F&F MB-LI-4 Hi Manual page 10

address
Read inputs status:
0/1 – 4 bits (e.g. 1001)
0
Order:
| In4 | In3 | In2 | In1 |
16 In1: Input status 0/1
32 In2: Input status 0/1
48 In3: Input status 0/1
64 In4: Input status 0/1
address
In1: Number of pulses
17÷18
R18×256²+R17
In2: Number of pulses
33÷34
R34×256²+R33
In3: Number of pulses
49÷50
R50×256²+R49
Digital input registers
description
Counters registers
description
- 10 -
func. type
01 int
03 int
03 int
03 int
03 int
func. type
03 int
03 int
03 int
atr.
R
R
R
R
R
atr.
R
R
R
