Arjo Enterprise 9000X Quick Reference Manual

QUICK REFERENCE GUIDE - CONTROLS
Enterprise 9000X
Attendant Control Panel (ACP)
Power On indicator
Battery Status LED indicator
fully charged
charging
discharged
CPR button - flattens the mattress platform.
Lower head end
(Trendelenburg position).
Lower foot end
(reverse Trendelenburg position).
Function Lock button - press the button, then
press selected Attendant Control Panel
button(s) to lock/unlock function.
Yellow light = locked
Auto-Chair up button - press and hold for chair
position.
Auto-Chair down button - return mattress
platform to flat and level position.
Caregiver Controls
Patient Controls
815-515EN_4 • 05/2020 • Page 1/2
Patient Handset
Raise/lower the mattress platform.
Raise/lower the thigh section.
Raise/lower the backrest.
Bio-Contour up button
(patient control only) -
raise backrest and thigh section.
Bio-Contour down button
(patient control only) - return to flat position.
