- Page 1 Marvel Ice Machine Installation Operation & Maintenance Instructions Part of AGA Foodservice Group...
-
Page 2: Starting Out
S TA RT I N G O U T Remove Packaging Your ice machine has been packed for shipment with all parts that could be damaged by movement securely fastened. Before installing the ice machine, be sure all packing materials and tape have been removed. -
Page 3: Installation
Select Location The proper location will ensure peak perform- ance of your ice machine. Choose a location away from heat and out of direct sunlight. Best performance will be maintained when installed within the following parameters: Ideal Ambient Temperature Range built-in 55-80°F freestanding... - Page 4 I N S TA L L AT I O N : D R A I N P L U M B I N G Drain Plumbing Your ice machine uses a gravity drain, (figure 1) that requires 5/8" I.D. tubing from the back of the ice machine to a plumbed connection to a sanitary sewer.
-
Page 5: Water Supply
Water Supply This ice machine must be connected to a potable, active cold water supply line delivering water pressure at a minimum of 20 psi and maximum of 120 psi. • Water connection is made through a right angle garden hose fitting. See garden hose fitting for detailed instruction sheet. -
Page 6: Care Of The Unit
C A R E O F T H E U N I T Care of Unit 1. Avoid leaning on the cabinet door. You may bend the door hinge or tip the unit. 2. Exercise caution when sweeping, vacuuming, or mopping near the front of the unit. Damage to the grille and/or switch can occur. -
Page 7: C A R I N G F O R Y O U R I C E M A C H I N E
Cleaning Your Ice machine Some impurities will remain and build-up in the ice machine and stick to the ice machine's parts over time. This build-up must be removed for proper ice production, ice quality, and ice machine life. Your ice machine is equipped with a cleaning mode that will help in cleaning out these impurities. -
Page 8: Things To Remember
T H I N G S TO R E M E M B E R Things to Remember • Allow your ice machine to run for 24-48 hours to accumulate ice in ice machine's bin. • Unit will cycle often between ice production and ice harvest cycles. -
Page 9: D O O R A Lt E R At I O N S
Optional Door Handle Installation (for units without door handle attached) The door handle for certain doors may be packed inside your ice machine can be mounted on the top or side of your refrigerator door. Locate the handle where it is convenient for you. You will need a 1/4"... -
Page 10: Obtaining Service
O B TA I N I N G S E RV I C E Before Calling for Service Before calling for service, check the following items: • Make sure unit is plugged into outlet. • Check the outlet for power. Test outlet with lamp to make certain outlet has power. -
Page 11: Warranty
Entire Product Limited One Year Parts and Labor Warranty Marvel warrants that it will supply all necessary parts and labor to repair or replace in the end user's home or office, any component which proves to be defective in material or workmanship,... -
Page 12: T R O U B L E S H O O T I N G O N E
T R O U B L E S H O O T I N G O N E PROBLEM Unit does not operate. Unit operates but does not produce any ice. POSSIBLE CAUSE The unit is unplugged. Breaker is tripped or fuse is blown. Ice machine selector switch is in the "OFF"... -
Page 13: T R O U B L E S H O O T I N G T W O
