For each output type, if the control signal is one of the inputs on the board, then there are up to six
output profiles that can be selected to determine how the output will react to a change at the input.
See the graphs below for a description of the profiles. See sections
the profile setpoints.
WARNING: If the control input is set to a Digital type, the output will simply jump
to the maximum setpoint when the input is ON, and jump to the minimum
setpoint when the output is OFF.
NOTE: For outputs that are controlled using a J1939 Command Message, only the
"Single Profile" responses will be used (single or dual slope)
I [mA]
Maximum
Breakpoint
Minimum
0
Error Minimum
Version 2.0.3
SINGLE PROFILE
Single Slope
Dual Slope
Either, with Error Checking
Either, no Error Checking
Minimum
Figure 1 – Analog Output Single Profile
Preliminary Documentation – May be Subject to Change
Breakpoint Minimum
4.2 and 4.5 for a description of
INPUT
Maximum
Error Maximum
8-36
