Mediatrix 2102 Specifications

®
The Mediatrix 2102 is a high-
quality and cost efficient VoIP
gateway connecting SOHOs to an
IP network, while preserving
investment in analog telephones
and faxes.
It allows Services Providers to
deploy rapidly and economically
their solutions in smaller
premises and it is the ideal
solution for remote line
connection to larger private
networks.
Key Benefits
Voice Functionalities
Carrier-grade voice quality
T.38 support
High compression Codecs support
Ease of configuration
Automatic firmware and configuration file
download
SNMP and web management
TFTP, HTTP or HTTPS auto-provisioning
Security
Support for SNMPv3
Encrypted configuration files support
HTTP Digest authentication
HTTPS support
Network functionalities
Transparent IP Address Sharing
PPPoE and DHCP client
STUN Support
Interoperable with equipment from leading
industry vendors
Sales Department
Americas - Tel: 1-877-GET-VOIP / (877) 438-8647 Tel: (819) 829-8749
Europe, Middle East, Africa - Tel: 49 (0)30-3496-2085
©2008, Mediatrix Telecom, a Division of Media5 Corporation
Mediatrix 2102 – 2 port VoIP Access Device
Mediatrix 2102 Overview
The Mediatrix 2102 connects up to two analog phones and/or
faxes, as well as a PC or a home router to a broadband modem.
The Mediatrix 2102 enables cost-effective VoIP deployments in
residential and SOHO applications.
With an embedded PPPoE client and its innovative Transparent IP
Address Sharing technology, the Mediatrix 2102 and the PC or
router connected to the second Ethernet port have the same public
IP address, eliminating the need for private IP addresses or address
translations.
The Mediatrix 2102 has the additional benefit of supporting high
compression codecs simultaneously on both analog voice ports, thus
saving valuable bandwidth.
As all other Mediatrix devices, the 2102 provides web interface,
giving users a convenient access to the unit for initial set-up. The
devices can also auto-provision by fetching their encrypted
configuration from a TFTP, HTTP or HTTPS server making
installation secure and transparent to the end-users. To further
facilitate deployments, factory loaded configurations are possible.
Technical Specifications
IP Telephony Protocol
SIP – RFC3261
Vocoders
G.711 (a-law, -law) with optional VAD support, G.723.1, G.726,
G.729a, ab
Echo Cancellation
G.168
Silence Suppression
Silence detection / suppression and Comfort Noise Generation level
software adjustable.
Fax: (819) 829-5100
/ CALA – Tel: (954)-349-0394 Fax: (954) 349-8722
MIP-GES080930 2102ProductBrochure
