OPERATOR'S MANUAL
KN121CGB D
Disc mower
Original instructions
KN121CGB D
- English - 11-2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMD702F and is the answer not in the manual?

Questions and answers

Related Manuals for KUHN GMD702F

Summary of Contents for KUHN GMD702F

  • Page 1 OPERATOR'S MANUAL KN121CGB D Disc mower Original instructions KN121CGB D - English - 11-2009...

  • Page 3: Dear Owner

    Designated use of the machine The GMD702F mower must only be used for the purpose for which it was manufactured: mowing on the ground of hay fields, grass silage fields and improved pastures for the purpose of harvesting fodder for feeding livestock.

  • Page 4: Table Of Contents

    Disc mower GMD702F $Contents  Dear Owner ........................1  Contents..........................2  Identification of the machine..................4 Front view............................4 Rear view............................4 Model identification plate ........................5 Optional equipment..........................5  Safety..........................6 Description of symbols used in this document................6 Safety instructions ...........................7 Location and description of safety decals on the machine ............15 Road safety equipment and recommendations................18...
  • Page 5 Disc mower GMD702F  Instructions for transport.................... 34 Putting the machine into transport position................34 Conformity with the road regulations ..................37  Instructions for work ....................38 Putting the machine into work position ..................38 Adjustments in working position....................40 Machine use............................

  • Page 6: Identification Of The Machine

    Disc mower GMD702F $Identification of the machine 1. Front view 2. Rear view Identification of the machine...

  • Page 7: Model Identification Plate

    Disc mower GMD702F 3. Model identification plate Please write below the type and serial number of the machine. This information is to be given to the Kuhn authorized dealer for any spare parts order or warranty claim. KUHN S.A. 67700 SAVERNE - FRANCE...

  • Page 8: Safety

    Disc mower GMD702F $Safety 1. Description of symbols used in this document This symbol indicates a potentially hazardous situation that if not avoided, could result in serious bodily injury. This symbol is used to identify special instructions or procedures which, if not followed strictly, could result in machinery damage.

  • Page 9: Safety Instructions

    Never let anyone operate the machine who is not trained to do so. Should you have any difficulties in understanding any parts of this manual, please contact your KUHN dealer.  Precautions to be taken before carrying out any operations on the machine...
  • Page 10 Disc mower GMD702F  Precautions to take before using the machine Do not wear loose clothing which could become caught up in moving parts. Wear the appropriate protective clothing for the work in hand (gloves, shoes, goggles, helmet, ear defenders, etc.).
  • Page 11 Disc mower GMD702F  Precautions when driving on public roads Dimensions Depending on the dimensions of the machine, contact the relevant authorities to ensure that it can be legally transported on public roads. If the machine is over the maximum legal size, follow the local regulations for special transportation of oversize equipment.
  • Page 12 Disc mower GMD702F  Precautions when coupling Before attaching the machine, make sure that it cannot accidentally start moving (chock the wheels) and that the parking stand is in the right position. The machine must only be attached to the hitch points provided for this purpose.
  • Page 13 Disc mower GMD702F  PTO shaft Use only PTO shafts supplied with the machine or recommended by the machine manufacturer. The protective shield of the tractor PTO stub, the PTO shaft guards and the protective shield of the machine input shaft must always be in place and in good condition.
  • Page 14 Disc mower GMD702F  Precautions during manoeuvres When moving the machine from the transport position to the working position and vice versa, make sure that nobody is within the machine pivoting area.  Remote controlled components Danger of crushing and shearing can exist when components are operated by hydraulic or pneumatic controls.
  • Page 15 For your own safety and for correct machine operation, only use original manufacturer parts. It is strongly recommended to have your machine checked by your Kuhn dealer after each season, especially tools and their attaching hardware.  Projection of stones and foreign objects For driver safety, always use a tractor equipped with a cab.
  • Page 16 Disc mower GMD702F The protection covers help reducing risks of projections. Therefore, make sure that all mower protection devices are in place and good condition prior to using the machine. Regularly check the condition of the protection covers. Immediatly replace any worn, damaged or missing cover.

  • Page 17: Location And Description Of Safety Decals On The Machine

    Disc mower GMD702F 3. Location and description of safety decals on the machine  Location of safety decals 599011001 59900300 599011001 59900300 Safety...
  • Page 18 Disc mower GMD702F  Description of safety decals Operating instructions (1) The operators' manual contains all the information necessary for using the machine safely. It is imperative to read and comply with all instructions. Working on the machine (2) Before...
  • Page 19 Disc mower GMD702F Rotating cutting tools (5) Keep away from the mower knives all the time the engine is running, the PTO drive engaged and the moving parts have not come to a complete stop. Cutting tools (6) The cutting tools and their attachment hardware meet safety and reliability criteria set by standards and by the manufacturer.

  • Page 20: Road Safety Equipment And Recommendations

    GMD702F 4. Road safety equipment and recommendations The road safety equipment is mounted in the factory or by your authorized Kuhn dealer according to current safety regulations. The front safety device comprises: - 2 signalling panels (1). - 2 white lights (2).

  • Page 21: Machine Specifications

    Disc mower GMD702F $Machine specifications 1. Description and glossary Main frame Mowing unit Parking stand Cutterbar Transport lock Side gearbox Central gearbox Parking stand operating lever Side guard 10 : Front guard 11 : Lift cylinder 12 : Suspension spring...

  • Page 22: Technical Specifications

    Disc mower GMD702F 2. Technical specifications GMD702F Front mounted with a quick release A frame coupler Attachment type category A 2 Number of discs Width in working position 2.80 m (9’2’’) Length in working position 1.72 m (5’7’’) Height in working position 1.33 m (4’4’’)

  • Page 23: Putting Into Service

    Disc mower GMD702F $Putting into service 1. Description of control elements The machine is supplied with an 18 mm box wrench (1) to carry out certain adjustment and maintenance tasks. 2. Coupling and uncoupling The machine adapts to tractors equipped with a front mounted 3-point lift linkage fitted with a quick release A frame coupler category ’’A’’...
  • Page 24 Disc mower GMD702F  Preparing the tractor The tractor PTO stub must rotate at a speed of 540 min or 1000 min (depending upon specification). 1000 The tractor must be equipped with: - 1 single acting valve with float position.
  • Page 25 Disc mower GMD702F Quick release "A" frame coupler - Attach the quick release "A" frame coupler to the tractor's front lift linkage using the hitch pins supplied with the machine (Part no. 56618200). - Attach check chains on hitch pins and secure using washers, roll pins and lynch pins.
  • Page 26 Disc mower GMD702F  Preparing the machine Central gearbox ( 1000 min The machine can be driven with a PTO stub rotating clockwise or counterclockwise. The two outer disks of the cutterbar must rotate inwards. If the outer disks of the cutterbar do not rotate inwards,...
  • Page 27 Disc mower GMD702F Central gearbox (540 min and 1000 min The machine can be driven with a PTO stub rotating clockwise or counterclockwise. The two outer disks of the cutterbar must rotate inwards. If the outer disks of the cutterbar do not rotate inwards,...
  • Page 28 Disc mower GMD702F • Connect pto shaft to the gearbox shaft according to 1000 the speed and direction of rotation of the tractor pto. 1000 The pto guard (1) must be fitted on the output used to couple the shaft and cover (2) on the non used output.
  • Page 29 Disc mower GMD702F "A" frame lock adjustment - Loosen the stop mounting screw (1). - Couple the machine to the tractor. - Rotate adjusting screw (3) until stop (2) contacts latch (4). - Check that latch is free to operate by pulling lever. If operation is difficult untighten adjusting screw 1/2 a turn.
  • Page 30 Disc mower GMD702F  Hydraulic connection - Connect the hydraulic hose to the single acting valve with float position. Before connecting hoses to the tractor hydraulics, ensure that tractor and machine circuits are not under pressure.  Electrical connection (optional equipment) Connect 7-pin plug to the tractor.
  • Page 31 Disc mower GMD702F  Primary PTO shaft Make sure that the PTO shaft is correctly adjusted, to avoid premature wear and tear. The tractor PTO stub must rotate at a speed of 540 min or 1000 min (depending upon specification).
  • Page 32 - Fit a new bolt (2) inside yoke. • Part no. 80060850 - Screw up and tighten the self-locking nut moderately. • Part no. 80200830 - Reinstall cover (1). To ensure that the torque limiter works properly, use only KUHN shear bolts. Putting into service...
  • Page 33 Disc mower GMD702F  Adjusting the machine Frame height and check chains. With the machine attached: - Place lever (1) in position (A), parking stands (2) disengaged. Position (A): Parking stands disengaged. Position (B): Parking stands engaged. - Lower the mowing unit using the machine lift cylinders.
  • Page 34 Disc mower GMD702F  Uncoupling the machine From the transport position: - Position transport lock lever in working position (1 on each machine side). - Lower the mowing unit using the machine lift cylinders. - Place lever (1) in position (B), parking stands (2) engaged.
  • Page 35 Disc mower GMD702F - Disconnect and store signalling equipment plug in its holder (1) (optional equipment). - Lower the tractor three-point linkage to rest the machine on the ground. - Disconnect and store hydraulic hose on machine. - Lower the tractor's front linkage and uncouple the "A"...

  • Page 36: Instructions For Transport

    Disc mower GMD702F $Instructions for transport Before placing the machine into transport position: Wait until the rotating parts have come to a complete stop. 1. Putting the machine into transport position From the working position: - Place lever (1) in position (A), parking stands (2) disengaged.
  • Page 37 Disc mower GMD702F - Unlock and lift front guard using 18 box spanner supplied with the machine. - Remove tensioner (1) (1 on each machine side). - Pivot side guards and lower/lock front guard. Instructions for transport...
  • Page 38 Disc mower GMD702F - Lift transport lock lever in transport position (1 on each machine side). Check that transport locks (1) are fully engaged: The frame and mowing unit must go down simultaneously when the tractor lift cylinders are operated The machine is in transport position.

  • Page 39: Conformity With The Road Regulations

    Disc mower GMD702F 2. Conformity with the road regulations Before driving the machine on public roads, ensure that the machine complies with current highway code regulations. Before driving onto a main road, employ a person to give the driver indications to manoeuvre safely: - When leaving the farm.

  • Page 40: Instructions For Work

    Disc mower GMD702F $Instructions for work 1. Putting the machine into work position From the transport position: - Lower the tractor's lift linkage to tension the check chains. - Position transport lock lever in working position (1 on each machine side).
  • Page 41 Disc mower GMD702F - Hook tensionsers (1) to suspension spring mounting brackets. - Make sure all the guards are in place. Immediately replace any worn or damaged guard. - Activate machine lift cylinders to rest the machine on the ground.

  • Page 42: Adjustments In Working Position

    Disc mower GMD702F 2. Adjustments in working position  Cutting height The desired cutting height is obtained directly by adjusting the top link length. The height can be adjusted between 30 and 80 mm (1.1’’ - 3.1’’) depending on the tractors.
  • Page 43 Disc mower GMD702F The maximum cutting height (L1 = 80 mm (3.1’’)) is obtained when the discs are parallel to the ground. The minimum cutting height must not be below (L2 = 30 mm (1.1’’)). Too low a cutting height can lead to: - Excessive disc and knife wear.
  • Page 44 Disc mower GMD702F  Reduced or increased ground pressure The mowing unit is suspended by means of floatation springs (1). In difficult working conditions, the suspension spring setting can be altered. - Place the machine in transport position. - Loosen counter nut (2).

  • Page 45: Machine Use

    Disc mower GMD702F 3. Machine use Before mowing and to reduce risks of projections, lower side guards and front hood. Fit rear cover tensioners to swath shield screws. Keep all persons and animals away from the machine danger zone. Never lean or step on the guards.
  • Page 46 Disc mower GMD702F  Machine safety In case an obstacle is struck: Before carrying out any maintenance or repairs on the machine, switch off the tractor engine, remove ignition key, wait until all moving parts have come to a standstill and apply park brake.

  • Page 47: Optional Equipment

    Disc mower GMD702F $Optional equipment 1. Quick release "A" frame coupler Kit no. 1276870 For tractors not equipped with a quick release "A" frame coupler ISO 11001. 2. 1 3/8’’-21 spline yoke Part no. 4603187 (Central gearbox 1000 min Part no.

  • Page 48: Central Gearbox 540 Min -1 And 1000 Min -1

    Disc mower GMD702F 3. Central gearbox 540 min 1000 min Kit no. 1036220 This equipment enables adapting the machine to tractors with a pto speed of 540 min or 1000 min Follow adjustment and maintenance instructions given in the present operator's manual.

  • Page 49: Raised Skid Shoes

    Disc mower GMD702F 5. Raised skid shoes Kit no. 1036250 Replace outer skids with 2 raised skids. This equipment enables obtaining a fixed cutting height of 55 mm (2.2’’) and easy machine uncoupling without having to touch the top link.

  • Page 50: Maintenance And Storage

    Disc mower GMD702F $Maintenance and storage Before carrying out any maintenance or repairs on the machine, switch off the tractor engine, remove ignition key, wait until all moving parts have come to a standstill and apply park brake. 1. Frequency chart...

  • Page 51: Lubrication

    Disc mower GMD702F 2. Lubrication Except for the secondary PTO shaft lubrication, the machine must be placed in transport position for all maintenance operations (knife replacement, lubrication, etc). Clean grease nipples before greasing. Lubricate with SHELL multi-purpose grease grade NLGI 2.
  • Page 52 Disc mower GMD702F  PTO shaft Primary PTO shaft - Every 8 hours: • U-joints (1). • transmission tube (2). • Guide rings (3). Secondary PTO shaft - Remove cover (1) to access greasers. - Every 250 hours: • U-joints (1).
  • Page 53 Disc mower GMD702F  Oil: - The moving parts and pivot points.  Cutterbar draining and refilling Before draining oil, operate the machine for a few minutes so that the oil warms up. The cutterbar is lubricated with 2 L (0.52 US gal) of extreme-pressure gear oil with viscosity grade SHELL SPIRAX A and SAE 80W90 grade API.
  • Page 54 Disc mower GMD702F  Lateral gearbox draining Before draining oil, operate the machine for a few minutes so that the oil warms up. The angle gearbox is lubricated with 0.7 L (0.18 US gal) of SHELL SPIRAX A extreme-pressure oil for mechanical transmissions with viscosity grade SAE 80W90 and API grade GL5.
  • Page 55 Disc mower GMD702F  Central gearbox draining Before draining oil, operate the machine for a few minutes so that the oil warms up. The main gearbox is lubricated with SHELL SPIRAX A extreme-pressure gear oil with viscosity grade SAE 80W90 and API grade GL5.

  • Page 56: Maintenance

    Disc mower GMD702F 3. Maintenance Before carrying out any maintenance or repairs on the machine, switch off the tractor engine, remove ignition key, wait until all moving parts have come to a standstill and apply park brake.  Belts - Regularly check belt tension and in particular during the first hours of use: - Remove cover (1).
  • Page 57 Disc mower GMD702F  Lift cylinders The machine lift cylinders are fitted with compressed air chambers allowing the mowing unit to immediately react to ground unevenness. Check the pressure: - Place the machine in working position. - Shift the mowing unit lift cylinder directional control valve in float position.
  • Page 58 Disc mower GMD702F  Checking cutterbar oil level Regularly check the cutterbar oil level: - Place the cutterbar in horizontal position (with regards to X and Y axis). - Remove filler plug (1) and (2) as well as their seals.
  • Page 59 Disc mower GMD702F  Inspection of knives and securing elements Immediately replace worn or damaged parts with genuine KUHN parts. Knives Inspect systematically all knives before the machine is operated to: - ensure the cutting quality. - ensure safety in use.
  • Page 60 Disc mower GMD702F Securing elements Check the securing elements: - After hitting an obstacle. - When replacing knives. - At the beginning of each season. The fixing bolts should be changed in the following cases: - When there is visible distortion.
  • Page 61 Disc mower GMD702F  Knife replacement Replace knife lock-nuts and bolts when they have been removed 5 times. Replace immediately all worn or distorted knives. Never straighten a bent knife. Always replace both knives per disc. - Clean the nut case.
  • Page 62 Disc mower GMD702F  Disc replacement - Place a wooden wedge (2) between two discs to stop them from moving. - Remove 2 bolts (1) and their spring washers using the box spanner supplied with the machine. - Remove the disc conical cover.
  • Page 63 Disc mower GMD702F  Outer cones Check torque of outer cover mounting bolts (1): 6 daN m (44 lbf ft). Replace any lost or damaged cover. - (2) (Part no. 56806610) Maintenance and storage...

  • Page 64: Storage

    Disc mower GMD702F 4. Storage  At the end of each season - Clean the machine thoroughly. - Drain all gearboxes and cutterbar and refill with new oil (see "Lubrication" chapter). - Touch up any areas of damaged paintwork. - Put the machine under cover in a dry place.

  • Page 65: Troubleshooting Guide

    Disc mower GMD702F $Troubleshooting guide    Problem Cause Remedy Dull or broken knives. Replace knives. Make sure the arrow on the Uneven stubble. Knives not installed correctly. knife upper face is pointing in the disc's direction of rotation.
  • Page 66 Disc mower GMD702F Retension belts Belts slip. (replace them if necessary). Badly shaped windrows. Increase speed to 540 min Too low PTO speed (rotational 1000 min (depending upon frequency). specification). Insufficient cutterbar ground Incorrect tractor lift linkage clearance in "headland turn"...

  • Page 67: Limited Warranty

    KUHN equipment from an authorized KUHN dealer, that such equipment is, at the time of delivery to such purchaser, free from defects in material and workmanship, and that such equipment is covered under this Limited Warranty providing the machine is used and serviced in accordance with the recommendations in the Operator's manual.
  • Page 68 - The warranty claim is completed on line via extranet - www.kuhn.com or submitted on a KUHN warranty claim form and returned to the Company within one month after the date of failure or the date of problem becoming apparent.
  • Page 69 $Specimen of the "Declaration of conformity" EC Declaration of conformity (European directive 2006/42/CE) The manufacturer: Manufacturer name and address declares that the product described hereafter: Brand Brand Machine Machine Type / Model : Type / Model Serial no. Serial no. - conforms to the requirements of the European directive 2006/42/CE.
  • Page 72 KUHN S.A. - B.P. 50060 - F - 67706 SAVERNE CEDEX (FRANCE) KUHN-AUDUREAU S.A. - B.P. 19 - F - 85260 LA COPECHAGNIERE (FRANCE) KUHN-BLANCHARD SAS - 24, route de Nantes - F - 44680 CHEMERE (FRANCE) KUHN-HUARD S.A. - B.P. 49 - F - 44142 CHATEAUBRIANT CEDEX (FRANCE) KUHN-GELDROP B.V.
