C3 USER MANUAL CONTENT Chapter 1 C3 Interfaces Introduction ..........................1 1.1 C3 Interface ................................1 1.2 Hardware Connection ..............................2 Chapter 2 Operation Environment ........................... 3 Chapter 3 C3 Parameter Settings ............................ 5 3.1 Connection Settings ..............................5 3.2 Basic Settings ................................8 3.3 Advanced Settings .............................. -
Page 3: Chapter 1 C3 Interfaces Introduction
C3 USER MANUAL Chapter 1 C3 Interfaces Introduction 1.1 C3 Interface Interface Function Indicator Light Indicate power and signal status LED DISPLAY Connect with LED screen (connect to receiving card) Audio HIFI stereo output CONFIG Connect with PC for parameters setting and contents update... -
Page 4: Hardware Connection
C3 USER MANUAL 1.2 Hardware Connection C3 Configuration Control & play without computer... -
Page 5: Chapter 2 Operation Environment
C3 USER MANUAL Chapter 2 Operation Environment Supported system: C3 only can run under windows 7/8/10, not support windows XP. Supported software: LEDVISION, 4.20 version or higher version is recommended. You can download the LEDVISION software from Colorlight’s official website www.lednets.com,... - Page 6 C3 USER MANUAL 2. Click [ Browse ], then choose the installation location, then click[ Next ], choose components according to your own computer status, click [ Install ] to complete.
-
Page 7: Chapter 3 C3 Parameter Settings
3.1 Connection Settings 1. Before connecting your C3 to the computer, first click [ Control ] on menu → [ Screen Control ], then select [ C-Series Box Play ] in Select Sending Device, then set up [ LED Screen Window Management]. - Page 8 C3 USER MANUAL 2. Use standard A/B cable to connect C3 to computer when C3 is powered on, one side to connect USB port, another side for C3 CONFIG port. Click [ Publish Program to C Series Playboxes ] (as shown in the red box) to enter program publish...
- Page 9 C3 USER MANUAL 3. Left-click [ Direct USB ] and then right-click [ Refresh ], your C3 will show up in program publishing window, select your device to set parameters and choose what content to play.
-
Page 10: Basic Settings
Ensure LED display is under normal configuration before setting on C3 parameters. When setting C3 parameters, you can connect your C3 to you PC through a standard USB A/B cable, and connect your C3 to your LED screen through network cable. - Page 11 C3 USER MANUAL The surface development of your C3’s parameter setting interface is shown below:...
-
Page 12: Advanced Settings
C3 USER MANUAL 3.3 Advanced Settings ① Screen Resolution The [ Width ]/[ Height ] you input must be equal to slightly larger than the actual screen resolution. ② Output [ Every Frame ] (Default) [ Every Other Frame ] (Choosing Every Other Frame can help avoid lag when image loading is too large) ③... -
Page 13: Chapter 4 Async Program Editing And Publishing
C3 USER MANUAL Chapter 4 Async Program Editing and Publishing 4.1 Async Program Editing When you open LEDVISION, you will see [ LED1 ] in program editing area. Right-click [ LED1 ] to add [ normal page ], you can add [ file window ] in [ normal page ], then add [ image ] and [ video ] under the... -
Page 14: Async Program Publishing
C3 USER MANUAL 4.2 Async Program Publishing 4.2.1 Publish Program through Direct USB... - Page 15 ① In [ program editing area ], after finishing content editing, select the [ program page ] that you are going to publish; ② Click [ C3 ] and then right-click to choose [ Publish Program to current play box ], you must rename the content and allow it to finish uploading to fully publish your program.
-
Page 16: Publish Program Through Ethernet Port
C3 USER MANUAL 4.2.2 Publish Program through Ethernet Port 2, Publish contents... - Page 17 ① In [ program editing area ], after finishing content editing, select the [ program page ] that you are going to publish; ② Click [ C3 ] and then right-click to choose [ Publish Program to current play box ], you must rename the content and allow it to finish uploading to fully publish your program.
-
Page 18: Publish Program Through Usb Disk
C3 USER MANUAL 4.2.3 Publish Program through USB Disk 1. To begin publishing through USB, first insert your USB stick to the PC USB port. Click [ Publish Program to C Series Playboxes ] to extend program publishing window. Note: USB stick should be empty before publishing for best performance. Remove previous update... - Page 19 2. Software will automatically identify USB stick when plug, click [ U Disk ] to choose [ Your USB’s Drive ]. ① Select [ program page ] in program editing area. ② Choose USB Stick Mode: • Play program from USB stick (Auto play USB stick content after inserting to C3; and the content won’t...
- Page 20 C3 USER MANUAL be stored in C3). • Update program from USB stick (Auto play USB stick content after inserting to C3; and the content will be stored in C3). ③ Select the drive letter under USB stick group, then right-click to choose [ Publish the current program to the selected disk ], after publishing program successfully, insert USB stick into C3 USB port.
-
Page 21: Async Program Scheduling
First publish multi-programs to C3 through the way of 4.1 and 4.2.above Then: ① In [ program publishing area ], select C3 and enter the interface of C3 Parameter settings; ② Click [ Schedule Settings ] →Advanced, and you can conduct Program Scheduling;... - Page 22 C3 USER MANUAL ③ Click [ Add ], select Play Program, and set Play Time, click [ OK ]; ④ Repeat the step③ to complete the program scheduling.
- Page 23 C3 USER MANUAL...
