- Page 1 BUS BODY ELECTRONICS SC400-410 TÜRKEI Operating Instructions - Busdriver Rev. 23.11.2018 Id.No. DOK30404...
-
Page 2: Table Of Contents
BUS BODY ELECTRONICS Contents Contents List of Figures List of Tables Introduction Intended purpose Symbols used Description of the control panel 1.3.1 SC400 1.3.2 SC410 Activate/deactivate Standby 2.1.1 Standby 2.1.2 Activation 2.1.3 Deactivation Auto mode 2.2.1 Activation Turning air-conditioning compressor on/off 2.3.1... -
Page 3: List Of Figures
Figure 16 - SC410 error display ................14 List of Tables Table 1 - SC400/410 temperature difference and blower level in cooling mode ......7 Table 2 - SC410 temperature difference and blower level in heating mode ......8 Table 3 - SC410 Temperature Difference Compressor ............. 8 Table 4 - SC410 Temperatur Difference Water Valve + Electric Water Pump ...... -
Page 4: Introduction
1 Introduction 1.1 Intended purpose The SC400 and SC410 control elements including the SR400 and SR410 relays boards are systems intended to control the HVAC components (heating, ventilation, air-conditioning) in buses, for example for roof-top air-condition systems. They consist of a control element inte- grated into the dashboard (control device as an interface between human and machine) and an accessible relays board. -
Page 5: Description Of The Control Panel
BUS BODY ELECTRONICS 1.3 Description of the control panel The control elements of the SC400 and SC410 have largely the same components. These are named and their functions described in the following sections. 1.3.1 SC400 Figure 1 - SC400 control panel... -
Page 6: Sc410
BUS BODY ELECTRONICS 1.3.2 SC410 Figure 2 - SC410 control panel Designation Function 1. Display Display for current room temperature and for error codes 2. Status light Indicates whether a function is active (red sta- tus light = function active) 3. -
Page 7: Use
BUS BODY ELECTRONICS 2 Use 2.1 Activate/deactivate Standby 2.1.1 Standby If the motor (KL 61) is running, the system is in Standby mode. The status light for the On/Off button lights up red (Figure 3). 2.1.2 Activation Press button Figure 3 - SC410 Standby ➔... -
Page 8: Auto Mode
>1 K Level 2 → 3: T_Room – T_Desired >3 K Level 3 → 2: T_Room – T_Desired <2 K Level 2 → 1: T_Room – T_Desired <0 K Table 1 - SC400/410 temperature difference and blower level in cooling mode... -
Page 9: Turning Air-Conditioning Compressor On/Off
BUS BODY ELECTRONICS Different blower level than level 1 is only possible when T_duct >33 °C Gebläsestufe Temperaturdifferenz Level 1: T_Duct <35 K Stufe 1 → 2: T_Room – T_Desired >-1 K Stufe 2 → 3: T_Room – T_Desired >-3 K Stufe 3 →... -
Page 10: Activation
BUS BODY ELECTRONICS 2.3.2 Activation Press button when status light is off. ➔ Air-conditioning compressor is activated and turns on if the minimum run times are maintained (see following note). The cooling function then turns on again. Figure 7 - SC410 air-conditioning compressor/Auto mode activated Note The air-conditioning compressor must be deactivated for... -
Page 11: Setting Desired Room Temperature
BUS BODY ELECTRONICS 2.5 Setting desired room temperature Note The temperature can be set between 17 °C to 28 °C in 0.5 °C intervals. Press button ➔ Desired temperature + 0.5°C Press button ➔ Desired temperature – 0.5°C Figure 8 – SC410 changing the temperature Figure 9 - SC410 changing the temperature... -
Page 12: Setting Blower Level
BUS BODY ELECTRONICS 2.6 Setting blower level Note If the blower level is changed manually, Auto mode turns off. The desired value of the room temperature is main- tained. Press button ➔ Auto mode is deactivated Press button ➔ Pressing once: Blower goes up one level. ➔... -
Page 13: Switch Air-Conditioning/Recirculating Air
BUS BODY ELECTRONICS 2.7 Switch air-conditioning/recirculating air Press button in order to switch between air-condition- ing and recirculating air. ➔ If the status light above the air-conditioning/recirculating air button lights up, the air-conditioning/recirculating air function is active and the fresh air supply is deactivated (Figure 13). -
Page 14: Additional Component
BUS BODY ELECTRONICS 2.8 Additional component Press button, for additional component on / off ➔ LED illuminates when additional component is switched on, if an additional component is present (Figure 15). Figure 15 – SC410 additional component The button controls output 7, to which the additional compo- switched on nent is connected. -
Page 15: Errors
BUS BODY ELECTRONICS 2.9 Errors 2.9.1 Error display Note If an error is present, the display varies between the set desired temperature and error codes. The desired temperature will display for 5 seconds then Figure 16 - SC410 error display the series of errors occurring will display for 2 seconds each. -
Page 16: Table 5 - Error Code Overview
BUS BODY ELECTRONICS System type No basic or standard system Replace ECU recognized Room tempera- Short-circuit to positive Inspect wiring harness ture sensor Replace sensor Replace ECU Room tempera- Short-circuit to ground Inspect wiring harness ture sensor Replace sensor Replace ECU Environmental Short-circuit to positive Inspect wiring harness... - Page 17 Valeo Thermal Commercial Vehicles Germany GmbH Postfach 1371 – 82198 Gilching - Germany - Tel. +49 (0)8105 7721-0 - Fax 49 (0)8105 7721-889 www.valeo-thermalbus.com - service-valeobus@valeo.com...
