aspenhome
ah
ITEM NO: I349-451B-WST
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
FUNCTIONALITY INSTRUCTION
I349-451B
I349-451
Option 1 (Left)
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/2
ASSEMBLY INSTRUCTIONS
R
NS Backer Panel (for 451 NS)
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
HARDWARE LIST:
No.
A
B
C
D
E
F
COMPONENTS LIST:
No.
1
2
Beds
Beds
Option 2 (Right)
FOR INDOOR USE ONLY
MADE IN VIETNAM
Description
Bolt Ø1/4" x 2-1/8" (20)
Bolt Ø1/4" x 3/4" (20)
Lock Washer Ø1/4"
Flat Washer Ø1/4" x 3/4"
Allen Wrench 4mm
Metal Plate
Description
Backer Panel
Filler Block
Double Powered USB
Port for Charging
Sketch
Quantity
5 PCS
8 PCS
13 PCS
13 PCS
1 PC
2 PCS
Quantity
Sketch
1 PC
1 PC
I349-451B
I349-451
04-25-2022
Advertisement
Table of Contents
Related Manuals for aspenhome I349-451B-WST
Summary of Contents for aspenhome I349-451B-WST
- Page 1 ASSEMBLY INSTRUCTIONS ITEM NO: I349-451B-WST NS Backer Panel (for 451 NS) Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment. TOOLS REQUIRED (NOT PROVIDED)
- Page 2 ASSEMBLY INSTRUCTIONS ITEM NO: I349-451B-WST NS Backer Panel (for 451 NS) Backer Panel STEP 1: Attach the backer panel to nightstand by using 3 bolts(A), lock washers(C) and flat washers(D). Do not completely tighten bolts. FOR OPTION 1: Nightstand...
- Page 3 ASSEMBLY INSTRUCTIONS ITEM NO: I349-451-WST 1 Drawer Nightstand Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment. TOOLS REQUIRED (NOT PROVIDED)
