Nilfisk-Advance SC530 Use & Maintenance

Use & maintenance
- SC530
ATTENTION! Do not use the machine before you have read and understood the Instructions for User Manual
1. Disconnect the battery charger cable
from the mains electricity supply.
6. Lower the brush deck with the pedal.
10. Once you have finished cleaning
empty the recovery tank with the hose.
Then empty the solution tank with the
trasparent hose.
15. Clean the filter by removing the
transparent cover and the gasket.
If the machine has been used until the red light illuminates on the battery level indicator on the machine, a full recharge of the batteries (10-12 hours) will be required. Failure to carry out this this
procedure may cause damage to the batteries. Charging the batteries after every use is recommended.
Nilfisk Ltd.
Nilfisk House · Bowerbank Way · Tel.: 01768 868995 (UK) · 01 2943838 (IE)
Gilwilly Industrial Estate · Penrith · Email: sales.uk@nilfisk.com (UK & IE)
Cumbria · CA11 9BQ www.nilfisk.co.uk · www.nilfisk.ie
2. Fill the tank with a clean water. The
clean water temperature must not
exceed 40 °C.
7. Turn on the key, then slightly press the
handle switch to engage the brush.
11. Wash with clean water the recovery
tank and the vacuum grid.
16. Clean the machine using a damp
cloth and where needed use a
neutral cleaning product.
3. If the squeegee is not connected to
the machine: install and fasten it with
the handwheels, then connect to the
suction hose.
8. Adjust (if needed) the solution flow
level according to the cleaning
performance and application.
12. Press the click-off button and wait
for the brush/pad holder to fall
on the floor. Remove to clean or
change brush.
17. Charge the batteries: Connect the
battery charger cable to the mains
electricity supply..
4. If the squeegee is in upper position,
lower it with the lever.
13. Take the squeegee off and remove
debris.
18. Park the machine with the recovery
tank cover open.
5. Place the brush or the pad-holder
under the deck. Use the appropriate
brush to clean the floor.
14. Check and clean the squeegee
blades.
