System Requirements; Specifications - Microtek ScanMaker i300 Install Manual

2 ScanMaker i300 Installing and Getting Started

System Requirements

• CD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 128MB RAM (256MB or more to use Digital ICE for Photo Prints)
PC and compatibles
• Pentium III PC or higher with USB or Hi-Speed USB (USB 2.0) port
• Microsoft Windows 98, 98SE, Me, 2000 or XP
Macintosh
• iMac or Mac G3/G4 with built-in USB port
• Mac OS 9.x or OS X

Specifications

Scanning Modes
Scanning Area
Resolution
Dimensions (L x W x H)
Weight
Voltage
Environment
Power Consumption
Power supply
(AC/DC adapter)
*Please note: Hi-Speed USB (USB 2.0) is a new standard which is backward compatible with USB
1.1. To achieve USB 2.0 throughput speeds, a USB 2.0 supported system is required.
Color, grayscale, and black-and-white in a single scanning
pass
True 48-bit color (approx. 281 billion colors)
16-bit grayscale (approx. 65,536 shades of gray)
8.5" x 11.7" (216 mm x 297 mm)
Optical: 4800 dpi x 2400 dpi
Interpolated: 65,535 dpi
19" x 11.5" x 2.3" (483 mm x 294 mm x 60 mm)
5.7 lbs (2.6 kg)
AC 100V to 120V (U.S. and Canada)
AC 200V to 240V (Europe and other parts)
50/60 Hz
Operating Temperature: 50° F to 104° F (10° C to 40° C )
Relative Humidity: 20% to 85%
15W max. (12V/1.25A)
Voltage Manufacturer
100V to 120V 1. DVE
2. HARD
200V to 240V 1. DVE
2. HARD
Model No.
DSA-0151A-12
HDAD15W101-123
DSA-0151A-12
HDAD15W101-124
