Installation Instructions
TOWER SOLAR BOLLARD/TABLE LAMP WITH SENSOR
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.
Warranty
• This luminaire is covered by a 3-year warranty valid for in-store replacement or refund only.
• The warranty period starts from the date of purchase. Please retain the proof of purchase.
• The warranty is for the luminaire only and does not include the rechargeable battery.
• Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
• Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the
warranty.
Installation Requirements
• Select a suitable location for installation:
−
This product is suitable for outdoor use only.
−
The mounting point must support 2 times the weight of the luminaire.
−
This luminaire is protected against water penetration to IP54 standards, which is splashing water from any
direction.
−
The solar panel must have access to direct sunlight to recharge the battery. Avoid any areas where there is
possible shading on top of the solar panel.
−
Depending on the luminance of the sun, the charging time required for the battery is approximately 5.5 hours.
−
See the Sensor Information section on the next page, for additional information about the sensor detection
range and sensor sensitivity, to select a suitable installation location.
• The luminaire must not be used if the protective shield or shade has been cracked or damaged. Replace the
protective shield or shade before using the luminaire.
• Lay out all the components on a smooth surface and make sure no components are missing before assembling.
If parts are missing, return the complete product to the place of purchase for inspection or replacement.
• Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
1 | P a g e
SKU# 229160, 229161
Rated Voltage 3.7V DC, 2W
v 1 . 0 ( 0 6 / 2 0 2 0 )
Advertisement
Table of Contents
Related Manuals for Lucci LEDlux 229160
Summary of Contents for Lucci LEDlux 229160
- Page 1 Installation Instructions TOWER SOLAR BOLLARD/TABLE LAMP WITH SENSOR SKU# 229160, 229161 Rated Voltage 3.7V DC, 2W Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.
- Page 2 Installation Instructions Sensor Information PIR (PASSIVE INFRA-RED) SENSOR: The luminaire has a PIR (Passive Infra-Red) sensing device which continuously scans the operating zone and immediately switches the luminaire on when it detects any movement in that area. Whenever movement is detected within the sensor range, the luminaire will switch on automatically to illuminate the area.
- Page 3 Installation Instructions Installation Directions Select the type of installation you require before assembly and installation: This luminaire can be installed as a PILLAR MOUNT or SPIKE MOUNT. Refer to the corresponding instructions and diagram for the different installation methods. PILLAR MOUNT (Refer to the diagram below) 1.
- Page 4 Installation Instructions SPIKE MOUNT (Refer to the diagram below) 1. Remove all packaging material from the product and be careful not to throw away accessories that may be hidden within the packaging material. If assembly is required, place the luminaire on a smooth non-scratch surface. 2.
- Page 5 Installation Instructions Battery Replacement This luminaire has a built-in rechargeable lithium battery. (ZNL18650E, 3.7VDC, 2200mAh) The battery has a limited life (1.5 – 2 years). After this time, the battery can be replaced following these steps: NOTE: During the battery replacement, do not scratch or damage the surface of the solar panel, as this will reduce its efficiency to recharge the battery.
- Page 6 There are no serviceable parts, do not attempt to dismantle or open the luminaire. • Dispose of exhausted batteries immediately and safely (so they cannot be retrieved by children). Contact your local council to dispose of the battery safely. Specifications SKU # 229160 229161 Rated Voltage 3.7V DC Rated Wattage 150 lumens, 2W, Warm White –...
