Summary of Contents for Marvel 30iM
- Page 1 M A R V E L I C E M A C H I N E Installation Operation Maintenance Instructions Clear Ice Models 30iM 3OiM outdoor l i f e . l u x u r y. m a r v e l ™...
-
Page 3: Table Of Contents
TA B L E O F C O N T E N T S Starting Out ............3 Installation ............4 Installation: Drain Plumbing .........5 Water Supply............6 Care of the Unit ............7 Caring for Your Ice Machine.........8 Things to Remember..........9 Door Alterations..........10 Obtaining Service ..........11 Warranty .............12 Troubleshooting..........13-16... -
Page 4: Starting Out
S TA RT I N G O U T Remove Packaging Your ice machine has been packed for shipment with all parts that could be damaged by movement securely fastened. Before installing the ice machine, be sure all packing materials and tape have been removed. -
Page 5: Installation
I N S TA L L AT I O N Select Location The proper location will ensure peak perform- Framed, Panel Ready ance of your ice machine. Choose a location Style Door away from heat and out of direct sunlight. Best performance will be maintained when installed within the following parameters: Ideal Ambient Temperature Range... -
Page 6: Installation: Drain Plumbing
I N S TA L L AT I O N : D R A I N P L U M B I N G Drain Plumbing Your ice machine uses a gravity drain, (figure 1) that requires 5/8" I.D. tubing from the back of the ice machine to a plumbed connection to a sanitary sewer. -
Page 7: Water Supply
WAT E R S U P P LY Water Supply This ice machine must be connected to a potable, active cold water supply line delivering water pressure at a minimum of 20 psi and maximum of 120 psi. • Water connection is made through a right angle garden hose fitting supplied with ice machine. -
Page 8: Care Of The Unit
C A R E O F T H E U N I T Care of Unit 1. Avoid leaning on the cabinet door. You may bend the door hinge or tip the unit. 2. Exercise caution when sweeping, vacuuming, or mopping near the front of the unit. Damage to the grille and/or switch can occur. -
Page 9: Caring For Your Ice Machine
C A R I N G F O R Y O U R I C E M A C H I N E Cleaning Your Ice Machine After the cleaning cycle has ended, remove Some impurities will remain and build up in the ice the front panel again and check that the machine and stick to the ice machine's parts over build-up has been removed. -
Page 10: Things To Remember
T H I N G S TO R E M E M B E R Things to Remember • Allow your ice machine to run for 24-48 hours to accumulate ice in ice machine's bin. APPROXIMATE TIME TO FILL PRODUCTION RATE •... -
Page 11: Door Alterations
D O O R A LT E R AT I O N S Optional Door Handle Installation for Panel Reversing the Door Ready Doors (for units without door handle You may want to change the side on which the attached) door opens and closes. -
Page 12: Obtaining Service
If service becomes necessary: Appliance Serial Number 1. If the product is within the first year warranty period, please call Marvel Customer Service at 800-428-6644 for directions on how to Model Number obtain warranty coverage in your area. -
Page 13: Warranty
Parts or Service Limited One Year Parts and Labor Warranty Not Supplied or Designated by Marvel Marvel warrants that it will supply all necessary The above warranties also do not apply if: parts and labor to repair or replace in the end... -
Page 14: Troubleshooting
T R O U B L E S H O O T I N G O N E PROBLEM POSSIBLE CAUSE CORRECTION Unit does not operate. The unit is unplugged. Plug in the unit. Breaker is tripped or fuse is blown. Reset breaker or replace fuse. - Page 15 T R O U B L E S H O O T I N G T W O PROBLEM POSSIBLE CAUSE CORRECTION Low ice consumption. Ice is slowly melting in the ice bin and will affect the size of Ice cubes are too small (less than the ice cube.
- Page 16 T R O U B L E S H O O T I N G T H R E E PROBLEM POSSIBLE CAUSE CORRECTION Ice is not clear. Low water level in reservoir. Make sure that the reservoir drain plug is installed properly. Check the water line to the unit to make sure there are no restrictions or kinks in the line.
- Page 17 T R O U B L E S H O O T I N G F O U R PROBLEM POSSIBLE CAUSE CORRECTION Ice cubes are sticking together. Ice consumption is low. Use the ice in the bin frequently. Ice will stick together if left in insulated bin over long periods of time.
-
Page 18: Service Parts Diagrams & Part Lists
S E RV I C E PA RT S D I A G R A M O N E... - Page 19 S E RV I C E PA RT S L I S T O N E Illus. No. Description Qty. Req. Part No. Service Assembly Serial Nameplate various Location Only Hole Plug 41001929 42242085 Screw 41004079 42242989 Escutcheon 41007277 42242989 Grille White 41006376 42243390...
- Page 20 S E RV I C E PA RT S D I A G R A M T W O...
- Page 21 S E RV I C E PA RT S L I S T T W O Illus. No. Description Qty. Req. Part No. Service Assembly Distributor Tube End 41005705 42242977 Distributor Tube 41005515 42242976 Tubing 41005042 42242976 Evaporator Assembly 42052559 42242978 Screw 08204920...
- Page 22 S E RV I C E PA RT S D I A G R A M T H R E E 120V 4000-20C02AE411 PRI-120VAC SEC-12VAC 20 V.A. 3597G CLASS 2 50/60Hz "B" 130-G PRODUCTS UNLIMITED CORP, U.S.A. DETAIL A-A (BOTTOM VIEW) SATURN CONTROL DETAIL A-A INSIDE COVER...
- Page 23 S E RV I C E PA RT S L I S T T H R E E Illus. No. Description Qty. Req. Part No. Service Assembly Condenser 41003609 42243035 Pop Rivet, Steel 41003962 42243035 Coil Retainer 41003662 42241490 Solenoid Coil 41003601 42242141 Hot Gas Valve...
- Page 24 S E RV I C E PA RT S D I A G R A M F O U R...
- Page 25 Hinges (upper & lower), Blk. 52417485 42244947 Hinges (upper & lower), Chrome 52417484 42244356 Hinges (upper & lower), Wht. 52417486 42246371 Hinge Screws, Blk. 41007599 42245718 Hinge Screws, Zinc 41007598 42245719 Hinge Screws, Wht. 41007600 42245720 Gasket, Wht. 41006285 42243388 Marvel Nameplate 41004477 42243063...
-
Page 26: Preparing Your Ice Machine For Storage
P R E PA R I N G Y O U R I C E M A C H I N E F O R S TO R A G E Storage of Ice Machine 5. Unplug the unit from the electrical outlet. If the ice machine is to be moved, not used for an 6. - Page 28 . c o m Marvel Industries P.O. Box 997 Richmond, IN 47375-0997 800.428.6644 All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements 41010308 Rev.
