- Page 1 MARVEL Installation Operation Maintenance Instructions Refrigerator / Freezer Models 61RF 80RF...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Unpacking your refrigerator...2 Removing the packaging...2 Warranty Registration...2 Installing your refrigerator...3 Selecting the location...3 Cabinet Clearances...3 Leveling legs...3 Grounding method...3 Electrical Requirements...3 Using Your Refrigerator...4 Setting the temperature control...4 Defrosting instructions...4 Dimensions For Models 61RF Solid Door... 5 Recommended Rough in Opening Dimensions For Models 61RF Solid Door... -
Page 3: Unpacking Your Refrigerator
MANUFACTURER - FILE THE CLAIM WITH THE RETAILER. If the unit was shipped or has been laying on its back for any period of time allow the refrigerator to sit upright for a period of at least 24 hours before plugging in. This will assure oil returns to the compressor. -
Page 4: Installing Your Refrigerator
For this reason it is important this area to not be obstructed and be kept clean. Marvel does not rec- ommend the use of custom made grilles as air flow may be restricted because of inadequate openings. -
Page 5: Using Your Refrigerator
(between the #3 and #4).After at least 2 hours adjust to the temperature that suits you. The higher the number you select, the cooler the temperature. (See figure 3). After loading the refrigerator allow at least 24 hours for your refrigerator to reach a new temperature setting. Figure 3... -
Page 6: Dimensions For Models 61Rf Solid Door
DIMENSIONS FOR MODELS 61RF SOLID DOOR Recommended Rough in Opening Dimensions, Models 61RF Solid Door 34-1/2” (87.6 cm) *24” (61 cm) standard cabinet 24” (61 cm) 23-7/8” (60.66cm) 34-1/4” to 34-1/2” 87 to 87.6cm) 3” to 3-1/4” 7.62 to 8.26cm) depth 47”... -
Page 7: Dimensions For Model 61Rf Solid Overlay Door
DIMENSIONS FOR MODEL 61RF SOLID OVERLAY DOOR 46-27/32” (119.02cm) 23-7/8” 24-1/16” (60.66cm) (61.11cm) 34-1/4” to 34-1/2” 87 to 87.6cm) 3” to 3-1/4” 22” 7.62 to 8.26cm) (55.8cm) 23-5/16” (59.21cm) Recommended Rough in Opening Dimensions, Model 61RF Solid Overlay Door Electrical Requirements: 115 volts, 3.3 amps running max. -
Page 8: Dimensions For Model 80Rf Solid Door
DIMENSIONS FOR MODEL 80RF SOLID DOOR Recommended Rough In Opening Dimensions, Model 80RF Solid Door 34-1/2” (87.6 cm) *24” (61 cm) standard cabinet depth 30” (76.2 cm) 47” (119.38cm) 29-7/8” (75.9cm) 34-1/4” to 34-1/2” 87 to 87.6cm) 3” to 3-1/4” 7.62 to 8.26cm) Electrical Requirements: 115 volts, 3.3 amps running max. -
Page 9: Dimensions For Model 80Rf Solid Overlay Door
DIMENSIONS FOR MODEL 80RF SOLID OVERLAY DOOR 46-27/32” (119.02cm) 29-7/8” (75.9cm) 24-1/16” (61.11cm) 34-1/4” to 34-1/2” 87 to 87.6cm) 22” 3” to 3-1/4” (55.8cm) 7.62 to 8.26cm) 23-5/16” (59.21cm) Recommended Rough In Opening Dimensions, Model 80RF Solid Overlay Door Electrical Requirements: 115 volts, 3.3 amps running max. -
Page 10: Full Overlay Panel Installation Instructions
Step 1: Verify door alignment The door should be parallel to the sides and top of the refrigerator. If alignment is necessary the door may be adjusted by loosening the 2 screws which secure the hinge adapter brackets to the door and adjusting the door side to side. - Page 11 3/32” (2.4mm) Diameter. Pilot Hole Softwood 5/64 (2.0mm) Diameter. Pilot Hole Table B If your refrigerator has a door lock proceed to Step 7. If your refrigerator does not have a door lock proceed to Step 9. Step 7: Mark and drill lock hole.
- Page 12 Install the top hinge pin so the screw head is flush with the top surface of the hinge. If applicable insert key into lock and verify the lock cam works properly with the catch bracket on the front of the refrigerator cabinet. Top hinge pin Top door hinge...
-
Page 13: Care And Cleaning
Condenser Air Flow The machine compartment located beneath the cabinet does not require frequent cleaning; however, satisfactory performance depends on adequate ventilation. Be sure nothing obstructs the required air flow openings in front of the cabinet. At least once or twice a year, brush or vacuum lint and dirt from the front grille openings. -
Page 14: Troubleshooting Your Refrigerator
If Service is Required: • If the product is within the first year warranty period please call Marvel Customer Service at 800.223.3900 for directions on how to obtain warranty coverage in your area. •... -
Page 15: Household Product Warranty
Entire Product Limited One Year Parts and Labor Warranty Marvel warrants that it will supply all necessary parts and labor to repair or replace in the end user’s home or office, any component which proves to be defective in material... - Page 16 Northland-Marvel P .O. Box 400 1260 E. Van Deinse St. Greenville MI 48838 800.223.3900 41011769-EN Rev F 11/10/09 www.marvelrefrigeration.com All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, replacements or compensation for...
