power supply. •... - Page 17 Other Useful Information (Cont.) Charcoal filters If you are using the rangehood with the air recirculating back into the room, two charcoal filters must be installed before use. The charcoal filters absorb cooking odours and must be changed regularly. How often you need to change the filters depends on your usage. We recommend changing them every three to six months.
- Page 18 Other Useful Information (Cont.) Service, repair and spare parts If the appliance is damaged, do not attempt to repair it yourself. If it requires repair or service, please contact our after sales support centre to arrange for examination and repair. Our after sales support centre stocks a range of spare parts for the appliance.
- Page 19 Other Useful Information (Cont.) Responsible disposal Packaging materials are recyclable. Please dispose of them responsibly for recycling. At the end of its working life, do not throw this appliance out with your household waste. Electrical and electronic products contain substances that can have a detrimental effect on the environment and human health if disposed of inappropriately.
