Installation Instructions
NOTE:
This fitting is 12V extra-low voltage and can be DIY.
This installation instruction applies to the 12V side of the fitting only.
When working with 240V, a licensed electrician is required.
Lucci wiring kit (SKU# 220826, 220827) and Lucci transformer (SKU# 220818, 220819, 220829) sold separately.
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before using the product. Please keep instructions for future reference.

Warranty

This light fitting is covered by a 3 year warranty. The warranty is from date of purchase, not the date of installation.
Please retain proof of purchase.
Warranty will be void if there is any damage due to improper usage or modification to the fitting.
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void
warranty.

Installation requirements

All wiring and installation of the light fitting must adhere to local and national wiring rules.
eg. AS/NZS 3000:2007/Amendment 2:2012 Electrical installations.
Do not exceed the maximum wattage rating.
This fitting is rated IP65. This must be maintained during installation.
Replace any cracked protective lamp shade to maintain IP rating when using this fitting.
Select a suitable location for installation:
-
This fitting is rated IP65 which is protected against jets of water.
-
The wiring kit is not suitable for underground installation without protection from water or damp conditions. It is
not designed to be immersed in water.
Take care not to pull any electrical wires during unpacking as this may damage the connection.
Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or replacement.
Check whether the fitting has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
Ensure power to the circuit you are working on has been switched OFF, before commencing any electrical work.

Installation directions

1.
Remove all packaging material from the product and be careful not to throw away accessories that may be hidden
within the packaging material.
2.
Turn OFF the power to Lucci transformer (sold separately). Fig.1
3.
Install the spike rod to the lamp body. Fig. 2
4.
Insert the spike rod into the ground. Fig. 3
Remove the cover from the connector on the Lucci wiring kit (SKU# 220826, 220827 – sold separately).Connect
5.
the fitting to the wiring kit. NOTE: The wiring kit is rated for Max. 80VA load only. Fig. 3
1 | P a g e
MARINE LED 12V SPIKE SPOT
SKU# 221052, 221055, 221058
Rated Voltage 12V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Marine LED 12V Spike Spot and is the answer not in the manual?

Questions and answers

Summary of Contents for Lucci LEDlux Marine LED 12V Spike Spot

  • Page 1 Installation Instructions MARINE LED 12V SPIKE SPOT SKU# 221052, 221055, 221058 Rated Voltage 12V NOTE: This fitting is 12V extra-low voltage and can be DIY. This installation instruction applies to the 12V side of the fitting only. When working with 240V, a licensed electrician is required.
  • Page 2 Installation Instructions Connect the Lucci wiring kit (SKU# 220826, 220827 – sold separately) to the Lucci transformer (SKU# 220818, 220819, 220829 – sold separately). NOTE: Do not exceed the load of the Lucci wiring kit and Lucci transformer. Ensure that the wires are secure and no bare wires are exposed. Ensure all wiring and the transformer used are appropriately rated and suitable for the location.
