SuperStorage Server
SSG-6049SP-E1CR60
SSG-6049SP-E1CR90
USER'S MANUAL
Revision 1.0a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SuperStorage Server SSG-6049SP-E1CR60 and is the answer not in the manual?

Questions and answers

Related Manuals for Supermicro SuperStorage Server SSG-6049SP-E1CR60

Summary of Contents for Supermicro SuperStorage Server SSG-6049SP-E1CR60

  • Page 1 ® SuperStorage Server SSG-6049SP-E1CR60 SSG-6049SP-E1CR90 USER’S MANUAL Revision 1.0a...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................9 1.3 System Features ........................10 1.4 Server Chassis Features ....................11 Control Panel ........................11 Front Features ........................12 Rear Features ........................13 1.5 Motherboard Layout ......................14 Quick Reference Table ......................15 Chapter 2 Server Installation 2.1 Overview ..........................18 2.2 Preparing for Setup ......................18 Choosing a Setup Location ....................18...
  • Page 5 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Processor and Heatsink Installation ..................31 Overview of the Processor Carrier Assembly ..............32 Overview of the CPU Socket ....................32 Overview of the Processor Heatsink Module ..............33 Creating the Non-F Model Processor Carrier Assembly...........34 Assembling the Processor Heatsink Module ..............35 Preparing the CPU Socket for Installation ................36...
  • Page 6 Preface Overheating ........................57 Power Supply ........................58 Power Supply LEDs .......................58 Chapter 4 Motherboard Connections 4.1 Power Connections ......................60 4.2 Headers and Connectors ....................61 4.3 Ports ...........................63 Rear I/O ..........................63 Additional I/O Ports ......................64 4.4 Jumpers ..........................65 Explanation of Jumpers ....................65 4.5 LED Indicators ........................67 Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................69...
  • Page 7 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Chapter 1 Introduction

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the SuperStorage Server SSG-6049SP-E1CR60/90. The SSG-6049SP-E1CR60/90 is a high-density, single-node storage system comprised of two main subsystems: the CSE-947STS-R2K05BP/CSE-947HTS-R2K63P 4U chassis and the X11DSC dual processor motherboard.

  • Page 9: Unpacking The System

    Chapter 1: Introduction 1.2 Unpacking the System Inspect the box the system was shipped in and note if it was damaged in any way. If any equipment appears damaged, please file a damage claim with the carrier who delivered it. Decide on a suitable location for the rack unit that will hold the server.

  • Page 10: System Features

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 1.3 System Features The following table provides you with an overview of the main features of the SSG-6049SP-E1CR60/90. Please refer to Appendix C for additional specifications. System Features Motherboard X11DSC Chassis SSG-6049SP-E1CR60: CSE-947STS-R2K05BP SSG-6049SP-E1CR90: CSE-947HTS-R2K63P Dual Intel Xeon Scalable CPUs (Socket P) with three UltraPath Interconnects (UPIs) of up to 10.4 GT/s.

  • Page 11: Server Chassis Features

    Chapter 1: Introduction 1.4 Server Chassis Features Control Panel The switches and LEDs located on the control panel are described below. See Chapter 4 for details on the control panel connections. Figure 1-1. Control Panel View Control Panel Features Item Feature Description The main power button is used to apply or remove power from the...

  • Page 12: Front Features

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Front Features The CSE-947STS-R2K05BP/CSE-947HTS-R2K63P is a 4U chassis. See the illustration below for the features included on the front of the chassis. Figure 1-2. Chassis Front View Front Chassis Features Item Feature Description Drive Drawer Latch...

  • Page 13: Rear Features

    Chapter 1: Introduction Rear Features The illustration below shows the features included on the rear of the chassis. Figure 1-3. Chassis Rear View Rear Chassis Features Item Feature Description Power Supply Module 2000/2600W* power redundant supply 2.5" Drive Bays Two 2.5" hot-swap SATA SSD drive bays PCI Slot PCIe 3.0 x16 HHHL slot (slot 3, from CPU2) Six 8-cm counter-rotating fans...

  • Page 14: Motherboard Layout

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 1.5 Motherboard Layout Below is a layout of the X11DSC with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4.

  • Page 15: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 LAN1 Enable/Disable Pins 1-2 (Enabled) JPME1 ME Recovery Pins 1-2 (Normal) JPME2 Manufacturing Mode Select Pins 1-2 (Normal) JWD1 Watch Dog Timer Pins 1-2 (Enabled, Reset)
  • Page 16 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Notes: • Use an SMC-proprietary mezzanine card for SAS3 support. Install the mezzanine card to the JMCN1/JMCN2/JMCN3 slot. Refer to Chapter 4 for details. • To avoid causing interference with other components, please be sure to use add-on cards that are fully compliant with the PCIe standard in PCIe slots.
  • Page 17 Chapter 1: Introduction X11DSC CPU1-C1 CPU1-B1 CPU1-A1 CPU1-A2 CPU2-A2 CPU2-A1 CPU2-B1 CPU2-C1 PVCCIN_CPU1 12V_STBY PVCCIN_CPU1 12V_STBY VR13 VR13 5+1 PHASE 5+1 PHASE 205W 205W 10.4/11.2G CPU1 CPU2 Skylake/ Skylake/ Cascade lake Cascade lake DDR4 DDR4 CPU1-F1 CPU1-E1 CPU1-D1 CPU1-D2 CPU2-D2 CPU2-D1 CPU2-E1 CPU2-F1 PECI:30 PECI:31...

  • Page 18: Chapter 2 Server Installation

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 4 for details on installing those specific components.

  • Page 19: Rack Precautions

    Chapter 2: Server Installation Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them. • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together.

  • Page 20: Mechanical Loading

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.

  • Page 21: Installing The Rails

    Chapter 2: Server Installation 2.3 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. Do not use a two post "telco" type rack. This rail set fits a rack between 26.5" and 36.4"...
  • Page 22 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 2. Mount the front end of the rail by pushing the outer rail latch through one of the square holes on the front of the rack. 3. Pull the inner rail out of the outer rail until it reaches the rear of the rack.
  • Page 23 Chapter 2: Server Installation 5. Secure the length of the extended rail by tightening the screws into the holes closer to the inner rail. Figure 2-3. Extending the Rail 6. Repeat the preceding steps for the other rail, making sure it is mounted at the same height as the first installed rail so that they are parallel.
  • Page 24 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 7. Secure the rails to the rack by installing screws into the square holes on the front and rear of the rack aligned with the rail holes. Figure 2-5. Securing Rails to a Rack...

  • Page 25: Installing The Chassis Into The Rack

    Chapter 2: Server Installation 2.4 Installing the Chassis into the Rack After the rails are installed on the rack, the chassis can be installed in the rack. It is heavy and requires two to three people or a lift. Installing the Chassis into a Rack 1.
  • Page 26 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 3. Push the chassis all the way into the rear of the rack until side brackets on the front of the chassis touch the front of the rack. 4. Secure the front of the chassis to the front of the rack by tightening screws through the chassis bracket holes and the rack holes aligned with them.

  • Page 27: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 28: Accessing The System

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 3.2 Accessing the System Drive bays can be accessed by pulling the HDD drawer forward out of the chassis. Other components can be accessed though the front or rear of the chassis. Caution: Except for short periods of time, do not operate the server without the cover in place.
  • Page 29 Chapter 3: Maintenance and Component Installation Figure 3-2. Opening the Drawer 3. Push the drive carrier handle to release the carrier and pull the drive from the chassis Drive carrier handle Figure 3-3. Removing an HDD...

  • Page 30: Static-Sensitive Devices

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 3.3 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid damaging your motherboard, it is important to handle it very carefully. The following measures are generally sufficient to protect the system PCBs from ESD.

  • Page 31: Motherboard Components

    Thermal grease is pre-applied on a new heatsink. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • All graphics in this manual are for illustrations only. Your components may look different.

  • Page 32: Overview Of The Processor Carrier Assembly

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Overview of the Processor Carrier Assembly The processor carrier assembly contains the Intel Xeon Non-Fabric (Non-F) processor and a processor carrier. 1. Non-F Processor 2. Processor Carrier Overview of the CPU Socket The CPU socket is protected by a plastic protective cover.

  • Page 33: Overview Of The Processor Heatsink Module

    Chapter 3: Maintenance and Component Installation Overview of the Processor Heatsink Module The Processor Heatsink Module (PHM) contains a heatsink, a processor carrier, and the Intel Xeon Non-Fabric (Non-F) processor. 1. Heatsink with Thermal Grease 2. Processor Carrier 3. Non-F Processor Processor Heatsink Module Note: heatsink shown may differ from the heatsink in your system.

  • Page 34: Creating The Non-F Model Processor Carrier Assembly

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Creating the Non-F Model Processor Carrier Assembly To install a Non-F model processor into the processor carrier, follow the steps below: 1. Hold the processor with the LGA lands (gold contacts) facing up. Locate the small, gold triangle in the corner of the processor and the corresponding hollowed triangle on the processor carrier.

  • Page 35: Assembling The Processor Heatsink Module

    Chapter 3: Maintenance and Component Installation Assembling the Processor Heatsink Module After creating the processor carrier assembly for the Non-F model processor, mount it onto the heatsink to create the processor heatsink module (PHM): 1. Note the label on top of the heatsink, which marks the heatsink mounting holes as 1, 2, 3, and 4.

  • Page 36: Preparing The Cpu Socket For Installation

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Preparing the CPU Socket for Installation This motherboard comes with a plastic protective cover installed on the CPU socket. Remove it from the socket to install the Processor Heatsink Module (PHM). Gently pull up one corner of the plastic protective cover to remove it.

  • Page 37: Installing The Processor Heatsink Module

    Chapter 3: Maintenance and Component Installation Installing the Processor Heatsink Module After assembling the Processor Heatsink Module (PHM), install the PHM onto the CPU socket: 1. Align hole 1 of the heatsink with the printed triangle on the CPU socket. See the left image below.

  • Page 38: Removing The Processor Heatsink Module

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Removing the Processor Heatsink Module Before removing the processor heatsink module (PHM) from the motherboard, unplug the AC power cord from all power supplies after shutting down the system. Then follow the steps below: 1. Use a T30 Torx-bit screwdriver to loosen the four screws in a backwards sequence of #4, #3, #2, and #1.

  • Page 39: Memory

    Support for 2933 MHz memory is dependent on the processor SKU. • The max. memory capacity support will differ according to the processor SKU. • Check the Supermicro website for recommended memory modules. • Exercise extreme care when installing or removing DIMM modules to prevent any damage. Memory Installation Sequence Memory is populated using the "Fill First"...

  • Page 40: Ddr4 Memory Support For Intel Xeon Scalable-Sp Processors

    4H-128GB 4H-256GB 2933 2933 2933 Notes: • 2933 MHz memory support in a two-DIMM per-channel (2DPC) configuration can be achieved by using memory purchased from Supermicro. • 2933 MHz memory is supported by 2nd Generation Intel Xeon Scalable-SP processors only..

  • Page 41: Dimm Population Guidelines For Optimal Performance

    Chapter 3: Maintenance and Component Installation DIMM Population Guidelines for Optimal Performance For optimal memory performance, follow the instructions listed in the tables below when populating memory modules. Key Parameters for DIMM Configuration Key Parameters for DIMM Configurations Parameters Possible Values Number of Channels 1, 2, 3, 4, 5, or 6 Number of DIMMs per Channel...

  • Page 42: Dimm Population Table

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual DIMM Population Table Note: Unbalanced memory configuration decreases memory performance and is not recommended for Supermicro motherboards. Memory Population Table for Intel Xeon Scalable-SP and 2nd Gen Intel Xeon Scalable-SP Processors Memory Population Table for 16 DIMM Slots...

  • Page 43: Dcpmm Memory Population Tables For 2Nd Gen Intel Xeon Scalable-Sp Processors

    Chapter 3: Maintenance and Component Installation DCPMM Memory Population Tables for 2nd Gen Intel Xeon Scalable-SP Processors Note: Only 2nd Gen Intel Xeon Scalable-SP processors support DCPMM memory. Symmetric Population within 1 CPU Socket Modes P1-DIMMF1 P1-DIMME1 P1-DIMMD1 P1-DIMMD2 P1-DIMMA2 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1...

  • Page 44: Installing Memory

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Installing Memory Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge.

  • Page 45: Mezzanine Card Installation

    For driver, firmware and management tools please refer to the system page on the Supermicro website. This card hosts connectivity to two NVME M.2 devices (2280/22110mm form factor), PCIe NTB switch PM40036, and Ethernet controller...
  • Page 46 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Installing the Mezzanine Card 1. Power down the server and extend the node to which you want the card installed from the chassis. 2. Align the mezzanine card with the mezzanine tray. 3. Secure the mezzanine board to the tray with screws as shown below.

  • Page 47: Motherboard Battery

    Chapter 3: Maintenance and Component Installation Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 48: Chassis Components

    Blinking at 4Hz Locates a drive Idle Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website and check the "Drive Options" in the product webpage.

  • Page 49: Installing Hot-Swap 3.5"/2.5" Hard Drives

    Dummy trays feature a built-in adapter to support 2.5" drives. Drive Carrier Handle Figure 3-7. Removing a 3.5" Drive Carrier Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www.

  • Page 50: Hard Drive Installation

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Hard Drive Installation The drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airflow through the drive bays. Removing Hard Drive Carriers from the Chassis 1.
  • Page 51 Chapter 3: Maintenance and Component Installation 2. Pull open the chassis so that a locking lever on each side of the chassis aligns with the front of the chassis cover and front of the rack, then press the lever down on each side to lock the open part of the chassis in place.
  • Page 52 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Installing a 3.5" Hard Disk Drive With the drive carrier removed from the storage compartment: 1. Under the main the carrier handle, find and the lift the breakout lever and pull out the side of the carrier.

  • Page 53: Expander Modules

    Chapter 3: Maintenance and Component Installation Expander Modules The SSG-6049SP-E1CR60 contains two BPN-SAS3-947EL expander modules, which are labelled B and D. The SSG-6049SP-E1CR90 contains three BPN-SAS3-947EL expander modules, which are labelled B, D, and F. Note that there are no expanders E or F in the SSG-6049SP-E1CR60.
  • Page 54 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Removing an Expander Module from the Chassis 1. Each expander module has two latches on its top side, which lock the expander into place and must be opened to remove the expander from the chassis. Pull both latches up into the open position, as shown below.

  • Page 55: System Cooling

    Chapter 3: Maintenance and Component Installation System Cooling Six hot-swap, heavy-duty rear mounted fans provide cooling. They can be replaced without powering down the system. Fan speed is controlled by a system temperature setting in IPMI. If a fan fails, the remaining fans will ramp up to full speed.
  • Page 56 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Release Tabs Figure 3-17. Removing a Fan or Drive from a Motherboard Sled 1. Place the new fan into the vacant fan bay and confirm that the fan is fully seated in the fan bay.

  • Page 57: Checking The Server Air Flow

    Chapter 3: Maintenance and Component Installation Checking the Server Air Flow • Make sure there are no objects to obstruct airflow in and out of the server. • If you are using a front bezel, make sure the bezel filter is replaced periodically. •...

  • Page 58: Power Supply

    New units can be ordered directly from Supermicro or authorized distributors. The power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120V or 180-240V range (200-240V for the 2600W power supplies).
  • Page 59 Chapter 3: Maintenance and Component Installation Changing the Power Supply Module (Non-redundant Models) The SSG-6049SP-E1CR60 model with 100-127Vac power has non-redundant power. The system will need to be shut down before replacing a power supply module. 1. Remove power from the system and unplug the AC cord from the module to be replaced.

  • Page 60: Chapter 4 Motherboard Connections

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 61: Headers And Connectors

    Chapter 4: Motherboard Connections 4.2 Headers and Connectors Onboard Fan Header Two 4-pin fan headers (JFAN1, JFANPW) used for CPU/system cooling. These 4-pin fan headers are backward compatible with a traditional 3-pin fan. The onboard fan speed is controlled by Thermal Management (via Hardware Monitoring) in the BIOS. Please use all 4-pin fans on the motherboard for better thermal management and system cooling.
  • Page 62 These SATA ports are supported by the Intel PCH C621 chipset. S-SATA4 and S-SATA5 can be used with Supermicro SuperDOMs, which are yellow SATA DOM connectors with power pins built in and do not require external power cables. Supermicro SuperDOMs are backward-compatible with regular SATA HDDs or SATA DOMs that require...

  • Page 63: Ports

    Chapter 4: Motherboard Connections 4.3 Ports Rear I/O See Figure 4-1 below for the locations and descriptions of the various I/O ports as well as a UID switch/LED on the rear of the motherboard. IPMI_LAN LAN1/LAN2 USB0/1 DESIGNED IN USA MAC CODE JUSBRJ45 JFANPW...

  • Page 64: Additional I/O Ports

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Universal Serial Bus (USB) Ports There are two USB 3.0 ports (USB0/USB1) on the I/O back panel. USB2 is a Type A USB 3.0 header on the motherboard used to provide a front access USB connection.

  • Page 65: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 66 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Watch Dog JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for the application that hangs.

  • Page 67: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators Dedicated IPMI LAN LEDs A dedicated IPMI LAN is located on the I/O back panel of the motherboard. The amber LED on the right indicates activity, while the green LED on the left indicates the speed of the connection.
  • Page 68 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Onboard Power LED The Onboard Power LED is located at LE2 on the motherboard. When this LED is on, the system is on. Be sure to turn off the system and unplug the power cord before removing or installing components.

  • Page 69: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 70 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner.

  • Page 71: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash drive or a DVD.

  • Page 72: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 73: Ipmi

    When logging in to the BMC for the first time, please use the unique password provided by Supermicro to log in. You can change the unique password to a user name and password of your choice for subsequent logins.

  • Page 74: Chapter 6 Uefi Bios

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ setup utility for the X11DSC motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 75: Main Setup

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is the BIOS build after RTC reset. Supermicro X11DSC BIOS Version This feature displays the version of the BIOS ROM used in the system.
  • Page 76 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Memory Information Total Memory This feature displays the total size of memory available in the system.

  • Page 77: Advanced Setup Configurations

    Chapter 6: UEFI BIOS 6.3 Advanced Setup Configurations Use the arrow keys to select Boot Feature and press <Enter> to access the submenu items. Warning: Take caution when changing the Advanced settings. An incorrect value, an incorrect DRAM frequency, or an incorrect BIOS timing setting may cause the system to malfunction. When this occurs, restore the setting to the manufacture default setting.
  • Page 78 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 (Interrupt 19) Trap Response Interrupt 19 is the software interrupt that handles the boot disk function.
  • Page 79 Chapter 6: UEFI BIOS Power Button Function This feature controls how the system shuts down when the power button is pressed. Select 4 Seconds Override for the user to power off the system after pressing and holding the power button for 4 seconds or longer. Select Instant Off to instantly power off the system as soon as the user presses the power button.
  • Page 80 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Monitor/Mwait Select Enable to support Monitor and Mwait, which are two instructions in Streaming SIMD Extension 3 (SSE3), to improve synchronization between multiple threads for CPU performance enhancement. The options are Auto, Enable, and Disable.
  • Page 81 Chapter 6: UEFI BIOS LLC Prefetch Select Enable to support the LLC prefetch on all threads. The options are Disable and Enable. Extended APIC (Extended Advanced Programmable Interrupt Controller) Select Enable to use the extended APIC (Advanced Programmable Interrupt Control) support to enhance power management.
  • Page 82 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual *If SpeedStep (P-States) is set to Enable, the following items will display: EIST PSD Function This feature allows the user to change the P-State (Power-Performance State) coordina- tion type. P-State is also known as "SpeedStep" for Intel® processors. Select HW_ALL to change the P-State coordination type for all hardware components only.
  • Page 83 Chapter 6: UEFI BIOS Package C State Control (Available when "Power Technology" is set to Custom) Package C State This feature allows the user to set the limit on the C-State package register. The options are C0/C1 state, C2 state, C6 (non Retention) state, C6 (Retention) state, No Limit, and Auto. CPU T State Control (Available when "Power Technology"...
  • Page 84 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Link L0p Enable Select Enable for the QPI to enter the L0p state for power saving. The options are Dis- able, Enable, and Auto. Link L1 Enable Select Enable for the QPI to enter the L1 state for power saving. The options are Dis- able, Enable, and Auto.
  • Page 85 Chapter 6: UEFI BIOS Stale AtoS (A to S) The in-memory directory has three states: I, A, and S states. The I (-invalid) state indi- cates that the data is clean and does not exist in the cache of any other sockets. The A (-snoop All) state indicates that the data may exist in another socket in an exclusive or modified state.
  • Page 86 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Enhanced PPR Select Enable to enable DRAM test and Enhanced PPR function. The options are Dis- able and Enable. Opertaion Mode Memory Frequency Use this feature to set the maximum memory frequency for onboard memory modules.
  • Page 87 Chapter 6: UEFI BIOS IMC Interleaving Use this feature to configure interleaving settings for the IMC (Integrated Memory Control- ler), which will improve memory performance. The options are 1-way Interleave, 2-way Interleave, and Auto. Memory Topology  This item displays the information of onboard memory modules as detected by the BIOS (See figure below).
  • Page 88 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Mirror Mode Use this feature to configure the mirror mode settings for all 1LM/2LM memory modules installed in the system which will create a duplicate copy of data stored in the memory to increase memory security, but it will reduce the memory capacity into half. The op- tions are Disable, Mirror Mode 1LM, and Mirror Mode 2LM.
  • Page 89 Chapter 6: UEFI BIOS IIO Configuration  EV DFX Features When this feature is set to Enable, the EV_DFX Lock Bits that are located on a proces- sor will always remain clear during electric tuning. The options are Disable and Enable. CPU1 Configuration ...
  • Page 90 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual CPU2 Configuration  IOU0 (IIO PCIe Br1) This feature configures the PCI-E port Bifurcation setting for a PCI-E port specified by the user. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16, and Auto. IOU1 (IIO PCIe Br2) This feature configures the PCI-E port Bifurcation setting for a PCI-E port specified by the user.
  • Page 91 Chapter 6: UEFI BIOS ACS (Access Control Services) Control Select Enable to program Access Control Services to Chipset PCI-E Root Port Bridges. Select Disable to program Access Control Services to all PCI-E Root Port Bridges. The options are Enable and Disable. Interrupt Remapping If this feature is set to Enable, I/O DMA transfer remapping and device-generated interrupts will be supported.
  • Page 92 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual *If the feature "Intel® VMD for Volume Management Device" is set to Enable, the following features will be available: VMD port 1A (Available when the device is detected by the system) Select Enable to enable Intel® Volume Management Device Technology support for the PCIe slot specified by the user.
  • Page 93 Chapter 6: UEFI BIOS VMD port 2D (Available when the device is detected by the system) Select Enable to enable Intel® Volume Management Device Technology support for the PCIe slot specified by the user. The options are Disable and Enable. Hot Plug Capable (Available when the device is detected by the system) Select Enable to enable Hot Plug support for the root ports specified by the user, which will allow the user to change the devices on those root ports without shutting...
  • Page 94 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Intel® VMD for Volume Management Device on CPU2  Intel® VMD for Volume Management Device for PStack0 Select Enable to use the Intel® Volume Management Device Technology support for the root port specified by the user. The options are Disable and Enable.
  • Page 95 Chapter 6: UEFI BIOS VMD port 2B (Available when the device is detected by the system) Select Enable to enable Intel® Volume Management Device Technology support for the PCIe slot specified by the user. The options are Disable and Enable. VMD port 2C (Available when the device is detected by the system) Select Enable to enable Intel®...
  • Page 96 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Hot Plug Capable (Available when the device is detected by the system) Select Enable to enable Hot Plug support for the root ports specified by the user, which will allow the user to change the devices on those root ports without shutting down the system.
  • Page 97 Chapter 6: UEFI BIOS Server ME Configuration This feature displays the following system ME configuration settings. • Operational Firmware Version • Backup Firmware Version • Recovery Firmware Version • ME Firmware Status #1 • ME Firmware Status #2 • Current State •...
  • Page 98 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual SATA Port 0~ Port 3 Hot Plug (SATA Port 0~ Port 3) Select Enable to support Hot-plugging for the device installed on a selected SATA port which will allow the user to replace the device installed in the slot without shutting down the system.
  • Page 99 Chapter 6: UEFI BIOS SATA Device Type (SATA Port 0~ Port 3) Use this feature to specify if the device installed on the SATA port specified by the user should be connected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
  • Page 100 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Hot Plug (SATA Port 0~ Port 5) Select Enable to support Hot-plugging for the device installed on a selected sSATA port which will allow the user to replace the device installed in the slot without shutting down the system.
  • Page 101 Chapter 6: UEFI BIOS sSATA Device Type (SATA Port 0~ Port 5) Use this feature to specify if the device installed on the sSATA port specified by the user should be connected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
  • Page 102 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual NVMe Firmware Source This feature determines which type of the NVMe firmware should be used in your system. The options are Vendor Defined Firmware and AMI Native Support. VGA Priority Use this feature to select the graphics device to be used as the primary video display for system boot.
  • Page 103 Chapter 6: UEFI BIOS CPU2 SAS on AOM PCI-E 3.0 x16 OPROM Select EFI to allow the user to boot the computer using an EFI (Extensible Firmware Interface) device installed on the PCI-E slot specified by the user. Select Legacy to allow the user to boot the computer using a legacy device installed on the PCI-E slot specified by the user.
  • Page 104 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Ipv4 PXE Support Select Enabled to enable IPv4 PXE boot support. If this feature is disabled, it will not create the IPv4 PXE boot option. The options are Disabled and Enabled. Ipv4 HTTP Support Select Enabled to enable IPv4 HTTP boot support. If this feature is disabled, it will not create the IPv4 HTTP boot option.
  • Page 105 Chapter 6: UEFI BIOS Device Settings (Available when "Serial Port 1" is set to Enabled) This item displays the base I/O port address and the Interrupt Request address of a serial port specified by the user. Change Settings This feature specifies the base I/O port address and the Interrupt Request address of Serial Port 1.
  • Page 106 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual COM1 Console Redirection Settings Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 107 Chapter 6: UEFI BIOS Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled.
  • Page 108 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Bits Per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 109 Chapter 6: UEFI BIOS Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects the settings for the function keys and the key pad used for Putty, which is a terminal emulator designed for the Windows OS.
  • Page 110 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Terminal Type Use this feature to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII character set. Select VT100+ to add color and function key support. Select ANSI to use the extended ASCII character set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 111 Chapter 6: UEFI BIOS The High Performance Event Timer is used to replace the 8254 Programmable Interval Timer. The options are Disabled and Enabled. Trusted Computing (Available when a TPM device is installed  and detected by the BIOS) When a TPM (Trusted-Platform Module) device is detected in your machine, the following information will be displayed.
  • Page 112 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual • Active PCR banks • Available PCR banks SHA-1 PCR Bank Select Enabled to enable SHA-1 PCR Bank support to enhance system security and data integrity. The options are Enabled and Disabled. SHA256 PCR Bank Select Enabled to enable SHA256 PCR Bank support to enhance system security and data integrity.
  • Page 113 Configuration" in the "Chipset/North Bridge" submenu). Note 2: For more information on TPM, please refer to the TPM manual at http://www. supermicro.com/manuals/other. HTTP Boot Configuration  This feature allows the user to configure HTTP Boot settings. When you select this submenu and press <Enter>, the following features will display:...
  • Page 114 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Enroll Cert (Certification) Using File  This feature allows the user to enroll the security certificate in the system by using a file. Cert (Certification) GUID (Global Unique Identifier) This feature displays the GUID for this system.
  • Page 115 Chapter 6: UEFI BIOS Intel Virtual RAID on CPU ®  This submenu displays the information of the Intel® VMD controllers as detected by the BIOS. Intel® Optane(TM) DC Persistent Memory Configuration (Available when Apache Pass device plug-in) This submenu configures AEP (Apache Pass) device parameters and displays driver version. Version Select an action below.
  • Page 116 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual This submenu allows the user to view and to configure the settings of the DCPMM memory modules installed in the system. DIMM ID  This submenu allows the user to view and to perform an action on a DCPMM module specified by the user.
  • Page 117 Chapter 6: UEFI BIOS • Part Number • Socket • Memory Controller ID • Vendor ID • Device ID • System Vendor ID • Subsystem Vendor ID • Subsystem Device ID • Device Locator • Subsystem Revision ID • Interface Format Code •...
  • Page 118 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual • Controller Revision ID • IS New • Memory Capacity • APP Direct Capacity • Unconfigured Capacity • Inaccessible Capacity • Reserved Capacity • Peak Power Budget [mW] • Avg (Average) Power Budget [mW] •...
  • Page 119 Chapter 6: UEFI BIOS • Modes Supported • Boot Status • AIT DRAM Enabled • Error Injection Enabled • Media Temperature Injection Enabled • Software Triggers Enabled • Software Triggers Enabled Details • Poison Error Injections Counter • Poison Error Clear Counter •...
  • Page 120 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual • Alarm Enabled State: This feature indicates the status of the non-critical threshold alarm for the DCPMM module specified by the user. • Modify Non-critical Thresholds: Use this feature to modify non-critical thresholds. • Controller Temperature: This feature displays the controller temperature in Celsius.
  • Page 121 Chapter 6: UEFI BIOS Back to Main Menu  Select this feature and press <Enter> to go back to the Intel® Optane® DC Persistent Memory Configuration menu. Configure Security  Use this feature to configure the security settings for all onboard DCPMM modules. State Select Enabled to configure the security settings for the DCPMM modules installed in the system.
  • Page 122 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Back to Main Menu  Select this feature and press <Enter> to go back to the Intel® Optane® DC Persistent Memory Configuration menu. Regions  Current Configuration Region ID  When this submenu is selected, the following items will display: •...
  • Page 123 Chapter 6: UEFI BIOS • Reserved [%]: Use this feature to reserve a percentage of the DCPMM capacity for a particular purpose and keep this portion of memory space from being mapped into the physical address of system for system use. •...
  • Page 124 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual • Block Size • Units: Use this feature to change the namespace capacity (in the unit of B, MB, MiB, GB, GiB, TB, and TiB.) • Capacity • Label Version Save: After configuring the settings for the namespace above, click on <Save> to save changes.
  • Page 125 Chapter 6: UEFI BIOS Back to Namespace  Select this feature and press <Enter> to go back to the Namespaces submenu. Back to Main Menu  Select this feature and press <Enter> to go back to the Intel® Optane® DC Persistent Memory Configuration menu.
  • Page 126 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Select Enabled for the quick diagnostics test to be performed on the DCPMM module. The options are Enabled and Disabled. (Note: More DIMM IDs will appear If more DCPMM modules are installed on the motherboard.)
  • Page 127 Chapter 6: UEFI BIOS App Direct Settings This feature displays the Application Direct Settings. The default setting is 4KB_4KB (Recommended). App Direct Granularity This feature allows the user to view and modify the minimum App Direct Granularity for each DIMM installed on the motherboard. The default setting is Recommended and 1. Back to Main Menu Use this feature to go back to the Intel®...

  • Page 128: Event Logs

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 6.4 Event Logs Use this feature to configure the Event Log settings. Change SMBIOS Event Log Settings  Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 129 Chapter 6: UEFI BIOS SMBIOS Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events. The options are Enabled and Disabled. MECI (Multiple Event Count Increment) Enter the increment value for the multiple event counter. Enter a number between 1 to 255. The default setting is 1.

  • Page 130: Ipmi

    SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual 6.5 IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. When you select this submenu and press the <Enter> key, the following information will display: • BMC Firmware Revision: This feature indicates the BMC firmware revision used in your system.
  • Page 131 Chapter 6: UEFI BIOS Erasing Settings Erase SEL Select "Yes, On next reset" to erase all system event logs upon next system boot. Select "Yes, On every reset" to erase all system event logs upon each system reboot. Select "No" to keep all system event logs after each system reboot.
  • Page 132 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual • Gateway IP Address: This feature displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1). • VLAN (available when Update IPMI LAN Configuration is set to Yes): This feature displays the status of VLAN support.

  • Page 133: Security

    Chapter 6: UEFI BIOS 6.6 Security This menu allows the user to configure the following security settings for the system. Administrator Password Use this feature to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long. User Password Use this feature to set the user password which is required to enter the BIOS setup utility.
  • Page 134 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Secure Boot Select Enabled to use Secure Boot settings. The options are Enabled and Disabled. Secure Boot Mode Use this feature to select the desired secure boot mode for the system. The options are Standard and Custom.
  • Page 135 Chapter 6: UEFI BIOS Restore DB defaults  Select Yes to restore database variables to the manufacturer default settings. The options are Yes and No. Secure Boot Variable/Size/Keys/Key Source Platform Key (PK)  This feature allows the user to enter and configure a set of values to be used as platform firmware keys for the system.
  • Page 136 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual OsRecovery Signatures  This feature allows the user to set and save the authorized signatures used for OS recovery. Select Update to update your "OS Recovery Signatures". Select Append to append your "OS Recovery Signatures". The settings are Update, and Append.

  • Page 137: Boot

    Chapter 6: UEFI BIOS 6.7 Boot Boot Mode Select Use this feature to select the type of devices from which the system will boot. The options are Legacy, UEFI (Unified Extensible Firmware Interface), and Dual. Legacy to EFI Support Select Enabled for the system to boot from an EFI OS when the Legacy OS fails. The options are Enabled and Disabled.
  • Page 138 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual  Delete Boot Option Use this feature to select a boot device to delete from the boot priority list. Delete Boot Option Use this feature to remove an EFI boot option from the boot priority list.

  • Page 139: Save & Exit

    Chapter 6: UEFI BIOS 6.8 Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 140 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Default Options Restore Optimized Defaults To set this feature, select Restore Optimized Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance.

  • Page 141: Appendix A Bios Codes

    Appendix A: BIOS Codes Appendix A BIOS Codes A.1 BIOS Error POST (Beep) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 142 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 143: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 144 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 145 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 146 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 147 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 148 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 149 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬...
  • Page 150 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 151 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 152 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 153 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 154 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 155 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 156 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 157 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
  • Page 158 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 159 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 160 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 161 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 162 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 163: Appendix C System Specifications

    Appendix C: System Specifications Appendix C System Specifications Processors Supports Dual Intel Xeon Scalable CPUs (Socket P) processors, which offer three Intel® UltraPath Interconnect (UPI) of up to 10.4 GT/s. Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel PCH C621 chipset BIOS...
  • Page 164 SuperStorage Server SSG-6049SP-E1CR60/90 User's Manual Operating Environment Operating Temperature: 10º to 35º C (50º to 95º F) Non-operating Temperature: -40º to 60º C (-40º to 140º F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
