The chassis can then be secured to the rack
by two thumb screws located on the left and
right of the front side of the chassis.
Figure 2-5. Securing the Chassis to the Rack
Removing the Rails
Removing a rail is basically just the reverse of the installation procedure.
Push bottom
lock button
1
A
Figure 2-6. Removing a Rail
25
Chapter 2: Server Installation
8 9 10 11
4 5 6 7
0 1 2 3
Pull up and away
from the rack
1
B
