Transition Networks SwitchMaster MSB-E6/X2 User Manual

Switchmaster or switchmasterfl eight segment bridge
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
™ or
™
SwitchMaster
SwitchMasterFL
Eight Segment Bridge
(MSB-E6/X2 or MSB-EFL6/X2)
7341.D
For assistance in installing, using, or
maintaining the TRANSITION Networks
SwitchMaster™ Eight Segment Bridge,
contact TRANSITION Networks Technical
Support at:
(800) 260-1312
or contact your local distributor.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SwitchMaster MSB-E6/X2 and is the answer not in the manual?

Questions and answers

Related Manuals for Transition Networks SwitchMaster MSB-E6/X2

Summary of Contents for Transition Networks SwitchMaster MSB-E6/X2

  • Page 1 ™ or ™ SwitchMaster SwitchMasterFL Eight Segment Bridge (MSB-E6/X2 or MSB-EFL6/X2) 7341.D For assistance in installing, using, or maintaining the TRANSITION Networks SwitchMaster™ Eight Segment Bridge, contact TRANSITION Networks Technical Support at: (800) 260-1312 or contact your local distributor.
  • Page 2 CAUTION: CONNECTION TO THE PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in damage to the public telephone network. Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer Konformität.

  • Page 3: Table Of Contents

    Preface ........... . iii 1.
  • Page 4 5.1 SwitchMaster™ BridgeFault Isolation Table ....5–2 5.2 Recovery Procedures ........5–4 5.3 SwitchMaster™...

  • Page 5: Preface

    Preface This guide is intended for the system or network administrator responsible for installing, configuring, using, and maintaining a Transition Networks SwitchMaster™ Eight Segment Bridge. A working knowledge of local area network (LAN) operations, including familiarity with communications protocols used on interconnected LANs, is assumed. EIGHT SEGMENT BRIDGE...

  • Page 7: Introduction

    1. INTRODUCTION The SwitchMaster™ Eight Segment Bridge is a multi-segment Ethernet bridge that provides six RJ-45 ports (with one alternate AUI connector) with installation space for two additional X Slot multi-media connections. T R A N S I T I O N Reset Power The SwitchMasterFL™...

  • Page 8: About Bridges

    1.1 About Bridges A bridge is a network device that can be used to merge two or more Local Area Networks (LANs) into a single functional LAN or, alternatively, to separate a single LAN into two or more functional LANs. The bridge is used to merge two or more LANs into a single functional LAN for: •...
  • Page 9 Large, slow LAN Remote, unattached LAN EIGHT SEGMENT BRIDGE 1. INTRODUCTION Smaller, faster LAN #1 RIDGE Smaller, faster LAN #2 RIDGE Smaller, faster LAN #3 RIDGE Attached LAN...

  • Page 10: Store And Forward

    According to the IEEE 802.1d specification, bridges must: • Store and Forward • Learn Addresses • Age Addresses • Participate in “Spanning Tree” Store and Forward A data packet sent out on a LAN is received by the bridge, which stores the data packet exactly as received.
  • Page 11 Destination #1 EIGHT SEGMENT BRIDGE 1. INTRODUCTION Source #1 Bridge Packet #1 Packet #1 Destination #2 Source #2 Source #3 Destination #3...

  • Page 12: Learn Addresses

    Learn Addresses When a data packet is received by the bridge, the source identifier and LAN are copied from the packet header and stored in the address cache. Then, when later packets are received, the bridge compares the destination identifier of the received packet with cache addresses. If a match is found, the bridge “knows”...
  • Page 13 Destination #1 EIGHT SEGMENT BRIDGE 1. INTRODUCTION Source #1 Destination #2 Bridge Packet #1 Packet #1 Address Cache source 1 LAN 1 source 2 LAN 2 source 3 LAN 3 source 4 LAN 4 source 5 LAN 5 Destination #2 Source #2 Source #3...

  • Page 14: Age Addresses

    Age Addresses When a data source identifier is copied from a packet header into the address cache, the bridge compares the destination identifier of the received packet with cache addresses. If a match is found, the bridge “knows” the destination LAN and sends the data packet only on the known destination LAN.
  • Page 15 Destination #1 EIGHT SEGMENT BRIDGE 1. INTRODUCTION Source #1 Bridge Packet #1 Packet #1 Address Cache source 1 LAN 1 source 2 LAN 2 source 3 LAN 3 source 4 LAN 4 source 5 LAN 5 Destination #2 Source #2 Source #3...

  • Page 16: Participate In "Spanning Tree

    Participate In “Spanning Tree” The spanning tree algorithm is intended to prevent LAN failure caused by the unintended generation of infinite broadcast loops. Infinite Loops Since bridges forward data packets across all LANs except the LAN from which the data packet is received, and since bridges are transparent to all other bridges, when multiple bridges connect multiple LANs, infinite loops can be generated by situations such as the following: 1.
  • Page 17 Bridge #1 Packet #1 Address Cache source 1 LAN 1 source 1 LAN 2 source 1 LAN 1 LAN 2 source 1 The “Spanning Tree” Algorithm The “Spanning Tree” algorithm avoids the generation of infinite loops by dynamically defining one and only one direct logical path between any two bridged LANs.

  • Page 18: The Switchmaster™ Eight Segment Bridge

    1.2 The SwitchMaster™ Eight Segment Bridge The SwitchMaster™ Eight Segment Bridge provides six RJ-45 port connectors (with one alternate AUI connector), a DB9 serial port connector, LED status indicators, and a reset switch. Connectors Six (6) RJ-45 connectors, a DB9 serial port connector, and an AUI port connector are provided at the front of the SwitchMaster™...
  • Page 19 Indicators SWITCHMASTER™ POWER INDICATOR When the SwitchMaster Eight Segment Bridge is powered, the Power indicator is illuminated. T R A N S I T I O N Reset Power SWITCHMASTER™ STATUS INDICATORS When the SwitchMaster™ Eight Segment Bridge is functioning normally, the eight Status indicators cycle in a steady roll.
  • Page 20 SEGMENT 1 RJ-45 STATUS INDICATORS WhenSegment 1 is connected through the RJ-45 connector, the Segment 1 status LEDs indicate RJ-45 connection status. SEGMENT 2-SEGMENT 6 RJ-45 STATUS INDICATORS When Segment 2 through Segment 6 RJ-45 are connected, the Segment status LEDs indicate RJ-45 connection status. T R A N S I T I O N Power 1-14...

  • Page 21: Switchmasterfl Eight Segment Bridges

    1.3 The SwitchMasterFL™ Eight Segment Bridge The SwitchMasterFL™ Eight Segment Bridge provides six (6) pairs of fiber transmit (TX) and receive (RX) data connectors, a DB9 serial port connector, LED status indicators, and a reset switch. Connectors Six (6) sets of fiber (TX and RX) connectors and a DB9 serial port connector are provided at the front of the SwitchMasterFL™...
  • Page 22 Indicators SWITCHMASTER™ POWER INDICATOR When the SwitchMasterFL™ Eight Segment Bridge is powered, the Power indicator is illuminated. T R A N S I T I O N Power SWITCHMASTER™ STATUS INDICATORS When the SwitchMasterFL™ Eight Segment Bridge is functioning normally, the eight Status indicators cycle in a steady roll. T R A N S I T I O N Reset Power...

  • Page 23: Switchmaster™ Bridge X Slot Cards

    1.4 SwitchMaster™ Bridge X Slot Cards X Slot Cards allow the SwitchMaster™ Bridge to provide additional segments, including wide area network (WAN) connections. NOTE: X Slot cards can be installed in the field. Full Duplex Ethernet X Slot Card The Full Duplex Ethernet X Slot Card, which provides the functionality of a redundant Segment 1, is installed at either of the two SwitchMaster™...

  • Page 24: 100Baset X Slot Card

    100BaseT X Slot Card The 100BaseT Slot Card, which provides connection to 100BaseT media, is installed at either of the two SwitchMaster™ Bridge X Slot locations. T R A N S I T I O N Reset Power Connectors One (1) RJ-45 connector is provided at the front of the installed 100BaseT X Slot Card.

  • Page 25: Site Planning

    2. SITE PLANNING Site planning for the SwitchMaster Eight Segment Bridge requires consideration both of site conditions and of the Ethernet IEEE 802.3 standards to which the SwitchMaster Bridge conforms. 2.1 Site Considerations The site for the SwitchMaster Bridge must provide the following: •...

  • Page 27: Installation

    EIGHT SEGMENT BRIDGE Unpack the SwitchMaster™ Bridge Install in rack or on table Connect to network Connect to power. Part Number MSB-E6/X2 or MSB-E6/E2 3344, 3347, 3348, 3349, or 3523, (depending upon power configuration in country where installed) 7341 Part Number...

  • Page 28: Installing In Rack Or On Table

    Installing in Rack or on Table Depending upon site conditions, the SwitchMaster™ Bridge can be installed in a standard 19-inch rack or on an open shelf or table. Standard 19-Inch Rack Installation NOTE: SwitchMaster™ Bridges are shipped with attached brackets for standard 19-inch rack installation.

  • Page 29: Table-Top Installation

    Table-Top Installation NOTE: SwitchMaster™ Bridges are shipped with a separate, unattached set of adhesive-backed rubber feet for table-top installation. CAUTION: The rubber feet MUST BE INSTALLED on the SwitchMaster™ Bridge if a SwitchMaster™ Bridge is installed on a table-top or other flat surface.

  • Page 30: Connecting To Network

    Connecting to Network Network connections are made at: • RJ-45 connectors • AUI connectors • optional X Slot Card connectors Connecting to 10BaseT at RJ-45 Connectors CAUTION: The RJ-45 connectors on the SwitchMaster™ Bridge are NOT INTENDED FOR CONNECTION TO THE PUBLIC TELEPHONE NETWORK.
  • Page 31 Straight Through/Crossover Pin Specifications Straight through and crossover configurations are made at the RJ-45 connector. The two active pairs in a 10BaseT network are pins 1 & 2 and pins 3 & 6. Use only dedicated wire pairs (such as blue/white & white/blue, orange/white &...
  • Page 32 Connecting to Network through AUI The AUI is connected to a transceiver which is connected to the network. The AUI port (on Segment 1 and/or on the optional Full Duplex Ethernet X Slot card) is always enabled. NOTE: On the Segment 1 connection and also on the Full Duplex Ethernet X Slot Card, only one LAN port (EITHER the AUI port OR the RJ- 45) can be used.

  • Page 33: Connecting To Power

    Connecting to Power To connect the SwitchMaster™ Bridge to power: 1. At SwitchMaster™ Bridge back, locate the power receptacle and associated fuse. CAUTION: Fuse must be installed at correct setting for power source voltage before connecting to AC voltage. Failure to observe this caution could result in equipment damage.

  • Page 35: Operation

    4. OPERATION Operating the SwitchMaster™ Eight Segment Bridge may require: • • 4.1 Power On/Power Off The SwitchMaster™ Eight Segment Bridge is powered ON when the power cord is connected between the SwitchMaster™ Bridge and an AC outlet during installation. NOTE: When the SwitchMaster™...

  • Page 36: Monitoring Switchmaster™ Bridge Operation

    4.2 Monitoring SwitchMaster™ Bridge Operation SwitchMaster™ Eight Segment Bridge operation is monitored by observing Bridge Status and Segment Status LEDs on the SwitchMaster™ Bridge front panel. Monitoring Bridge Status LEDs during Operation SwitchMaster™ Bridge Status LEDs are located on the SwitchMaster™ Bridge front panel.
  • Page 37 Phase 0 Power On Diagnostic Tests At power on, the Status LEDs cycle through diagnostic test patterns as internal SwitchMaster™ Bridge software tests: Flash, serial port, dynamic RAM, static RAM, dual port memory, and each of the Ethernet ports. During each of the diagnostic tests, the four Bridge Status LEDs at the top of the Status LEDs cycle in a steady right to left pattern to indicate test progress.
  • Page 38 Phase 1 Software Loading SwitchMaster™ Bridge phase 1 operation loads configuration software. The default is loading configuration software from the SwitchMaster™ EEPROM. Optionally, during phase 1 operation, configuration software can be loaded from a network server using the bootp function. During power on, at some point in the reset, the top row of Status LEDs flashes continuously while the bottom row of Status LEDs are steadily illuminated, indicating that the SwitchMaster™...

  • Page 39: Monitoring Segment Status Leds

    Monitoring Segment Status LEDs SEGMENT 1 AUI STATUS INDICATORS WhenSegment 1 is connected through the AUI connector, the Segment 1 status LEDs indicate AUI network activity. T R A N S I T I O N Reset Power When a SwitchMaster™ AUI is actively connected to normal mode (half duplex) Ethernet, the Segment LEDs indicate the following AUI conditions: When a SwitchMaster™...
  • Page 40 SEGMENT 1 RJ-45 STATUS INDICATORS WhenSegment 1 is connected through the RJ-45 connector, the Segment 1 status LEDs indicate RJ-45 connection status. SEGMENT 2-SEGMENT 6 RJ-45 STATUS INDICATORS When Segment 2 through Segment 6 RJ-45 are connected, the Segment status LEDs indicate RJ-45 connection status. T R A N S I T I O N Power When a SwitchMaster™...
  • Page 41 Monitoring X Slot Card Status Indicators Full Duplex Ethernet The Full Duplex Ethernet X Slot Card Status indicators are the same as Segment 1 Status indicators. When a SwitchMaster™ AUI is actively connected to normal mode (half duplex) Ethernet, the Segment LEDs indicate the following AUI conditions: When a SwitchMaster™...
  • Page 42 Monitoring X Slot Card Status Indicators 100BaseTX Ethernet When a SwitchMaster™ 100BaseT X Slot card is installed at either of the two X Slot locations, the Segment LEDs indicate the following conditions: T R A N S I T I O N Reset Power (continued)

  • Page 43: Maintenance

    5. MAINTENANCE To assist in SwitchMaster™ Bridge maintenance, this section provides: • • • • NOTE: Recovery of a failed SwitchMaster™ Bridge may require the assistance of TRANSITION Networks Technical Support. EIGHT SEGMENT BRIDGE SwitchMaster™ Bridge Fault Isolation Table Directions for enabling SwitchMaster™ Bridge recovery by resetting the SwitchMaster™...

  • Page 44: Switchmaster™ Bridgefault Isolation Table

    5.1 SwitchMaster™ Bridge Fault Isolation Table Use Table 5-1 for troubleshooting the SwitchMaster™ Bridge. Table 5-1 presents a list of faults and probable causes, presented in the order of increasing probability, with suggested remedial action. To use Table 5-1, locate the problem in the FAULT column. In the PROBABLE CAUSE box next to the fault, find one or more probable cause(s) associated with the fault.
  • Page 45 FAULT Steady green LED illuminated in a Unit with no physical device present No console connection allowed by software. User cannot see rest of network Loud fan noise Table 5-1. Fault Isolation in the SwitchMaster™ Bridge The DB9 serial port on the SwitchMaster™ Bridge is a DTE device. If the DB9 serial port cable will be attached directly between two DTE devices, use a null modem cable.

  • Page 46: Recovery Procedures

    5.2 SwitchMaster™ Bridge Recovery Procedures Recovery procedures for the SwitchMaster™ Bridge include: • Resetting the SwitchMaster™ Bridge • Verifying and optionally modifying Bridge Port Settings Resetting the SwitchMaster™ Bridge At power on or reset, the Status LEDs cycle through diagnostic test patterns as internal SwitchMaster™...

  • Page 47: Replacement Procedures

    5.3 Replacement Procedures WARNING: SwitchMaster™ Units contain no user-serviceable parts. Except for the installation or replacement of X Slot Cards, DO NOT, UNDER ANY CIRCUMSTANCES, open and attempt to repair SwitchMaster™ equipment. Failure to observe this warning could result in electrical shock and personal injury. NOTE: Failure to observe the above warning will immediately void any warranty.

  • Page 48: Downloading Updated Software

    5.4 SwitchMaster™ Bridge Field Upgrades Downloading Updated Software SwitchMaster™ Bridge field upgrades include: • Software Upgrades To download updated software: • Connect SwitchMaster™ Bridge to PC with ASCII terminal • Bring up the SwitchMaster™ Bridge download software • Transfer TE/OS.bin files. Connecting to PC with ASCII Terminal NOTE: The DB9 serial port on the SwitchMaster™...
  • Page 49 Bringing Up the SwitchMaster™ Bridge Download Software To bring up the SwitchMaster™ Bridge download software: 1. Use a small screwdriver, bent paper clip, or other small device to reset the SwitchMaster™ Bridge by depressing the internal reset switch. Reset SwitchMaster T R A N S I T I O N n e t w o r k s Eight Segment Bridge...
  • Page 50 Transferring TE/OS.bin software To transfer the TE/OS.bin software. 1. Load the TRANSITION Networks software update disk into the ASCII terminal PC. 2. Using methods appropriate to the attached terminal, download the bootp.bin code from the TRANSITION Networks software update into the reserved SwitchMaster™...
  • Page 51 Installing X-Slot Card in SwitchMaster™ Unit WARNING: DISCONNECT POWER CORD from SwitchMaster™ Unit before installing the X-Slot card. Failure to observe this warning could result in personal injury or death from electrical shock. WARNING: AVOID CONTACT WITH POWER SUPPLY during X-Slot card installation.
  • Page 52 5-10 5. From SwitchMaster™ Unit inside front, remove knockout plate from SwitchMaster™ Unit by holding screwdriver against knockout plate and striking firmly until knockout plate falls onto the table or other flat surface and free of the SwitchMaster™ Unit.. Knockout Plate 6.
  • Page 53 7. Carefully align the X-Slot card mounting tabs with the internal X-Slot card mounting bracket slots. 8. Slide the X-Slot card mounting tabs into the internal X-Slot Card mounting bracket slots. Internal X-Slot Card Mounting Bracket Slots 9. Carefully press X-Slot card onto the two (2) 96-pin connectors on the SwitchMaster™...

  • Page 55: Appendix A. Technical Specifications

    Appendix A. Technical Specifications Network Standards Ethernet IEEE 802.3 10BaseT, 10Base2, 10BaseFL, and 10Base5 Cable Type 22, 24, or 26 AWG twisted shielded pair cable, level 3 or higher. Universal Power Supply Input Range: 85 to 265 VAC at 47 to 63 Hz. Rated at 40 watts maximum. AC Input: TE PN 3344...

  • Page 57: Appendix B. Cable Specifications

    Appendix B. Cable Specifications A. Null Modem Cable Specifications The table below shows the pin assignments for the DB9 cable. Function Carrier Detect Receive Data Transmit Data Data Terminal Ready Signal Ground Data Set Ready Request To Send Clear To Send Ring Indicator B.
  • Page 58 D. 10BaseT Cable Specifications The following describes the specifications when twisted pair is used. Either shielded or unshielded twisted pair can be used. The physical characteristics must meet or exceed those set forth by the IEEE 802.3 10BaseT specifications. Generally, Level 3 wire or bet- ter is recommended.

  • Page 59: Appendix C. Segment Distance

    Appendix C. Segment Distance The IEEE 802.3 CSMA/CD specification has defined standards which are differentiated by the oper- ating link, the type of signaling, the type of media and distances supported. The following chart highlights the characteristics of the major standards: 10BaseT 10Base2 Operating rate 10...

  • Page 61: Appendix D. Approved European Power Cord Set

    Appendix D. Approved European Power Cord Set Approval Organization Belgium:Comite Electrotechnique Beige (CEBEC) Verband Deutscher Elektrotechniker (VDE)e, V., Prufstelle Technique de l’Electricite (UTE) Institute del Marchio Qualita British Approvals Service For Electric Cables (BASEC-HAR) N.V. tot Keuring van Electro- technische Matarialien (KEMA) Svenska Elecktriska (SMEKO) Osterreichnischer Verband ful Electrotechnik (OVE)
  • Page 63 A. Five Year Warranty Transition Networks, Inc. (TN) warrants, for a period of five years, that TN products (with the exception of power supplies and fans that TN warrants for two years) will be free from defects in materials and workmanship, and will be in conformity with TN’s specifications. TN’s warranty on products manufactured by or assembled for TN in accordance with a customer’s specifications, is a five-year warranty that the goods conform to such specifications.
  • Page 64 The sole purpose of this remedy shall be provided the customer with the replacement or repair of non-conforming goods in the manner described in this Warranty statement. This exclusive remedy shall not be deemed to have failed of its essential purpose so long as TN is willing and able to repair or replace the defective item(s) or refund the purchase price.
