REF 9748
1 Person
15 min
EASY
ID.
PIEZA / PART
1
2
3
4
5
6
7
HONDA CB1000R '18- /CB650R '19-
C A R E N A B R Í S / W I N D S H I E L D / W I N D S C H U T Z C H E I B E
N A K E D N E W G E N E R A T I O N S P O R T
DESCRIPCIÓN
Cúpula Sport
Soporte izquierdo
Soporte derecho
Silentblock M5
Arandela nylon M5x1
Tornillo allen M5x16 Ø11 ISO 7380
Tapón tornillo M5 ISO7380
www.puig.tv
www.puigusa.com
DESCRIPTION
Sport screen
Left support
Right support
M5 silentblock
M5x1 nylon washer
M5x16 Ø11 ISO7380 allen screw
M5 ISO7380 screw cap
Pg. 1/3
info@puig.tv
info@puigusa.com
TORX
T40
ALLEN
Nº 3
QTY.
REF.:
1
9748F/H/N/WM3
1
SOPOR-2P-5-9748
1
SOPOR-2P-5-9748
4
SILENBTM5-046/1
4
ARNV0000000245
4
TORNI-I7380-493
4
TAPON--------85
