EMPX operators
Installation & maintenance information
APPLICATION
EMPX barrel assemblies include pilot lights, pushbutton switches, illuminated pushbutton
switches, selector switches and combinations. They are used in control stations, panels
and enclosures used in areas made hazardous due to the presence of flammable vapors,
gases or combustible dusts.
UL application details:
Identification:
Certificate:
Ambient temperature range:
Thread:
Required threads (Class I):
Required threads (Class II and III): T
Ingress protection:
Storage temperature in original packaging:
APPLICABLE STANDARDS
UL1203 Standard for Explosionproof and Dust-ignitionproof Electrical Equipment for
use in Hazardous (Classified) Locations
UL50 Enclosures for Electrical Equipment
UL508 Standard for Industrial Control Equipment
CSA C22.2 No. 25-1966 Enclosures for use in Class II, Groups E, F , G Hazardous
Locations
CSA C22.2 No. 30-M1986 Explosionproof Enclosures for use in Class I Hazardous
Locations
CSA C22.2 No. 94-M91 Special Purpose Enclosures Industrial Products
CSA C22.2 No. 14-13 Industrial Control Equipment
EN 60079-1 / IEC 60079-1
EN 60079-31 / IEC 60079-31
TECHNICAL DATA
This product is not intended to be used alone. The electrical apparatus or systems to which
it is being incorporated require certification as a whole when intended for use in explosive
atmospheres. The 3/4" NPSM thread joint of this product, and the thread of the equipment
to which it is being incorporated, must have a female 3/4" NPSM thread attending the
requirements for threaded joints.
ELECTRICAL SPECIFICATIONS
PUSHBUTTONS:
Rated voltage
Rated current
Breaking capacity for AC 15
Breaking capacity for DC 13
ILLUMINATED PUSHBUTTONS:
CONTACT BLOCK INFORMATION
Rated voltage
Rated current
Contacts for AC 15
Contacts for DC 13
IF 1857 • 09/18
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
Class I, Division 1, Groups B, C, D
Class II, Division 1, Groups E, F , G
Class III
E10593
-50°C to +60°C
3/4" x 14 NPSM
Eight (8) full threads engaged
Three (3) full threads engaged
Type 4X
-20°C to +50°C
U
500V
i
I
10A
th
Voltage
Current
220V
10A
380V
7.5A
500V
5A
Voltage
Current
24V
2.75A
60V
1.10A
110V
0.55A
220V
0.27A
U
500V
i
I
6A
th
Voltage
Current
250V
6A
Voltage
Current
24 VDC
3A
Copyright © 2018, Eaton's Crouse-Hinds Division
IMPORTANT NOTE
When EMPX devices are to be installed in Crouse-Hinds equipment, refer to Installation
Instruction Sheet that came with that equipment for proper installation.
IECEx and ATEX application details:
Identification:
Certificates:
Ambient temperature range:
Thread:
Required threads (EN 60079 1):
Required threads (EN 60079 31):
Ingress Protection:
Storage temperature in original packaging:
PILOT LIGHTS:
12V / 24V / 120V
240 VAC
Rated voltage: 250 VAC/VDC
Rated voltage: 240 VAC
Maximum power: 2.6W
Maximum power: 2.6W
NOTE: Verify that LED marked rating matches the socket before replacement.
ROTARY SWITCHES:
Breaking capacity
Rated current
for AC
20A
220-240V
3.0 kW
AC-3
380-440V
5.5 kW
220-240V
5A
AC-15
380-440V
4A
220-240V
20A
AC-22A
380-440V
20A
220-240V
3.7 kW
AC-23A
380-440V
7.5 kW
Breaking capacity for
Rated
DC
current 20A
24V
48V
60V
Resistive
loads
20A
12A
4.5A
T<1ms
Inductive
loads
12A
2A
1A
T=50ms
II 2G Ex db IIC Gb
II 2D Ex tb IIIC Db
Sira 18ATEX1236U
IECEx CSA 18.0027U
-50°C to +60°C
3/4" x 14 NPSM
Five (5) threads engaged (3/4" NPSM)
3.7mm (3/4" NPSM)
IP66W (salt spray)
-20°C to +50°C
LED SOCKET
480 VAC
Rated voltage: 480 VAC
Maximum power: 2.6W
Rated voltage
Rated current
Max. no. contact
chambers
110V
1A
0.4A
IF 1857
690V
20A
6
Page 1
