AXIOMATIC AX030200 User Manual page 2

VERSION HISTORY
Version Date
1.0.0 October 10, 2006
1.2.0 November 14, 2006
1.2.1 November 21, 2006
1.3.0 August 15, 2007
2.0.0 July 22, 2008
2.0.1 March 10, 2009
2.0.2 January 18, 2011
2.0.3 May 23, 2012
ACCRONYMS
ACK Positive Acknowledgement
AIN Analog Input
CFB Current Feedback
DM Diagnostic Message (from SAE J1939 standard)
DOUT Digital Output
DTC Diagnostic Trouble Code
EA Axiomatic Electronic Assistant
ECU Electronic Control Unit (from SAE J1939 standard)
FIN Frequency Input
NAK Negative Acknowledgement
PDU1 A format for messages that are to be sent to a destination address,
either specific or global
PDU2 A format used to send information that has been labeled using the Group Extension
technique, and does not contain a destination address.
PGN Parameter Group Number (from SAE J1939 standard)
PropB Message that uses a Proprietary B PGN
PWM Pulse Width Modulation
RPM Rotations per Minute
SPN Suspect Parameter Number (from SAE J1939 standard)
%dc Percent Duty Cycle (measured from a PWM input)
Version 2.0.3
Author
Anna Murray
Anna Murray
Anna Murray
Anna Murray
Anna Murray
Manraj S. Pannu
Amanda Wilkins
Amanda Wilkins
®
, p/n AX070502 (A Service Tool for Axiomatic ECUs)
Preliminary Documentation – May be Subject to Change
Modifications
Initial Draft
Added "Command Timeout" feature
Updated EA Screen Captures
UM version stepped to 1.2.0 to match other ECUs
Added ECU Address setpoint to miscellaneous group
Added low frequency support description (s/w
V4.1.0+) Added CAN termination resistor information
Removed Fault Setpoint references
Updated screen captures
Dimensional drawing updated.
®
trademark ( ) added to Electronic Assistant.
Added Technical Specifications
Updated Dimensional Drawing with current
dimensions
Registered
ii
