- Page 1 Kit Instructions Remote I/O Chassis 7772-K038/K039 Issue B...
-
Page 2: Revision Record
NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current. - Page 3 Remote I/O Chassis This kit provides a Remote I/O Chassis for the NCR CX7 All-in-One POS (7772) or NCR CX5 All-in-One POS (7773). • 7772-K038 – Remote USB Centric I/O (Retail) Chassis • 7772-K039 – Remote Serial Centric I/O (Hospitality) Chassis...
-
Page 4: Kit Contents
Remote I/O Chassis Kit Contents 7772-K038 Remote USB Centric I/O (Retail) Chassis Item Part Number Description Remote USB Centric I/O (Retail) Chassis Assembly 497-0526508 Bottom Plate, Remote I/O, CX7 497-0526509 Casing, Remote I/O, CX7 497-0526511 Remote I/O Plate and Shield, Retail, CX7 497-0467780 Foot, Rubber, 7600 497-0525283 PCB Assembly –... - Page 5 Remote I/O Chassis 7772-K039 Remote Serial Centric I/O (Hospitality) Chassis Item Part Number Description Remote Serial Centric I/O (Hospitality) Chassis Assembly 497-0526508 Bottom Plate, Remote I/O, CX7 497-0526509 Casing, Remote I/O, CX7 497-0526510 Remote I/O Plate and Shield, HSR, CX7 497-0467780 Foot, Rubber, 7600 497-0525263 PCB Assembly –...
-
Page 6: Installation Procedure
Remote I/O Chassis Installation Procedure Warning: Disconnect the AC power cord from the AC outlet and wait 30 seconds before servicing the terminal. 1. Install the Brackets on each side of the Remote I/O Chassis (2 screws per bracket) in the orientation shown below. - Page 7 Remote I/O Chassis 2. Mount the assembly on the wall as desired. The Remote I/O Chassis can be mounted in four (4) ways: I/O Facing Up I/O Facing Down...
- Page 8 Remote I/O Chassis I/O Facing Right...
- Page 9 I/O Facing Left 3. Connect the cables to the appropriate I/O port. For information on the ports available for each kit, refer to the I/O Ports section: • 7772-K038 Remote USB Centric I/O (Retail) Chassis on the next page • 7772-K039 Remote Serial Centric I/O (Hospitality) Chassis on page 9...
- Page 10 Remote I/O Chassis I/O Ports 7772-K038 Remote USB Centric I/O (Retail) Chassis Callout Port Name RJ50 Serial (Enhanced UART) Dual USB 3.0 DisplayPort DB9 Serial (Standard UART) LAN In LAN Out USB-C 24V Power In USB 12V USB 24V Cash Drawer...
- Page 11 Remote I/O Chassis 7772-K039 Remote Serial Centric I/O (Hospitality) Chassis Callout Port Name RJ12 Serial • COM1 (Enhanced UART) • COM2 (Standard UART) • COM3 (Enhanced UART) • COM4 (Standard UART) Cash Drawer A Cash Drawer B DisplayPort LAN In LAN Out USB-C 24V Power In USB 24V...
