D. Using The Lightlid 35 Calibrator; A. Install The Lightlid 35 Calibrator.; B. Launch The Lightlid 35 Calibrator. - Microtek ScanMaker 3700 Install Manual

The LightLid 35 Calibrator is a program designed for calibrating your LightLid 35 to
ensure that it captures colors accurately when scanning slides and filmstrips. Calibration
is strongly recommended as a procedure for optimizing your scanned image.
On PC:
1. Place the Microtek CD into your CD-ROM drive. When the Installer screen
comes up, click Exit.
2. Double-click the My Computer icon on the desktop.
3. Locate your CD-ROM drive icon, and right-click the icon to bring up the
Context menu.
4. Choose Open, then double-click the LL35 Calibrator folder to open it.
5. Double-click the setup.exe icon to install the Calibrator. Follow the on-screen
instructions until installation is complete.
On Mac OS 9.x:
1. Place the Microtek CD into your CD-ROM drive. When the Microtek CD icon
appears on the desktop, double-click it.
2. Double-click "For OS 9.x" icon to open Installer screen.
3. Open the folder "LightLid 35 Calibrator", and double-click the Installer icon.
Follow the on-screen instructions until installation is complete. Once the
Calibrator is successfully installed, the "LightLid 35 Calibrator" icon appears on
the desktop.
On Mac OS X:
1. Place the Microtek CD into your CD-ROM drive. When the Microtek CD icon
appears on the desktop, double-click
2. Double-click "For OS X" icon to open the Installer screen.
3. Double-click "LightLid 35 Calibrator" to mount the LightLid 35 Calibrator on
the desktop.
4. Open the "LightLid 35 Calibrator" on the desktop, and double-click "LightLid
35 Calibrator.pkg".
5. Enter the administrator's name and password when the installation dialog box
comes up. Follow the on-screen instructions until installation is complete. Once
the Calibrator is successfully installed, the "LL35 Calibrator" icon appears on
the desktop.
Make sure that ScanWizard 5 is already installed on your system and that your scanner
is powered up. Launch the LightLid 35 Calibrator (Mac OS 9.x) or LL35 Calibrator
(Mac OS X) from your desktop. Alternatively, you
can launch the LightLid 35 Calibrator from the
LightLid 35 Calibrator folder (PC and Mac OS 9.x)
or from the Applications/ScanWizard 5 Folder
(Mac OS X).
Follow the on-screen instructions as shown in the
Calibrator window right (sample taken from
Windows version, which is identical to the
Macintosh except for the Title bar).
it.
